Hawkeye® Pro MicroFlex and Pro Semi-Rigid Borescopes User Guide Hawkeye® Pro MicroFlex and Pro Semi-Rigid Borescopes User Guide
3
6
C-MOUNT
The Hawkeye® Pro MicroFlex is shipped with an adapter to
connect the Pro MicroFlex directly to any video camera with
a C-mount, such as the Sony XC-505.
C-Mount Adapter
To use the C-mount adapter, first
unscrew the eyecup from the
Pro MicroFlex.
Next, push the C-mount adapter onto the end
of the Pro MicroFlex until it slides over the
o-ring and starts to engage the thread. Then
screw it on the rest of the way.
Mounting the Adapter
Now the Pro MicroFlex may be threaded onto a
C-mount video camera as shown below.
Threading onto the C-Mount Camera
C-Mount Camera
Care and Maintenance
• Clean the insertion tube with soapy water, then rinse and dry.
• Clean the glass surfaces in the viewing tip, light guide connector and eyepiece with a
soft cloth or cotton swab and a lens cleaning solution. Isopropyl (rubbing) alcohol or
common household glass cleaners will work as well.
• Clean the borescope body with a damp cloth.
• Do not immerse the body in water – it is not watertight.
When packing the borescope, take care to:
Secure entire scope length in storage cut-out before closing case lid.
CAUTION: Do not let case lid fall on insertion tube!
Warranty
Gradient Lens Corporation warrants the Hawkeye® Pro MicroFlex to be free of defects
in material and workmanship and to perform in accordance with the manufacture’s
specifications when subject to normal use and service for a period of one year from the date
of purchase. Gradient Lens Corporation will either repair or replace components found to be
defective or at variance from the manufacture’s specifications within this time at no cost to the
customer. It shall be the purchaser’s responsibility to return the instrument to the authorized
service center.
This warranty does not cover breakage or failure due to tampering, misuse, neglect, accidents,
improper installation, modification, shipping, or to improper maintenance, service and cleaning
procedures. This warranty is also void if the instrument is not used in accordance with the
manufacture’s recommendations or if required service is performed by anyone other than a
Gradient Lens Corporation authorized agent. No other express or implied warranty is given.
Service
