H.Koenig STC68 User manual

INSTRUCTION MANUAL

MANUEL D’INSTRUCTIONS

BEDIENUNGSANLEITUNG

GEBRUIKSAANWIJZING

MANUAL DE INSTRUCCIONES

MANUALE D’USO

STC68

VACUUM CLEANER

ASPIRATEUR

STAUBSAUGER

STOFZUIGER

ASPIRADORA

ASPIRATORE

ENGLISH

SAFETY DIRECTIONS

1. For the first operation, it is advisable to read the manual

carefully before hand and keep it properly for future use.

2. Before the first operation, make sure the dust cup or the

dust bag is properly installed.

3. Make sure the power supply is 220-240V~ 50/60Hz

4. Do not vacuum water and inflammable material.

5. Do not vacuum burning material and ashes.

6. Do not use the machine without a motor protection filter

filled.

7. Please change the dust bag immediately when it was

damaged.

8. Do not store or use the machine close to high

temperature places.

9. Dot not let children use the machine in case of danger.

10. If abnormal noise, smell, smoke or any other failure or

breakage is found during the operation, you should turn

off the switch and unplug it. Then contact with your

service center for repair. Do not repair by yourself.

11. If the supply cord is damaged, it must be replaced by

the manufacturer or its service agent or a similarly

qualified person in order to avoid a hazard.

12. This appliance is not intended for use by persons

(including children) with reduced physical, sensory or

mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person

responsible for their safety.

13. Children should be supervised to ensure that they do

not play with the appliance.

14. The plug must be removed from the power socket

before any maintenance or replacement.

MAIN PART IDENTIFICATION

A. Floor Brush

G. Handle

B. Tube

H. On/Off Switch

C. Airflow Control

I. Cord Button

D. Bend Tube

J. Dust Cup Clip

E. Hose

K. Multi-cyclonic Plastic Filter

F. Hose Connector

L. Speed Control Button

BRIEF INTRODUCTION

This model features exquisite appearance, graceful in color, reasonable in internal structure. this

is multi-cyclone with plastic filter vacuum cleaner with foot push switch and automatic wire rolling

button on it, and also have many absorbing attachments. It features low noise and high efficiency.

It makes your life comfortable if you choose this machine

For the sake of safety, please comply with following instruction

1. After using, don't pull the power cable when you want to stop the power.

2. Don't run the appliance over the power cable when operating.

3. Don't absorb the burning cigarette.

4. Don't absorb water or other liquid.

5. Don't absorb sharp things or too heavy things.

6. Don't place it near heat source.

HOW TO USE

1. Preparation

(1) Let the end of the hose insert into the air intake socket until clicking position.

(2) After using, push the button on the hose and pull the end out.

(3) Fit the extension tube to the handle, tube and tube to floor brush as showing in the picture.

2. Using the machine

Pull out the wire to suitable length, insert the plug into power socket. Then press the switch to run

the machine. The vacuum cleaner begins to work. The part, which can adjust wind volume, is on

the handle.

*Attention: Don't extend the cable beyond the RED mark.

3. Using accessories for the floor.

4. Power and Cord Rewind Function

Your Vacuum Cleaner is equipped with an automatic cord rewind and power Button. Please press

the cord button and Switch button by foot in order to make it easier using.

REPLACING THE DUST-CUP

1. When the dust reach to the 1/4 level in the dust-cup, it means dust-cup is full. At this moment,

dust-cup should be emptied or the filter should be washed.

2. Open the dust-cup as showing in the picture.

MAINTENANCE

1. The filter should often be washed when it is dirty.

2. When the Plastic-filter is full of dust, it should be washed.

*Attention: Don't wash the filter in the washing machine or

dry it with electrical heater, please refix it after drying the

filter in the air.

3. Don't clean the outer-shell of vacuum cleaner in petrol

oil-like liquid. Please rub it with water and soft soap liquid.

*Attention:

(1).Don't clean the machine with the cloth full of water.

Don't let the water flow into the vacuum cleaner.

(2).Use only as described in manual. Only use

manufacturers recommended attachments.

(3). This appliance is intended to normal household use.

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

CHILDREN. SHOULD BE SUPERVISED TO ENSURE THAT

THEY DO NOT PLAY WITH THE APPLIANCE

ENVIRONMENT

CAUTION:

Do not dispose of this product as it has with other household products. There is a separation of this

waste product into communities, you will need to inform your local authorities about the places where

you can return this product. In fact, electrical and electronic products contain hazardous substances

that have harmful effects on the environment or human health and should be recycled. The symbol here indicates

that electrical and electronic equipment should be chosen carefully, a wheeled waste container is marked with a

cross.

Adeva SAS / H.Koenig Europe - 8 rue Marc Seguin - 77290 Mitry Mory - France

www.hkoenig.com - [email protected] - contact@hkoenig.com - Tél: +33 1 64 67 00 01

FRANCAIS

INSTRUCTIONS DE SÉCURITÉ

1. Avant d’utiliser l’appareil, il est recommandé de lire

attentivement le manuel et de le conserver en lieu sûr.

2. Avant la mise en route, assurez-vous que le

compartiment ou le sac à poussière soit

correctement installé.

3. Vérifiez que l’alimentation électrique possède ces

caractéristiques : 220-240V~ 50/60Hz

4. N’aspirez ni eau ni matériaux inflammables.

5. N’aspirez ni de matériaux brulés ni de cendres.

6. N’utilisez pas l’aspirateur sans que le moteur ne soit

protégé par un filtre.

7. Veuillez changer le sac à poussière s’il est endommagé.

8. N’utilisez pas l’aspirateur et ne le rangez pas dans des

endroits très chauds.

9. Ne laissez pas les enfants se servir de l’aspirateur en

cas de danger.

10. S’il y a un bruit ou une odeur anormale, de la fumée

ou tout autre problème durant son fonctionnement,

éteignez puis débranchez l’appareil. Contactez alors

votre revendeur et ne réparez pas l’aspirateur par

vous-même.

11. Si le câble d’alimentation est endommagé, il doit

être remplacé par le fabricant, ou son agent, ou

encore par une personne qualifiée afin d’éviter tout

accident.

12. Il n’est pas prévu que cet appareil soit utilisé par des

personnes (enfants compris) possédant des infirmités

physiques, mentales ou sensorielles, un manque

d’expérience ou de connaissance, à moins qu’elles

ne soient surveillées ou qu’elles n’aient reçues des

instructions de la part de leur responsable.
