Haier LE49B7000 User manual

49B7000EL

Contents

-1-

1 Safety and warnings........................................................................................................ ..2-3

2Introduction............................................................................................................... ......4

3Installation............................................................................................................... ....... 5-9

4Remote Controller......................................................................................................... .. 10

5TV Operation.................................................................................................................. 11-14

6Trouble shooting.............................................................................................................1 5

If you are going to clean the product,Unplug the TV,use

soft fabric,no water,never chemicals.

74W

PAL: BG

2 x 8W

00810 x291

123 cm

199

TV 48.25 MHz – 863.25 MHzFrequency

VGA x 1

1xoiduACP

Quick Set up Guide

Note:This product uses a panel consisting of sub pixels which require sophisticated technology to

produce. However, there may be a few bright or dark pixels on the screen. These pixels will have

no impact on the performance of the product.

INSTALLATION NOTES

Locate the TV in a room where light does not strike the screen directly. Total darkness or a reflection

on the screen can cause eyestrain. Soft and indirect lighting is recommended for comfortable viewing.

Allow enough space between the TV and the wall to permit ventilation.

Please do not attempt to rotate the TV on the stand.

Avoid excessively warm locations to prevent possible damage to the cabinet or premature component

failure.

Use the four screws to fix the TV onto a wall mounting bracket (not included) via the four VESA standard

holes on the back of the television.

Wall Mounting Installation Guidelines

Stand Assemble Instruction

INSTALLATION

Finished.Attach the stand base set to the bottom

of the TV by firmly tightening the

supplied 4pcs screws.

400.0

200.0

POWER

HDMI1, HDMI2, VGA, PC AUDIO, RF.

YPb/Pr, VIDEO/L/R, USB1, USB2, HEADPHONE.

Note: VIDEO and YPbPr share one audio channel.

RF.

The actual power wire is subject to goods.

Y Yellow (Video)
