Grandstream Networks GXV3240 User manual

Grandstream Networks, Inc.

126 Brookline Ave, 3rd Floor

Boston, MA 02215. USA

Tel : +1 (617) 566 - 9300

Fax: +1 (617) 249 - 1987

www.grandstream.com

For Warranty and RMA information, please visit www.grandstream.com

GXV3240

IP Multimedia Phone for AndroidTM

Quick Installation Guide

HDMI, the HDMI Logo, and High-Denition

Multimedia Interface are trademarks or registered

trademarks of HDMI Licensing LLC in the United

States and other countries.

*Android is a Registered Trademark of Google, Inc.

Content

English..............................................................................1

简体中文..........................................................................9

Español............................................................................17

Français...........................................................................25

Deutsch...........................................................................33

Italiano............................................................................41

Русскй.............................................................................49

Português........................................................................57

1 2

The GXV3240 is not pre-congured to support or

carry emergency calls to any type of hospital, law

enforcement agency, medical care unit (“Emergency

Service(s)”) or any other kind of Emergency Service.

You must make additional arrangements to access

Emergency Services. It is your responsibility to pur-

chase SIP-compliant Internet telephone service, prop-

erly congure the GXV3240 to use that service, and

periodically test your conguration to conrm that it

works as you expect. If you do not do so, it is your re-

sponsibility to purchase traditional wireless or landline

telephone services to access Emergency Services.

GRANDSTREAM DOES NOT PROVIDE CON-

NECTIONS TO EMERGENCY SERVICES VIA THE

GXV3240. NEITHER GRANDSTREAM NOR ITS

OFFICERS, EMPLOYEES OR AFFILIATES MAY

BE HELD LIABLE FOR ANY CLAIM, DAMAGE, OR

LOSS. YOU HEREBY WAIVE ANY AND ALL SUCH

CLAIMS OR CAUSES OF ACTION ARISING FROM

OR RELATING TO YOUR INABILITY TO USE THE

GXV3240 TO CONTACT EMERGENCY SERVICES,

AND YOUR FAILURE TO MAKE ADDITIONAL AR-

RANGEMENTS TO ACCESS EMERGENCY SER-

VICES IN ACCORDANCE WITH THE IMMEDIATELY

PRECEDING PARAGRAPH.

PACKAGE CONTENTS:

PRECAUTIONS:

WARNING: Please DO NOT power cycle the GXV3240 during system boot

up or rmware upgrade. You may corrupt rmware images and cause the unit to

malfunction.

WARNING: Use only the power adapter included in the GXV3240 package.

Using an alternative non-qualied power adapter may possibly damage the unit.

1 X GXV3240 Main Case 1 X Handset 1 X Phone Cord

1 X Ethernet Cable 1 X 12V Power Adapter 1 X Phone Stand

1 X Quick

Installation Guide

1 X Wall Mount 1 X Screen

Cleaning Cloth

12V

3 4

CONNECTING THE PHONE:

OVERVIEW:

PHONE SETUP:

GXV3240 represents the future in personal IP multimedia communication, featur-

ing Android™ Operating System 4.2 and its vast number of 3rd party applications,

a 4.3” (480x272) capacitive touch screen, a tiltable mega-pixel CMOS sensor,

dual Gigabit network ports, integrated Wi-Fi, PoE and Bluetooth. The GXV3240

delivers superior HD audio & video, leading edge telephony features and integra-

tion of rich Web content with access to the rapidly growing Android™ applications

base and automated provisioning. GXV3240 redenes the desktop communica-

tion experience with a raised level of innovation and integration of state-of-art real

time video conferencing, personalized rich media presentation & delivery, popular

Web and social networking applications and advanced business productivity tools.

1. Attach the wall mount to the slots on the back of the phone;

2. Attach the phone to the wall via the wall mount hole;

3. Pull out the tab rom the handset cradle (see gure below);

4. Rotate the tab and plug it back into the slot with the extension up to hold the

handset while the phone is mounted on the wall.

Installing The Phone (Wall Mount):

1. Connect the handset and main phone case with the phone cord;

2. Connect the LAN port of the phone to the RJ-45 socket of a hub/switch or a rou-

ter (LAN side of the router) using the Ethernet cable;

3. Connect the 12V DC output plug to the power jack on the phone; plug the power

adapter into an electrical outlet. If PoE switch is used in step 2, this step could

be skipped;

4. The LCD will display booting up or rmware upgrading inormation. Beore con-

tinuing, please wait for the main screen display to show up;

5. Using the web conguration interace or rom the menu othe touch screen, you

can urther congure network connection using static IP, DHCP and etc.

HDMI Port

Port

LAN

Port

Handset

Port

Power Headset

Port

SD Card Slot

USB Port

Slots for the wall mount

and phone stand

Tab with extension up

Handset Rest

Tab with extension down

Attach the phone stand to the back of the phone where there is a slot for the

phone stand. Upper part and bottom part are available for two angels.

Installing The Phone (Phone Stand):

EXT

Port

5 6

Tips For Using the Keypad:

Confguring the GXV3240 Using Touch Screen:

Message Waiting

Indicator

Hold

Message

Transfer

Volume

Send

Speaker

Conference

Back

Home

Backspace

Phonebook

Standard

Keypad

PHONE CONFIGURATION:

Confguring the GXV3240 Using Web Browser:

1. Ensure your phone is properly powered up and connected to the Internet;

2. The IP address of the phone will show in the main screen when pressing the

Home button;

3. Type the phone’s IP address in your PC’s browser (see gure in the next page);

4. The default username and password for administrator are “admin” and “admin”.

The default username and password for user are “user” and “123”;

5. In the web GUI, select Account 1/2/3/4/5/6 page to congure Account name, SIP

Server, SIP User ID, Authenticate ID and Authenticate Password to register the

account on the GXV3240.

1. Make sure the phone is properly powered up and in idle screen;

2. Tap on the LCD MENU icon to access GXV3240’s applications and settings;

3. Select Settings->Advanced Settings->Account. Tap on one of the Account to

congure Account name, SIP Server, SIP User ID, SIP Auth ID, SIP Auth Pass-

word to register account on the GXV3240. After successfully registered, the ma-

in screen will be shown as the gure below;

4. Follow the LCD Menu options to congure other settings on the phone. For exa-

mple, to congure static IP on the GXV3240, set up static IP address via LCD

Menu->Settings->Wireless & Network->Ethernet Settings;

5. Please contact your ITSP (Internet Telephony Service Provider) for additional

settings that may be necessary to congure the phone.

Headset

Mute

7 8

The GXV3240 uses GXP2200EXT as the extension module. The extension mod-

ule is an ideal solution for the busy enterprise environment looking to add the

ability to receive and dispatch calls eciently. Each GXP2200EXT extension mod-

ule has 20 programmable buttons, Left and Right buttons, supporting 40 Multiple

Purpose Keys to be congured. GXV3240 supports up to 4 extension modules,

adding 160 fully programmable phone extensions to the phone.

Note: The GXP2200EXT is an additional accessory for the GXV3240. Therefore,

the GXP2200EXT (including extension module accessories for installation) is not

included in the GXV3240 box. For detailed information about the GXP2200EXT,

please refer to the link below:

http://www.grandstream.com/support

Note: For the detailed user manual, please download from:

http://www.grandstream.com/support

Confguring GXV3240 Extension Module:

1. Login the GXV3240 web GUI and congure multiple purpose keys or extension

board 1/2/3/4 under web GUI->Advanced Settings->MPK EXT Settings page;

2. On the GXV3240 extension board (i.e., GXP2200EXT), press LEFT or RIGHT

button to browse all the MPKs’ status in different pages;

3. For more conguration inormation, please reer to the GXV3240 user manual

and the GXP2200EXT user manual.

3. Connect the GXP2200EXT to the GXV3240 via the EXT port using the RJ11-

RJ11 cable provided with the GXP2200EXT;

4. Install the phone stands on the GXV3240 and the GXP2200EXT;

5. Power up the GXV3240. The GXP2200EXT will show the booting up screen

with version information and connecting status;

6. After successfully booting up, the extension board will stay in idle. Press and

hold the LEFT button for 3 seconds to check the version information and status.

Installing GXP2200EXT to the GXV3240:

1. On the back of the GXV3240 and the GXP2200EXT, there are slots for connec-

tor plate. Attach the connector plate between the slots for the GXV3240 and the

GXP2200EXT;

2. Apply the screws provided and securely tighten them in (see gure in the next

page);

CONNECTING GXV3240 EXTENSION MODULE:

GXP2200EXT Package Content:

1 X GXP2200EXT Board 1 X GXP2200EXT Stand 1 X RJ11-RJ11 Cable

1 X Connector Plate 4 X Screws 1 X Quick Installation Guide
