H.Koenig UP810 User manual

INSTRUCTION MANUAL

MANUEL D'UTILISATION

BEDIENUNGSANLEITUNG

HANDBOEK

MANUAL DE UTILIZACION

MANUALE D’USO

UP810

2 IN 1 VACUUM CLEANER

BALAI ASPIRATEUR 2 EN 1

2 IN 1 HANDSTAUBSAUGER

2 IN 1 STEEL STOFZUIGER

ASPIRADORA DE MANGO 2 EN 1

2 IN 1 SCOPA ASPIRAPOLVERE

ENGLISH

IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE.

RETAIN INSTRUCTIONS FOR FUTURE REFERRENCE.

Do not use in rain or leave outdoors whilst raining

WARNING: Basic safety precautions should always be

observed when using an electrical appliance, including the

following to reduce the risk of fire, electrical shock, or injury.

Personal Safety:

1. Store indoors in a dry place out of the reach of children;

2. This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way

and understand the hazards involved. Children shall not

play with the appliance. Cleaning and user maintenance

shall not be made by children without supervision.

3. Don’t let children play with the appliance; supervise

children using or maintaining the appliance;

4. Use only manufacturer’s recommended attachments as

described in this manual; misuse or use of any accessory

or attachment other than those recommended, may

present a risk of personal injury;

5. Take extra care when cleaning stairs;

6. Keep the appliance and accessories away from hot

surface;

7. Do not block the appliances openings or hinder air flow,

keep openings free of any objects including dust, lint,

clothing, fingers (and all parts of the body);

8. Particularly keep hair away from openings and moving

parts;

9. The device must not be used if it has been dropped, it

obvious signs of damage are visible or if it has leaks.

Electrical Safety:

1. Only use batteries and chargers supplied by the

manufacturer;

2. Never modify the charger in any way;

3. The charger has been designed for a specific voltage.

Always check that the mains voltage is the same as that

stated on the rating plate;

4. A charger that is suitable for one type of battery pack

may create a risk of fire when used with another battery

pack;

5. Before use, check the charger cord for signs of damage

or ageing. A damaged or entangled charger cord increases

the risk of fire and electric shock;

6. Don not abuse the charger cord;

7. Never carry the charger by the cord;

8. Do not pull the cord to disconnect from a socket, grasp

the plug and pull to disconnect;

9. Don’t wrap the cod around the charger when storing;

10, Keep the charger cord away from hot surfaces and

sharp edges;

11. The supply cord cannot be replaced. If the cord is

damaged the charger should be discarded and replaced. It

must be replaced by the manufacturer, its service agent or

a qualified technician in order to avoid a hazard.

12. Do not handle the charger or the appliance with wet

hands;

13. Do not store or charge the appliance outdoors;

14. The charger must be removed from the socket before

removing the battery, cleaning or maintaining the

appliance.

15. Cleaning and maintenance should not be carried

out by children unless they are at least 8 years of age

and are supervised by an adult.

16. Keep the appliance and its power cord out of

reach of children under 8 years of age.

17. When using electrical equipment, safety precautions

must always be taken to prevent the risk of fire, electric

shock and/or injury in the event of misuse.

18. Make sure that the voltage rating on the

typeplate corresponds to your main voltage of your

installation. If this is not the case, contact the dealer and

do not connect the unit

19. Never leave the unit unattended while in operation.

20. Please keep this document at hand and give it to the

future owner in case of transfer of your device.

Battery safety:

1. This appliance includes Li-ion batteries, do not

incinerate batteries or expose to high temperatures,as

they may explode;

2. Liquid ejected from the battery may cause irritation or

burns;

3. in an emergency situation contact professional help

immediately;

4. Leaks from the battery cells can occur under extreme

conditions. Do not touch any liquid that leaks from the

battery. If the liquid that gets on skin wash immediately with

soap and water. If the liquid gets into the eyes, flush them

immediately with clean water for a minimum of 10 minutes

and seek medical attention. Wear gloves to handle the

battery and dispose of immediately in accordance with

local regulations;

5. Shorting the battery terminals may cause burns or fire;

6. When the battery pack is not in use, keep it away from

paper clips, coins, keys, nails, screws or other small metal

objects that could make a connection from one terminal to

another.

7. When you dispose of the appliance remove the battery

and dispose of the battery safely in accordance with local

regulations.

Service:

1. Before using the appliance and after any impact, check

for signs of wear of damage and repair as necessary;

2. Do not use the appliance if any part is damaged or

defective;

3. Repairs should be carried out by a service agent or a

suitably qualified person in accordance with relevant safety

regulations. Repairs by unqualified persons could be

dangerous;

4. Never modify the appliance in any way as this may

increase the risk of personal injury;

5. Only use replacement parts or accessories provided or

recommended by manufacturer.

Intended use:

1. This appliance has been designed for domestic dry

vacuum cleaning only;

2. Do not pick up liquids or use on wet surfaces;

3. Do not pick up anything that is flammable, burning or

smoking;

4. Use only as described in this manual;

5. Don’t use on concrete, tarmacadam or other rough

surfaces.

WARNING:

1. Do not use water, solvents, or polishes to clean the

outside of the appliance; wipe clean with a dry cloth;

2. Never immerse the unit in water and do not clean in a

dish washer.

Introduction of components:

Metal tube

loacker

Metal tube

Power brush

locker

Power brush

Switch

Handle with

Dust cup

Charger

base

2 in 1

crevice

I Use as the stick vacuum cleaner

a) Assemble the battery into the dust cup, make sure the battery bolt head insert the dust cup

slot rightly as below

b) Attached the metal tube to the body as

below until hear click sound

c) Attached the brush to another head of metal tube

as below showed

d) Press the switch to work

Dust cup slot

Battery bolt

head

A Lower power

It’s lower power when your press the switch button first time

B high power

Its high power when you press the switch button second time

It will be power off when press third time, it’s kind of circle as

below showed

II How to use as handly

Insert the accessory (2in 1 crevice or long crevice) to body as below showed

BATTERY CHARGING:

When the battery power indictor

Is blinking, please power off then

Put back to charge base for charging

As left showed

HOW TO EMPTY THE DUST CUP:

1. Press the metal

tube locker then

take out the metal

2. unlock the dust

cup locker

3. Empty the dust

cup

Blinking

Lower power

HOW TO MAINTAIN THE FILTER:

1. Press the battery locker

to unattached the battery

from dust cup

2. Open the dust cup as

below showed

3. Take out the filter case,

then take out the filter

4. wash the filter case and

HEPA filter

5. Please dry the HEPA filter

and filter case completely

before assemble back

6. After drying, assemble

the filter to the case

7. put the filter case back to

the dust cup

8. assemble the dust cover

into the dust cup as below

showed

TROUBLESHOOTING:

Not cleaning Well

1. Empty the dust bin

2. Check dust bin is correctly fitted

3. Check the filter is correctly fitted

4. Clean the filter

Stop or won’t work

1. Charge battery

2. Clear debris from brush bar

Battery will not

charge

1. Check connections

2. Check wall socket

TECHNICAL SPECIFICATION:

Battery

22.2V/2200mA

Charging period

4 hours

Battery charger output

26V/500mA

Net Weight

2.3kg

Usage time

35min (low speed), 20min (high speed)

Power

160W

Airflo

30m3/s

ENVIRONMENT

CAUTION:

Do not dispose of this product as it has with other household products. There is a

separation of this waste product into communities, you will need to inform your local

authorities about the places where you can return this product. In fact, electrical and

electronic products contain hazardous substances that have harmful effects on the

environment or human health and should be recycled. The symbol here indicates that electrical

and electronic equipment should be chosen carefully, a wheeled waste container is marked with a

cross.

Adeva SAS / H.Koenig Europe - 8 rue Marc Seguin - 77290 Mitry Mory - France

www.hkoenig.com - [email protected] - [email protected] - Tél: +33 1 64 67 00 05
