Grizzly G0518 User manual
DRUM / FLAP SANDER
MODEL G0518
PARTS LIST
COPYRIGHT © JANUARY 2003 BY GRIZZLY INDUSTRIAL, INC
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
PRINTED IN TAIWAN
ONLINE PARTS LIST DISCLAIMER
THESE PARTS REPRESENT THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. THE MACHINE CONFIGURATION
CAN CHANGE AS PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF THE MACHINE, THIS PARTS
LIST MAY NOT EXACTLY DEPICT YOUR MACHINE. CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS ABOUT PART DIFFER-
ENCES. PREVIOUS PARTS LIST VERSIONS ARE NOT AVAILABLE ONLINE.
G0518 Drum/Flap SanderG0518 Drum / Flap Sander
PARTS DIAGRAMS AND LISTS
-B-
G0518 Drum/Flap Sander G0518 Drum / Flap Sander
19 P0518019 BRUSH
20 P0518020 1 HP MOTOR
21 P0518021 PLATE
22 PS08M PHLP HD SCR M5-0.8 X 12
23 P0518023 STRAIN RELIEF
24 PWRCRD110L POWER CORD 110V
25 P0518025 SANDING DRUM
26 PS06M PHLP HD SCR M5-0.8 X 20
27 P0518027 POWER SWITCH
28 P0518028 PLASTIC DISC PAD
29 PN18 HEX NUT 1"-8 LH
30 PLW01M LOCK WASHER 5MM
31 P0518031 FOAM
32 P0518032 MACHINE ID LABEL
33 P0518033 ROTATION LABEL
34 PLABEL-14 ELECTRICITY LABEL
35 PLABEL-12 READ MANUAL LABEL
36 PLABEL-11 SAFETY GLASSES LABEL
1PSB14M CAP SCREW M8-1.25 X 20
2PLW04M LOCK WASHER 8MM
3PW01M FLAT WASHER 8MM
4P0518004 ACRYLIC EYE SHIELD
5P0518005 DUST HOOD
6P0518006 ACRYLIC EYE SHIELD
7P0518007 DUST HOOD BRACKET
8P0518008 PLUG
9PSB12M CAP SCREW M8-1.25 X 40
10 P0518010 BASE
11 P0518011 DOOR LATCH ASSEMBLY
12 P0518012 DOOR COVER
13 PW05M FLAT WASHER 4MM
14 PS17M PHLP HD SCR M4-0.7 X 6
15 P0518015 STAND
16 PFN01M HEX FLANGE NUT M8-1.25
17 PN22 HEX NUT 1"-8
18 P0518018 BUSHING
REF PART # DESCRIPTION REF PART # DESCRIPTION
G0518 Drum/Flap SanderG0518 Drum / Flap Sander
G0518 Drum/Flap Sander G0518 Drum / Flap Sander
112 PS35 PHLP HD SCR 5/16" X 3/4"
113 P0518113 MOTOR BASE
114 PLW04M LOCK WASHER 8MM
115 P0518115 HEX NUT M8-1.25
116 PS18 PHLP HD SCR #10-24 X 1/4
117 P0518117 CAPACITOR CLAMP
118 P0518118 CAPACITOR
119 P0518119 CAPACITOR COVER
120 P0518120 CAPACITOR
121 P0518121 CAPACITOR COVER
122 P0518122 CAPACITOR CLAMP
101 P0518101 MOTOR SHAFT
102 P0518102 STATOR WINDING
103 P0518103 MOTOR BODY
104 PB09M HEX BOLT M8-1.25 X 20
105 P0518105 CENTRIFUGAL SWITCH
106 P6206 BALL BEARING 6206
107 P0518107 MOTOR COVER
108 P0518108 SPRING PLATE
109 PLW01M LOCK WASHER 5MM
110 PS18 PHLP HD SCR #10-24 X 1/4
111 PLW03M LOCK WASHER 6MM
REF PART # DESCRIPTION REF PART # DESCRIPTION
