Greenlee 7238SB SLUG-BUSTER Datasheet

Printed in U.S.A.

7238SB SLUG-BUSTER®PUNCH SET WITH RATCHETING WRENCH

PARTS LIST

CAT./UPC NO.

KEY 78-3310- DESCRIPTION QTY.

A 34941 Ratcheting 1" Box End Wrench 1

B 00042 3/8" Draw Stud 1

C 304AVBB/04042 3/4" Draw Stud 1

D 721-1/2/31756 1/2" Slug-Buster® Conduit Punch 1

D 14722 1/2" Conduit Die 1

E 721-3/4/31757 3/4" Slug-Buster® Conduit Punch 1

E 124AV/06972 3/4" Conduit Die 1

F 712-1/31758 1" Slug-Buster® Conduit Punch 1

F 126AV/04011 1" Conduit Die 1

G 721-1-1/4/31759 1-1/4" Slug-Buster® Conduit Punch 1

G 128AV/04013 1-1/4" Conduit Die 1

H 721-1-1/2/31760 1-1/2" Slug-Buster® Conduit Punch 1

H 440AV/04061 1-1/2" Conduit Die 1

I 721-2/31761 2" Slug-Buster® Conduit Punch 1

I 442AV/04063 2" Conduit Die 1

34758 Plastic Case 1

INSTRUCTIONS AND PARTS LIST

INSTRUCTIONS ET LISTE DES PIÈCES

INSTRUCCIONESY LISTA DE PIEZAS

7238SB SLUG-BUSTER®

1/2" Thru 2" Knockout Punch Set

with Ratcheting Wrench

7238SB SLUG-BUSTERmd

de 1/2 po à 2 po ensemble

de poinçon avec clé à rochet

7238SB SLUG-BUSTER®

1/2" a 2" equipo de perforadora

de impacto con llave de trinquete

Read and understand this material before operating. Failure to understand how to safely

operate the Slug Buster®set could result in an accident causing serious injury or death. This

tool should only be operated by qualified personnel.

Assurez-vous que vous avez lu et compris la documentation avant d’utiliser l’appareil. Si vous

necomprenezpascommentutiliserleSlugBustermd entoutesécurité,vouspourriezprovoquer

un accident entraînant des blessures graves, voire mortelles. Cet outil ne doit être utilisé que

par un personnel qualifié.

Leer y comprender este material antes de operar. La falta de comprensión acerca de cómo

operar con seguridad el equipo Slug Buster®puede ocasionar un accidente que cause lesiones

graves o muerte. Esta herramienta debe ser operada solamente por personal calificado.

www. .com information@itm.com1.800.561.8187

7238SB SLUG-BUSTER®PUNCH SET WITH RATCHETING WRENCH

Do not punch enclosures containing or close to

live circuits. Electrical shock could result causing

severe injury or death.

• When hole is completed the punch unit (punch, die and draw

stud) can fall free toward the die side.

• Make sure you have firm footing and balance when operating.

Position yourself to avoid injuries in case of slippage, break-

age or any other loss of control while punching.

Lubricate threads and cutting edges before use.

CAPACITY: 10 ga. mild steel

5Disassemble punch by turning

draw stud counterclockwise

while holding punch. Tip die and

drop out split slugs.

6For 3/4" through 2" conduit

sized holes use 304AVBB 3/4"

draw stud. Place selected size

die on draw stud. Insert draw

stud in 3/4" or larger pilot hole.*

Thread same size punch on the

draw stud with the cutting edge

toward the material being

punched.

7Turn draw stud clockwise with

34941 wrench until material is

punched.

CAUTION: punch will become

free of hole and could fall.

8Disassemble punch by turning

draw stud counter-clockwise

while holding punch. Tip die

and drop out split slugs.

OPERATING INSTRUCTIONS — SAVE THESE INSTRUCTIONS!

1The 1/2" conduit size punch

requires 3/8" or larger pilot hole.

Use Greenlee Kwik Stepper

pilot step drills.

2Place 1/2" conduit die on 3/8"

draw stud. Insert draw stud

through pilot hole.

3Thread punch on draw stud with

cutting edge toward material

being punched.

4Turn draw stud clockwise with

the 34941 wrench until material

is punched.

CAUTION: punch will become

free of hole and could fall.

* Time Saver: Use 1/2" conduit

punch to make 7/8" pilot hole

for 3/4"-2" conduit punches.

www. .com information@itm.com1.800.561.8187
