Grundig VCH 7830 User manual

HANDHELD

VACUUM CLEANER

VCH 7830

_________________________________________________________________

J K

_________________________________________________________________

DEUTSCH 4 - 8

ENGLISH 9 - 13

FRANÇAIS 14 - 18

ITALIANO 19 - 23

PORTUGUÊS 24 - 28

ESPAÑOL 29 - 33

POLSKI 34 - 38

ČESKY 39 - 43

MAGYAR 44 - 48

TÜRKÇE 49 - 53

ΕΛΛΗΝΙΚΑ 54 - 58

ENGLISH 9

Please note the following instructions when

using the appliance.

7This appliance is intended for domestic use

only. Claims on the guarantee are not valid if

the appliance is used for industrial or commer-

cial purposes.

7Follow these instructions to prevent damaging

the appliance or danger arising from

improper use. Keep them in a safe place.

7Do not use on wet surfaces.

7Do not use the appliance in damp

surroundings.

7Never put the appliance in water or other

liquids.

7Keep the appliance and the accessories

away from eyes and ears while operating.

7This appliance is designed for vacuuming dirt

and dust particles. Do not attempt to use it on

large objects which could block the appli-

ance and damage it.

7Do not use it on cigarette stubs, ash from a

fireplace or matches. This could cause a fire.

7Never operate the appliance without the dust

container and filter.

7Do not use the appliance if the air duct and

the ventilation slot are blocked. Always keep

the air ducts and ventilation slot free of dirt,

hair and any other elements which could

obstruct or block the air flow.

7Never use the appliance if it is visibly

damaged. This also applies if the appliance

has become accidently wet.

Please contact your specialist dealer if this is

the case.

7Only use the power supply unit supplied to

charge the appliance.

7Keep the appliance out of the reach of

children.

7Only store the appliance in a dry, safe place.

7Do not open the appliance under any circum-

stances. No warranty claims are accepted

for damage resulting from improper handling.

SAFETY_______________________________________________________

10 ENGLISH

Dear customer,

Congratulations on the purchase of your

VCH 7830 handheld vacuum cleaner.

Read the following user notes carefully to

ensure you can enjoy your quality product from

Grundig for many years to come.

Special features

– Extremely powerful and handy, bagless

vacuum cleaner

– Washable dust ﬁlter

– Especially lightweight (800 grams)

– Approx. 300ml dust container capacity

– Extra strong suction power at intake with

65 W

Controls and individual parts

See the illustrations on page 2.

Handle.

Switch for turning on and off.

Charging display.

Dust filter.

Dust container with suction intake.

Charging contacts.

Accessories

Charging unit.

LED for power supply.

Charging contacts in the charging unit.

Socket for the mains cable.

Power supply unit.

OVERVIEW _________________________________________________

ENGLISH 11

Charging unit

You can set up the charging unit anywhere

where there is a power supply available.

Charging

Check if the type plate on the power supply

unit corresponds to your local mains supply.

1Press the button to switch off the device.

2Fit the appliance exactly into the charging

unit .

Note

7Make sure that the charging contacts of

the charging unit are congruent with the

contacts on the appliance.

3Plug the power cord into the socket on

the charging unit.

4Plug the power supply unit into the socket.

– The charging begins and the charging

display lights up red.

Notes

7Charge up the battery completely (14 -16

hours) before you first use it or if you have

not used it for a long time.

7Charge the appliance at room temperature.

Low or high temperatures will affect the serv-

ice life of the battery.

7The ambient temperature should be between

5 °C and 40 °C.

7When fully charged, the appliance works for

around 15 minutes.

It is not advisable to charge the batteries after

each use. Particularly if it has not been used

for the full 15 minutes operating time. Only

charge the batteries when they are completely

discharged. This increases their service life.

Do not charge them every day.

7The power supply unit and the charging unit

heat up while charging. This is totally normal.

7The charging unit has a blue LED light which

lights up when the charging unit is connected

to the mains with the power supply unit.

POWER SUPPLY __________________________________________

12 ENGLISH

Switching on and off and use

1Remove the appliance from the charging

unit .

2Press the switch to turn on the appliance.

3Do the vacuuming required.

4Press the switch again to turn off the

appliance.

Emptying and cleaning the

dust container

1Press the switch to turn off the appliance.

2Hold the appliance upright with the suction

intake facing downwards.

3Release the dust container and remove

by turning clockwise.

4Remove the ﬁlter from the dust container.

Note

7Wash the filter with warm soapy water occa-

sionally. Leave it to dry completely after

washing.

5Empty the dust container and clean with

a damp cloth if necessary.

Note

7Leave the dust container to dry completely

before you insert it again.

6Insert the filter into the dust container

again.

7Relace the dust container by turning it

anti-clockwise until it locks into place.

Cleaning and care

7Do not clean the appliance with chemical

cleaning agents. This could damage the

housing.

7Only clean the appliance with a damp cloth

and a mild detergent.

7Brush out the filter over a dustbin.

7Wash the filter and the inside of the dust con-

tainer. Do not wash the filter in the washing

machine.

7The filter and dust container must be comple-

tely dry before they are used again.

OPERATION________________________________________________

ENGLISH 13

Environmental note

This product is manufactured from high-quality

parts and materials which can be reused and

recycled.

Therefore, do not dispose of the product along

with normal household waste at the end of its

service life. Take it to a collection point for the

recycling of electrical and electronic equipment.

This is indicated by this symbol on the product,

in the operating manual and on the packaging.

Please ﬁnd out about collection points operated

by your local authority.

Help protect the environment by recycling used

products.

Technical data

This product conforms to the

European directives

2004/108/EC and

2006/95/EC.

Power supply

Power supply unit

Rechargeable battery: NiMH, 9.6 Volt

Protection class

III

INFORMATION ___________________________________________

Ni-MH

Technical and design modifications are

reserved.

Grundig Multimedia B.V.

Atrium, Strawinskylaan 3105 • NL-1077 ZX Amsterdam • http://www.grundig.com
