Grizzly G4668 User manual
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P4668001 SWITCH BOX 6 P4668006 CONTACTOR RETAINER
2 P4668002 SWITCH BOX COVER ASSEMBLY 7 PS38M PHLP HD SCR M4-.7 X 10
2-1 P4668002-1 DATA LABEL, HNFB-18 8 PHTEK18 TAP SCREW #10 X 5/8
3 P4668003 CONTACTOR TECO CN-18 220V 9 PS10 PHLP HD SCR 10-24 X 1-1/2
4 P4668004 FIELD SWITCH 10 P4571010 LIQUID-TITE STRAIN RELIEF
5 P4668005 RELAY TECO RHN-18 23-32A 11 P4571011 RUBBER SEAL
5
2
4
6
7
1
3
2-1
COPYRIGHT © JANUARY, 2008 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE
REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#CR10356 PRINTED IN TAIWAN
8
10
11
9
Model G4668 Magnetic Switch
Parts
