Instructions - Parts List

Viscount®4-Ball Pumps 3A0537M

Hydraulic-powered pumps for low

pressure, high volume circulation of

finishing materials.

Do not use for flushing or purging

lines with caustics, acids, abrasive

line strippers, and other similar

fluids. For professional use only.

See page 3 for model information, including

maximum working pressure and approvals.

Important Safety Instructions

Read all warnings and instructions in

this manual. Save these instructions.

TI15609a

Viscount II

Pump with

4000cc 4-Ball

Lower

II 2 G c IIB T3

Related Manuals

23A0537M

Contents

Related Manuals . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Pumps with 3000cc or 4000cc 4-Ball Lowers . . . 3

Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Stand Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Wall Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Plumbing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Flush Before Using Equipment . . . . . . . . . . . . . . 7

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Pressure Relief Procedure . . . . . . . . . . . . . . . . 10

Prime the Pump . . . . . . . . . . . . . . . . . . . . . . . . 10

Stop the Pump at the Bottom of Its Stroke . . . . 10

Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Preventive Maintenance Schedule . . . . . . . . . . 11

Flushing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Mix Tank Volume . . . . . . . . . . . . . . . . . . . . . . . . 11

Hydraulic Power Supply Check . . . . . . . . . . . . . 11

Stall Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Changing the TSL . . . . . . . . . . . . . . . . . . . . . . . 12

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Reassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Reassemble the Coupling Adapter and

Tie Rods to the Motor . . . . . . . . . . . . . . . . . 15

Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Viscount II Pumps with 3000cc or

4000 cc 4-Ball Lowers . . . . . . . . . . . . . . . . . 16

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Motor Mounting Hole Diagram . . . . . . . . . . . . . . . 18

Mounting Stand Hole Layout . . . . . . . . . . . . . . . . 18

255143 Wall Mount Bracket . . . . . . . . . . . . . . . . . . 19

Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

3000 and 4000cc Pumps with

Viscount II Motor . . . . . . . . . . . . . . . . . . . . . 20

Performance Charts . . . . . . . . . . . . . . . . . . . . . . . . 20

Graco Standard Warranty . . . . . . . . . . . . . . . . . . . 22

Graco Information . . . . . . . . . . . . . . . . . . . . . . . . . 22

Related Manuals

Part No. Description

308048 Viscount II Hydraulic Motor manual

3A0540 4-Ball Lower manual (3000cc and 4000cc)

Models

3A0537M 3

Models

Pumps with 3000cc or 4000cc 4-Ball Lowers

Model No. Series

Maximum Pump

Working Pressure

psi (MPa, bar) Lower Size Motor

Connection

Style Material

Rod

Material

Cylinder

Material

24E337 A 400 (2.8, 28.0) 3000cc Viscount II npt cst Chromex Chrome

24E338 A 400 (2.8, 28.0) 3000cc Viscount II npt sst Chromex Chrome

24E339 A 400 (2.8, 28.0) 3000cc Viscount II npt sst Ultralife Ultralife

24E340 A300 (2.1, 21.0) 4000cc Viscount II npt cst Chromex Chrome

24E341 A300 (2.1, 21.0) 4000cc Viscount II npt sst Chromex Chrome

24E342 A300 (2.1, 21.0) 4000cc Viscount II npt sst Ultralife Ultralife

Warnings

43A0537M

Warnings

The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-

tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When

these symbols appear in the body of this manual, refer back to these warnings. Product-specific hazard symbols and

warnings not covered in this section may appear throughout the body of this manual where applicable.

WARNING

FIRE AND EXPLOSION HAZARD

Flammable fumes, such as solvent and paint fumes, in the work area can ignite or explode. To help prevent

fire and explosion:

• Use equipment only in a well-ventilated area.

• Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop

cloths (potential static arc).

• Keep the work area free of debris, including solvent, rags, and gasoline.

• Do not plug or unplug power cords, or turn power or light switches on or off when flammable fumes are

present.

• Ground all equipment in the work area. See Grounding instructions.

• Use only grounded hoses.

• Hold the gun firmly to the side of a grounded pail when triggering into a pail.

• If there is static sparking or you feel a shock, stop operation immediately. Do not use the equipment

until you identify and correct the problem.

• Keep a working fire extinguisher in the work area.

Static charge may build up on plastic parts during cleaning and could discharge and ignite flammable

vapors. To help prevent fire and explosion:

• Clean plastic parts only in a well-ventilated area.

• Do not clean with a dry cloth.

• Do not operate electrostatic guns in the equipment work area.

PRESSURIZED EQUIPMENT HAZARD

Fluid from the gun/dispense valve, leaks, or ruptured components can splash in the eyes or on skin and

cause serious injury.

• Follow the Pressure Relief Procedure when you stop spraying and before cleaning, checking, or ser-

vicing the equipment.

• Tighten all fluid connections before operating the equipment.

• Check hoses, tubes, and couplings daily. Replace worn or damaged parts immediately.

TOXIC FLUID OR FUMES HAZARD

Toxic fluids or fumes can cause serious injury or death if splashed in the eyes or on skin, inhaled, or swal-

lowed.

• Read the Safety Data Sheet (SDS) to know the specific hazards of the fluids you are using.

• Store hazardous fluid in approved containers, and dispose of it according to applicable guidelines.

Warnings

3A0537M 5

PERSONAL PROTECTIVE EQUIPMENT

You must wear appropriate protective equipment when operating, servicing, or when in the operating area

of the equipment to help protect you from serious injury, including eye injury, hearing loss, inhalation of

toxic fumes, and burns. This equipment includes but is not limited to:

• Protective eyewear, and hearing protection.

• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer.

EQUIPMENT MISUSE HAZARD

Misuse can cause death or serious injury.

• Do not operate the unit when fatigued or under the influence of drugs or alcohol.

• Do not exceed the maximum working pressure or temperature rating of the lowest rated system compo-

nent. See Technical Specifications in all equipment manuals.

• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Specifications

in all equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete information

about your material, request a Safety Data Sheet (SDS) from your distributor or retailer.

• Do not leave the work area while equipment is energized or under pressure. Turn off all equipment and

follow the Pressure Relief Procedure when equipment is not in use.

• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine manufac-

turer’s replacement parts only.

• Do not alter or modify equipment.

• Use equipment only for its intended purpose. Call your distributor for information.

• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.

• Do not kink or over bend hoses or use hoses to pull equipment.

• Keep children and animals away from work area.

• Comply with all applicable safety regulations.

MOVING PARTS HAZARD

Moving parts can pinch, cut, or amputate fingers and other body parts.

• Keep clear of moving parts.

• Do not operate equipment with protective guards or covers removed.

• Pressurized equipment can start without warning. Before checking, moving, or servicing equipment, fol-

low the Pressure Relief Procedure and disconnect all power sources.

WARNING

Installation

63A0537M

Installation

Grounding

Pump: use a ground wire and clamp. See FIG. 1.

Loosen the locknut (W) of the grounding lug (Z). Insert

one end of the wire (Y) in the ground lug and tighten the

locknut securely. Connect the ground clamp to a true

earth ground. Order Part No. 237569, Ground Wire and

Clamp.

Air and fluid hoses: use only electrically conductive

hoses with a maximum of 500 ft. (150 m) combined

hose length to ensure grounding continuity. Check the

electrical resistance of hoses. If total resistance to

ground exceeds 25 megohms, replace hose immedi-

ately.

Hydraulic power supply: follow manufacturer’s recom-

mendations.

Surge tank: use a ground wire and clamp.

Dispense valve: ground through a connection to a

properly grounded fluid hose and pump.

Fluid supply container: follow local code.

Object being sprayed: follow local code.

Solvent pails used when flushing: follow local code.

Use only conductive metal pails, placed on a grounded

surface. Do not place the pail on a nonconductive sur-

face, such as paper or cardboard, which interrupts

grounding continuity.

To maintain grounding continuity when flushing or

relieving pressure: hold metal part of the spray gun

firmly to the side of a grounded metal pail, then trigger

the gun.

The equipment must be grounded. Grounding reduces

the risk of static and electric shock by providing an

escape wire for the electrical current due to static build

up or in the event of a short circuit.

FIG. 1 Ground Wire

TI15854a

Installation

3A0537M 7

Stand Mount

Mount the pump in the accessory pump stand (B). Use

Part No. 218742 Stand for 3000 and 4000cc Pumps

(see FIG. 2, page 9).

See Mounting Stand Hole Layout on page 18. Secure

the stand to the floor with M19 (5/8 in.) bolts which

engage at least 152 mm (6 in.) into the concrete floor to

prevent the pump from tipping.

Wall Mount

1. Ensure the wall is strong enough to support the

weight of the pump assembly and accessories, fluid,

hoses, and stress caused during pump operation.

2. Ensure that the mounting location has sufficient

clearance for easy operator access.

3. Position the wall bracket at a convenient height,

ensuring that there is sufficient clearance for the

fluid suction line and for servicing the lower.

4. Drill four 7/16 in. (11 mm) holes using the bracket as

a template. Use any of the three mounting hole

groupings in the bracket. See 255143 Wall Mount

Bracket, page 19.

5. Bolt the bracket securely to the wall using bolts and

washers designed to hold in the wall’s construction.

6. Attach the pump assembly to the mounting bracket.

7. Connect air and fluid hoses.

Plumbing

Install a fluid shutoff valve (D) between the mix tank (A)

and the pump.

When using a stainless steel pump, use stainless steel

plumbing to maintain a corrosion-resistant system.

Flush Before Using Equipment

The equipment was tested with lightweight oil, which is

left in the fluid passages to protect parts. To avoid con-

taminating your fluid with oil, flush the equipment with a

compatible solvent before using the equipment. See

Flushing, page 11.

Installation

83A0537M

Accessories

Install the following accessories in the order shown in

FIG. 2, using adapters as necessary.

Hydraulic Power Supply

Be sure the power supply can provide sufficient power to

the motor. Be sure the power supply is equipped with a

suction filter to the hydraulic pump.

Hydraulic Supply Line

• For Viscount I Plus motors, the hydraulic inlet on the

motor is 3/4 in., 37° flare. Use a minimum 1/2 in. (13

mm) ID hydraulic supply line (L).

• For Viscount II motors, use a minimum 13 mm (1/2

in.) ID supply line (L). The motor has a 3/4 npt(f)

hydraulic oil supply fitting.

•Supply line shutoff valve (S): isolates the motor

when servicing the system.

•Hydraulic fluid pressure gauge (P): monitors the

hydraulic oil pressure to the motor to avoid over-

pressurizing the motor or lower.

•Pressure- and temperature-compensated flow

control valve (T): prevents the motor from running

too fast, which can damage it.

•Pressure reducing valve (N), which has a drain

line (M) running to the return line (K): controls the

hydraulic pressure to the motor.

Hydraulic Return Line

• For Viscount I Plus motors, the hydraulic outlet on

the motor is 7/8 in., 37° flare. Use a minimum 5/8 in.

(16 mm) ID hydraulic return line (K).

• For Viscount II motors, use a minimum 22 mm (7/8

in.) ID return line (K). The motor has a 1 in. npt(f)

hydraulic oil return fitting.

•Return line shutoff valve (R): isolates the motor

when servicing the system.

•Return fluid filter (J): removes residue from the

hydraulic fluid to help keep the system running

smoothly (10 micron size).

Fluid Line

For typical installation, see FIG. 2 on page 9.

•Fluid filter: with a 60 mesh (250 micron) stainless

steel element to filter particles from the fluid as it

leaves the pump.

•Fluid drain valve (U): required in your system, to

relieve fluid pressure in the hose and gun.

•Fluid shutoff valve (D): shuts off fluid flow.

NOTICE

The hydraulic power supply must be kept clean at all

times to avoid damage to the motor and hydraulic

power supply.

1. Blow out hydraulic lines with air and flush thor-

oughly before connection to the motor.

2. Plug hydraulic inlets, outlets, and line ends when

disconnecting them for any reason.

NOTICE

To avoid damage to the pump, never use the return

line shutoff valve to control the hydraulic flow. Do not

install any flow control devices on the hydraulic return

line.

Installation

3A0537M 9

Key:

AMixTank

B 218742 Pump Stand

C Fluid Supply Line; 1-1/2 in. (38 mm) minimum diameter

D Fluid Shutoff Valve

E Fluid Line; 1 in. (25 mm) minimum diameter

F Surge Tank Stand

G Surge Tank

J 10 Micron Return Filter

K Hydraulic Return Line

L Hydraulic Supply Line

M Drain Line

N Pressure Reducing Valve

P Hydraulic Pressure Gauge

R Return Line Shutoff Valve

S Supply Line Shutoff Valve

T Flow Control Valve

U Fluid Drain Valve (required)

Y Ground Wire (required; see page 6 for installation)

FIG. 2. Typical Installation for 3000 and 4000cc Pumps (Viscount II Motor Shown)

NPS

TI15856a

Operation

10 3A0537M

Operation

Pressure Relief Procedure

1. Shut off the hydraulic supply line valve (S) first, then

the return line valve (R).

2. Open the dispensing valve, if used.

3. Open all fluid drain valves (U) in the system, having

a waste container ready to catch drainage. Leave

drain valve(s) open until you are ready to pump

again.

Prime the Pump

1. Fill the TSL reservoir to the Maximum fill line with

Throat Seal Liquid (TSL). See FIG. 3 on page 12.

NOTE: During operation the TSL level in the reservoir

will fluctuate slightly at pump changeover.

2. Close the flow control valve (T) by turning knob

counterclockwise reducing pressure to zero. Close

the supply line shutoff valve (S) and the return line

shutoff valve (R). Also verify that all drain valves (U)

are closed.

3. Check that all fittings throughout system are tight-

ened securely.

4. Start the hydraulic power supply.

5. Open the return line shutoff valve (R), then the sup-

ply line shutoff valve (S). Slowly turn the flow control

valve (T) clockwise, increasing pressure until pump

starts.

6. Cycle pump slowly until all air is pushed out and

pump and hoses are fully primed.

7. Verify that pump actuations are priming the pump

wet-cup. If not, confirm that the TSL pump piston is

being depressed at bottom changeover, and that

reservoir check valves are not stuck closed.

8. Close the fluid shutoff valve (D) downstream of the

pump. The pump should stall against pressure.

NOTE: In a circulation system, the pump operates con-

tinuously until the power supply is shut off. In a

direct-supply system, the pump starts when the dis-

pense valve is opened, and stops when the dispense

valve is closed.

Stop the Pump at the Bottom of

Its Stroke

Relieve the pressure when you stop the pump for any

reason. Stop the pump on the downstroke, before the

motor changes over.

Shutdown

Follow the Pressure Relief Procedure, page 10.

Always flush the pump before the fluid dries on the dis-

placement rod. See Flushing on page 11.

NOTICE

When shutting down the hydraulic system, always

shut off the hydraulic supply line shutoff valve (S) first,

and then the return line shutoff valve (R) to prevent

overpressurizing the motor or its seals. When starting

the hydraulic system, open the return line shutoff

valve first.

NOTICE

Failure to stop the pump at the bottom of its stroke

allows fluid to dry on the piston rod, which can dam-

age the throat packings and the TSL pump piston seal

when the pump is restarted.

This manual suits for next models

Table of contents

Other Graco Water Pump manuals

Graco

Graco 24G546 User manual

Graco

Graco SaniForce 1040 Manual

Graco

Graco HYDRA-SPRAY President A Series Operation manual

Graco

Graco Husky 2200 Instruction Manual

Graco

Graco Dyna-Star 77X100 Use and care manual

Graco

Graco 5:1 Monark 952-793 Operation manual

Graco

Graco 257100 Instruction Manual

Graco

Graco 1030 Operation manual

Graco

Graco Husky 2200 User manual

Graco

Graco 226040 Operation manual

Graco

Graco 231161 Operation manual

Graco

Graco SaniForce Instruction Manual

Graco

Graco fire-ball 425 Operation manual

Graco

Graco HUSKY 1050P User manual

Graco

Graco ChemSafe 515 PT Series Operation manual

Graco

Graco Dura-Flo 600 Parts list manual

Graco

Graco Merkur W10CAS User manual

Graco

Graco 24F448 Operation manual

Graco

Graco ToughTek MP-Series Instruction Manual

Graco

Graco Husky 205 Operation manual

Graco

Graco ChemSafe 1590 Parts list manual

Graco

Graco Husky 1050HP Instruction Manual

Graco

Graco Fire-Ball 237526 Datasheet

Graco

Graco President 17E222 Operation manual

Popular Water Pump manuals by other brands

Neptun

Neptun NPHW 5500 operating instructions

Sensidyne

Sensidyne Gilian BDX-II Operation & service manual

Draper

Draper 47808 instructions

Trolla

Trolla 12820 manual

Sunfab

Sunfab SVH Series installation guide

WilTec

WilTec 50740 Operation manual

Fieldmann

Fieldmann FVC 5015 EK user manual

Everbilt

Everbilt EFSUB5-122HD Use and care guide

esotec

esotec 101018 operating manual

moyno

moyno 2000 CC Service manual

Becker

Becker BASIC VASF 2.80/1-0.AC230 operating instructions

Sykes AmeriPumps

Sykes AmeriPumps GP100M Operation and maintenance instructions

DUROMAX

DUROMAX XP WX Series user manual

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 operating instructions

Franklin Electric

Franklin Electric IPS Installation & operation manual

Xylem

Xylem e-1532 Series instruction manual

Milton Roy

Milton Roy PRIMEROYAL instruction manual

STA-RITE

STA-RITE ST33APP owner's manual
