Grundfos SE1 50 Installation instructions
SE1 50, 80, 100 - SEV 65, 80, 100
Safety instructions
Safety instructions and other important information
GRUNDFOS INSTRUCTIONS
SE1 50, 80, 100 - SEV 65, 80, 100
English (GB)
Safety instructions................................................5
Български (BG)
Инструкции за безопасност .......................................33
Čeština (CZ)
Bezpečnostní pokyny ............................................68
Deutsch (DE)
Sicherheitshinweise .............................................97
Dansk (DK)
Sikkerhedsanvisninger...........................................132
Eesti (EE)
Ohutusjuhised ................................................160
Español (ES)
Instrucciones de seguridad........................................189
Suomi (FI)
Turvallisuusohjeet ..............................................223
Français (FR)
Consignes de sécurité ...........................................251
Ελληνικά (GR)
Οδηγίες ασφαλείας .............................................283
Hrvatski (HR)
Sigurnosne upute ..............................................318
Magyar (HU)
Biztonsági utasítások ...........................................346
Italiano (IT)
Istruzioni di sicurezza ...........................................377
Lietuviškai (LT)
Saugos nurodymai .............................................410
Latviešu (LV)
Drošības instrukcijas ............................................438
Nederlands (NL)
Veiligheidsinstructies ............................................468
Polski (PL)
Zasady bezpieczeństwa..........................................500
3
Table of contents
Português (PT)
Instruções de segurança .........................................532
Română (RO)
Instrucţiuni de siguranţă..........................................564
Srpski (RS)
Sigurnosna uputstva ............................................594
Русский (RU)
Указания по технике безопасности .................................622
Svenska (SE)
Säkerhetsinstruktioner...........................................658
Slovensko (SI)
Varnostna navodila .............................................687
Slovenčina (SK)
Bezpečnostné pokyny ...........................................716
Türkçe (TR)
.............................................745
Українська (UA)
Інструкція з техніки безпеки ......................................774
中文 (CN)
安全指导 ....................................................810
Norsk (NO)
Sikkerhetsinstruksjoner ..........................................833
(AR)
...................................................861
繁體中文 (TW)
安全指示 ....................................................885
Tiếng Việt (VI)
Hướng dẫn an toàn.............................................908
Declaration of conformity .......................................937
Declaration of conformity .......................................940
Declaration of performance ......................................942
Operating manual EAC .........................................958
4SE1 50, 80, 100 - SEV 65, 80, 100
Table of contents
English (GB) Safety instructions
■Original safety instructions
These safety instructions give a quick overview of the
safety precautions to be taken in connection with any
work on this product.
Observe these safety instructions during handling,
installation, operation, maintenance, service and
repair of this product.
These safety instructions are a supplementary
document, and all safety instructions will appear
again in the relevant sections of the installation and
operating instructions.
Keep these safety instructions at the installation site
for future reference.
General information
This appliance can be
used by children aged
from 8 years and above
and persons with re-
duced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision
or instruction concerning
use of the appliance in a
safe way and under-
stand the hazards in-
volved.
Children shall not play
with the appliance.
Cleaning and user main-
tenance shall not be
made by children without
supervision.
Read this document be-
fore you install the prod-
uct. Installation and op-
eration must comply with
local regulations and ac-
cepted codes of good
practice.
Product description
5
6
1
2
3
4
7
9
10
8
TM065987
SE pump
Pos. Description
1 Lifting bracket
2 Nameplate
3 Sleeve
4 Oil screw
5 Outlet flange
6 Outlet opening
7 Cable plug
8 Top cover
9 Clamp
10 Pump housing
5
English (GB)
Intended use
The SE1 and SEV pumps are designed for
transferring wastewater, process water and
unscreened raw sewage in heavy-duty municipal,
utility and industrial applications.
The pumps are available with S-tube® or SuperVortex
impellers allowing the free passage of solids up to
100 mm.
The pumps can be used in permanent, dry- or
submerged installations on auto-coupling systems.
The pumps are also suitable for free-standing
installations or as portable pumps.
Pumped liquids
The standard cast iron versions are designed for
pumping the following liquids:
• large quantities of drainage, surface and storm
water
• domestic wastewater with discharge from toilets
• wastewater with a high content of fibres
(SuperVortex impeller)
• industrial process water
• wastewater with gaseous sludge
• municipal and commercial sewage and
wastewater.
Stainless steel versions
The stainless steel versions are suitable for pumping
the following liquids:
• industrial process water containing chemicals
• aggressive or corrosive drain water and effluent
• wastewater containing abrasives
• seawater contaminated with wastewater.
Nameplate
Fix the extra nameplate supplied with the pump at the
installation site or keep it in the cover of this booklet.
12 1311 19 6
2
1
3
4
5
7
8
9
10
18
17
16
15
20
21
22
23
24
25
14
Tmax: °C
Type: P.c.
Hmax: Qmax:
m
VA
A
m h
/
3
V
Model:
mInsul.class: Cosφ :
Motor: Hz
0197
~
n: min-1
kgWeight: IP68P1/P2： / kW
U.K Importer: Grundfos Pumps ltd
Grovebury Road Leighton Buzzard
Bedfordshire LU74TL DK-8850 Bjerringbro, Denmark
98948763 99657185Made in Tatabánya Hungary
For Converter Operation,
see manual
TM028398
Nameplate
Pos. Description
1Notified body and explosion protection
classification
2 Explosion protection mark
3 Type designation
4 Product number
5 Maximum head [m]
6 Enclosure class
7 Maximum installation depth [m]
8 Number of phases
9 Frequency [Hz]
10 Speed [min-1]
11 Motor input power P1 [kW]
12 Motor output power P2 [kW]
13 Country of production
14 Explosion protection certificate number
15 Standard for wastewater lifting stations for
buildings and installation sites
16 Maximum flow rate [m3/h]
17 Production code (year/week)
18 Maximum liquid temperature [°C]
19 Insulation class
20 Power factor
21 Rated current [A], delta connection
22 Rated voltage [V], delta connection
23 Rated current [A], star connection
24 Rated voltage [V], star connection
25 Net weight [kg]
Type key
Example: SE1.80.80.40.A.Ex.4.51D.B
Code Explanation Designation
SE Sewage and wastewater
pump Pump type
1S-tube® impeller Impeller type
V SuperVortex impeller
80 Maximum solids size [mm] Pump passage
80 Nominal diameter [mm] Pump outlet
40 Output power P2/10 Power [kW]
6
English (GB)
Code Explanation Designation
[ ] Standard (without sensor) Sensor version
A Sensor version
[ ] Non-explosion-proof pump
(standard) Pump version
Ex Explosion-proof pump
2 2-pole Number of
poles
4 4-pole
50 50 Hz Frequency
[Hz]1
0B 400-415 V, DOL
Voltage and
starting method
0D 380-415 V, DOL
1D 380-415 V, Y/D
0E 220-240 V, DOL
1E 220-240 V, Y/D
[ ] First generation Generation2
B Second generation
[ ] Cast iron impeller, pump
housing and top cover
Pump materials
Q
Stainless steel impeller,
cast iron pump housing
and top cover
REntire pump of stainless
steel
S
Stainless steel pump hous-
ing, impeller and intermedi-
ate flange and cast iron top
cover (on request)
D Stainless steel
Z Custom-built products Customisation
1 Maximum frequency in case of frequency-converter
operation.
2 The generation code distinguishes between pumps
of different design, but with the same power rating.
Approvals
SE1 and SEV pumps have been tested by Dekra /
KEMA. The explosion-proof version hold two
examination certificates:
• ATEX(EU): KEMA 04ATEX2201X
• IECEx: IECEx DEK 21.0017X.
Both certificates have been issued by Dekra. The
standard versions of SE1 and SEV pumps are tested
by VDE.
Approval standards
The standard variants are approved by TÜV
Rheinland (LGA) notified body under the Construction
Products Directive according to EN 12050-1 or EN
12050-2 as specified on the nameplate.
Explanation of the Ex approval
The SE1 and SEV pumps have the following
explosion protection classifications:
• CE 0344 II 2 GD Ex db eb h mb IIB T4, T3 Gb;
Ex h mb tb IIIC T135 °C, T200 °C Db.
Directive or
standard Code Description
ATEX
CE 0344 = CE marking of conformity according to the ATEX directive 2014/34/EU. 0344 is
the number of the notified body which has certified the quality system for ATEX.
= The equipment conforms to harmonised European standard.
II = Equipment group according to the ATEX directive, defining the requirements
applicable to the equipment in this group
2 = Equipment category according to the ATEX directive, defining the requirements
applicable to the equipment in this category
G = Explosive atmosphere caused by gases, vapours or mists
D = Explosive atmosphere caused by dust
7
English (GB)
Directive or
standard Code Description
Harmonised
European
standard
Ex = Marking of explosion protection
h = Constructional safety (c) and Liquid immersion (k) according to EN ISO
80079-36 and EN ISO 80079-37
db = Flameproof enclosure according to EN 60079-1
eb = Protection according to EN 60079-7
mb = Encapsulation according to EN 60079-18
IIB = Classification of gases, see EN 60079-0. Gas group B includes gas group A.
T4/T3 = Maximum surface temperature is 135 °C (T4) in direct-drive pumps and 200 °C
(T3) in pumps operated by frequency converter, according to EN 60079-0*
Gb = Suitable for use in explosive gas atmospheres in zone 1 and zone 2
tb = Protection by enclosure EN 60079-31
IIIC = Conductive dust
T135 °C /
T200 °C = Maximum surface temperature
Db = Suitable for use in explosive dust atmospheres in zone 1 and zone 2
*For motors connected to a frequency converter, the
maximum surface temperature T3 is 200 °C.
Australia
Explosion-proof variants for Australia are approved as
Ex nA II T3 according to IEC 60079-15
(corresponding to AS 2380.9).
Standard Code Description
IEC 60079-15:1987
Ex = Area classification according to AS 2430.1
nA = Non-sparking according to AS 2380.9:1991, section 3
(IEC 79-15:1987)
II = Suitable for use in explosive atmospheres (not mines)
T3 = Maximum surface temperature is 200 °C
XThe letter X in the certificate number indicates that the
equipment is subject to special conditions for safe use.
8
English (GB)
Potentially explosive environments
Use explosion-proof pumps for applications in
potentially explosive environments.
SE1 and SEV pumps
must under no circum-
stances pump combusti-
ble liquids.
The classification of the
installation site must be
defined by the owner.
Special conditions for
safe use of explosion-
proof pumps:
1. Make sure the mois-
ture switch and ther-
mal switches are
connected in the
same circuit, but
have separate alarm
outputs (motor stop)
in case of high hu-
midity or high tem-
perature in the mo-
tor.
2. Bolts used for re-
placement must be
class A2-70 or better
according to EN/ISO
3506-1.
3. Contact the manu-
facturer for informa-
tion on the dimen-
sions of the
flameproof joints.
4. The level of the pum-
ped liquid must be
controlled by level
switches connected
to the motor control
circuit. The minimum
level depends on the
installation type and
is specified in these
installation and oper-
ating instructions.
5. Make sure the per-
manently attached
cable is suitably me-
chanically protected
and terminated in a
suitable terminal
board placed outside
the potentially explo-
sive area.
6. The pumps have an
ambient temperature
range of -20 to +40
°C and a maximum
process temperature
9
English (GB)
of +40 °C. The mini-
mum ambient tem-
perature for a pump
with a water-in-oil
(WIO) sensor is 0 °C.
7. The thermal protec-
tor in the stator wind-
ings has a rated
switch temperature
of 150 °C and must
guarantee the dis-
connection of the
power supply. The
power supply must
be reset manually.
8. The control unit must
protect the WIO sen-
sor against short cir-
cuit current. The
maximum current
from the control unit
must be limited to
350 mA.
9. For painted pumps,
minimise the risk of
electrostatic dis-
charge by:
• Earthing (mandato-
ry).
• In dry installations,
keep a safety dis-
tance between
pumps and walking
paths.
• Use wet cloths for
cleaning.
10. The WIO sensor
must be used only
with a galvanically
isolated circuit.
11. The lock nut of the
cable connector
must only be re-
placed with an identi-
cal one.
Transporting the product
The pump may be transported and stored in a vertical
or horizontal position.
CAUTION
Crushing hazard
Minor or moderate per-
sonal injury
‐Make sure the pump
cannot roll or fall
over.
10
English (GB)
Other manuals for SE1 50
6
This manual suits for next models
5
Table of contents
Other Grundfos Water Pump manuals
Grundfos
Grundfos MAGNA 25-40 User manual
Grundfos
Grundfos SP Operating manual
Grundfos
Grundfos Home Booster 4.5 Manual
Grundfos
Grundfos SL User manual
Grundfos
Grundfos TPE User manual
Grundfos
Grundfos PS.W.04-20 User manual
Grundfos
Grundfos Unilift AP12 User manual
Grundfos
Grundfos MSS Series User manual
Grundfos
Grundfos DDE User manual
Grundfos
Grundfos CRE Series User manual
Grundfos
Grundfos UPM3 User manual
Grundfos
Grundfos alpha2 l User manual
Grundfos
Grundfos MTC User manual
Grundfos
Grundfos ALPHA1 B User manual
Grundfos
Grundfos Unilift KP 150 User manual
Grundfos
Grundfos DWK User manual
Grundfos
Grundfos LC 241 User manual
Grundfos
Grundfos MQ User manual
Grundfos
Grundfos DDC User manual
Grundfos
Grundfos UP Series User manual
Popular Water Pump manuals by other brands
Sykes AmeriPumps
Sykes AmeriPumps GP100M Operation and maintenance instructions
DUROMAX
DUROMAX XP WX Series user manual
BRINKMANN PUMPS
BRINKMANN PUMPS SBF550 operating instructions
Franklin Electric
Franklin Electric IPS Installation & operation manual
Xylem
Xylem e-1532 Series instruction manual
Milton Roy
Milton Roy PRIMEROYAL instruction manual
