Grundig Sonoclock 390 User manual
CLOCK RADIO
Sonoclock 390
Sonoclock 390 QL
frde en esit pt
___________________________________________________________
2
FM..MW
FM..LW
TUNING
SNOOZE SLEEP FM MHz MW kHZ
FM MHz LW kHZ
TIME
HOUR
ALARM MIN
C
___________________________________________________________
3
DEUTSCH 04 -13
ENGLISH 14 - 23
FRANÇAIS 24 - 33
ITALIANO 34 - 43
PORTUGUÊS 44 - 53
ESPAÑOL 54 - 63
14 ENGLISH
SAFETY AND SET-UP____________________________
7 This device is designed for the playback of audio signals. Any other use
is expressly prohibited.
7 Protect the device from moisture (water drops or splashes). Do not
place any vessels such as vases on the device. These may be knocked
over and spill fluid on the electrical components, thus presenting a
safety risk.
7 Do not place any naked flames such as candles on the device.
7 Make sure the device is adequately ventilated. Do not cover the ventila-
tion slots with newspapers, table cloths, curtains, etc.
7 When deciding where to place the device, please note that furniture
surfaces are covered by various types of varnish and plastic, most of
which contain chemical additives. These additives can corrode the
device supports, leaving residues on the furniture surfaces which can be
difficult or impossible to remove.
7 Do not use any cleaning agent, as this may damage the casing. Clean
the device with a clean, moist leather cloth.
7 Do not expose the back-up battery to extreme heat, caused for example
by direct sunlight, heaters or fire.
7 Never open the device casing. No warranty claims are accepted for
damage caused by incorrect handling.
7 The type plate is located on the bottom of the device.
ENGLISH 15
OVERVIEW ______________________________________
See the figure on page 2.
Controls on the top
SNOOZE Interrupts the alarm function. Stops the sleep timer.
TIME Press and hold down to activate the time setting.
ALARM Press and hold down to activate the alarm setting.
Press briefly to cancel the alarm standby.
Displays the alarm time (in standby mode).
HOUR For setting the hours.
Press briefly to change the hour step-by-step.
Hold down to change the hour continuously.
MIN For setting the minutes.
Press briefly to change the minutes step-by-step.
Hold down to change the minutes continuously.
SLEEP Activates the sleep timer.
16 ENGLISH
OVERVIEW ______________________________________
Controls on the sides
The slide switch on the left side of the device switches
the radio on or to standby.
In alarm mode, it switches between the signal tone and
the radio station; cancels the alarm standby.
CAdjusts the volume (on left side of device).
FM and MW frequency scale, on right side of device
(SC 390).
FM and LW frequency scale, on right side of device
(SC 390 QL).
TUNING For tuning to radio stations (on right side of device).
FM• • MW FM and MW frequency band switch, on right side of
device (SC 390).
FM• • LW FM and LW frequency band switch, on right side of de-
vice (SC 390 QL).
Controls on the back
ÜMains cable.
Wire antenna for FM reception.
The device has a built-in antenna for MW reception (SC
390) or for LW reception (SC 390 QL). Turn the device
around to direct the antenna.
Controls on the bottom
Battery compartment for back-up battery.
The display
•LED, indicates that the alarm setting is activated.
10:00 Displays the time, the alarm time and the sleep timer
time.
FM MHz
MW KHz
FM MHz
LW KHz
ENGLISH 17
POWER SUPPLY ________________________________
Mains operation
Check that the mains voltage on the type plate (on the bottom of the device)
corresponds to your local mains supply. If this is not the case, contact your
specialist dealer.
1Plug the mains cable into the socket (230V~, 50 Hz – SC 390;
230V~, 50/60 Hz – SC 390 QL).
Caution:
The device is connected to the mains with the power plug. To fully
disconnect the device from the mains, pull out the plug.
The mains plug is used to disconnect the device. It shall remain readily
operable and should not be obstructed during intended use.
Inserting the back-up battery
During mains operation, the back-up battery ensures that stored settings
are not lost in the case of a power failure or when the device is briefly
disconnected from the mains.
1Open the battery compartment lid by pressing on the arrow and pushing
down the lid.
2When inserting the battery (9 V, 6LF 22), observe the polarity marked on
the base of the battery compartment.
3Close the battery compartment.
Note:
Remove the back-up battery when it is flat or when you know that the
device will not be used for a long period of time.
Batteries, including those which do not contain heavy metal, should not
be disposed of with household waste. Always dispose of used batteries
in accordance with local environmental regulations
18 ENGLISH
SETTINGS________________________________________
Setting the clock
When you switch on the device for the first time, the time flashes in the display
to indicate that you must set the clock. The same thing applies after a power
failure, or if the device has been plugged out and no back-up battery is
inserted.
1Press and hold down »TIME«.
2Press »HOUR« briefly to set the hours step-by-step or hold it down to run
through the hours quickly.
3Press »MIN« briefly to set the minutes step-by-step or hold it down to run
through the minutes quickly.
Note:
When the minute display changes from »59« to »00«, this does not affect
the hour display.
4Release »TIME« to conclude the setting.
– Display: the current time.
Setting the alarm time
1Press and hold down »ALARM«.
2Press »HOUR« briefly to set the hours step-by-step or hold it down to run
through the hours quickly.
3Press »MIN« briefly to set the minutes step-by-step or hold it down to run
through the minutes quickly.
4Release »ALARM« to conclude the setting.
5Use the » « slide switch to set the alarm signal you require (» «
= radio station » « = signal tone).
– Display: the » « LED lights up, i.e. the alarm setting is activated.
– The device switches on at the set alarm time with the selected alarm
signal.
ENGLISH 19
OPERATION_____________________________________
Switching on and off
1Use » « to switch the device on and to standby.
Radio turns on
Standby, radio/signal tone turn off
Wake by radio
Wake by signal tone
Radio operation
For the best FM (VHF) reception, it is sufficient to direct the wire antenna
accordingly.
Tuning radio stations
1Set the frequency band with »FM••MW« (SC 390);
or
set the frequency band with »FM••LW« (SC 390 QL);
2Find and tune the station using »TUNING«.
Adjusting the volume
1Adjust the volume using »C«.
Alarm mode
Displaying the alarm time
1Press and hold down »ALARM«.
– Display: the last alarm time set.
2Release »ALARM«.
– Display: the current time.
20 ENGLISH
Alarm with radio station
1Use » « to switch on the device.
2Set the frequency band with »FM• • MW« (SC 390) or with »FM••LW«
(SC 390 QL).
3Find and tune the station using the »TUNING«.
4Set the alarm volume using »C«.
Note
If the alarm volume is set to minimum, the sound cannot be heard at the
alarm time.
5Select the radio alarm (» «) with » «.
– The radio switches on at the set alarm time (alarm duration 1 hour,
59 minutes).
Alarm with signal tone
1Select the signal tone alarm (» «) with » « .
– The signal tone switches on at the set alarm time (alarm duration
1 hour, 59 minutes).
Interrupting the alarm
1Press »SNOOZE« while the alarm is sounding.
– The alarm (signal tone or radio) stops.
– The alarm goes on again at 9-minute intervals (the total alarm time is
1 hour, 59 minutes).
Cancelling the alarm for the day
1Press »ALARM« while the alarm is sounding.
– The alarm (signal tone or radio) stops, but the alarm function remains
activated for the next day at the set time.
