Grange ERP User manual

Grange Code: ERP

GRANGE FENCING LIMITED

Halesfield 21, Telford TF7 4PA

Tel:01952 588088 Fax:01952 581522

Email:[email protected] Web:www.grangefen.co.uk

OUT OF HOURS MESSAGE SERVICE: 01952 588088

MARCH 2014 - ISSUE 1

1.2m

0.310m

0.4m

0.4m

ELITE RECTANGLE PLANTER (ERP)

PLAN

SIDE ELEVATIONS

TOP ELEVATION

ELITE

RECTANGLE

PLANTER

Elite Planter [ERP] label (A5) 6/3/14 11:36 Page 1

ASSEMBLY INSTRUCTIONS

ELITE RECTANGLE PLANTER

PARTS LIST

HARDWARE

Screws x 4

Short Side x 2

Long Side x 2

TOOLS REQUIRED:

RUBBER MALLET / SCREWDRIVER / SPANNER

Base Section x 1

C

B

A

y

Top Nut x 4

v

Long Bolt x 4

xBase Nut x 4

Washers x 8

w

z

B

C

A

Insert the Base

Section (C) into the

bottom of the

assembled planter

and secure in

position with the

four screws (z)

ASSEMBLY TIP:

The top edges of Side Sections (A) and (B)

are smooth while the

undersides have

nail holes visible.

B

B

C

C

A

A

x

z

z

v

w

y

w

v

w

y

x

w

With the interlocking corners

in position it may be advisable

to use a rubber mallet to

‘gently’ drive the long bolt (y)

through the aligned holes.

Use your Spanner to tighten

the top and bottom nuts (v

and x)

A B

Elite Planter [ERP] label (A5) 6/3/14 11:36 Page 2
