Graco TURBOBOOSTER GROW RightGuide User manual
Read This Instruction Manual
featuring RightGuide™Seat Belt Trainer
FAILURE TO PROPERLY USE THIS
CHILD RESTRAINT INCREASES THE
RISK OF SERIOUS INJURY OR DEATH
IN A SUDDEN STOP OR CRASH.
Do not install or use this child restraint
until you read and understand the
instructions in this manual.
NWL0000792167A 7/18 www.gracobaby.com
TURBOBOOSTER®GROW™
2
1-A Quick Guide to Your Manual
1-B Welcome to the Graco Family
1-C Before You Begin
Register This Car Seat
If You Need Help
Certification
Car Seat’s Useful Life
Vehicle Seat Protection
Warm Weather Use
1-D Safety Warnings
1 Important Pages 5-17
2 Features Pages 18-23
2-A Car Seat Features
3
3 Booster Pages 24-34
4-A Securing Child in Highback Booster
4-B Securing Child in Backless Booster
4-C Securing Child in RightGuide™ Seat Belt Trainer
4 Securing Child Pages 35-50
6 Accessories Page 53
3-A Booster Use
3-B Install Highback Booster
3-C Install Backless Booster
3-D Install RightGuide™ Seat Belt Trainer
5 Reinstall RightGuide™ Seat Belt Trainer to Booster Pages 51-52
4
7-A How to Remove Lower Anchor Connectors
7-B Choosing Vehicle Seat Location
7-C Unsafe Vehicle Seat Location
7-D Vehicle Seat Belts
8-A Cleaning Seat Pad
8-B Cleaning Lower Anchor Straps
7 Vehicle Information Pages 54-58
8 Care & Cleaning Pages 59-67
5
1-A Quick Guide to Your Manual
Car Seat Assembly (On Select Models)
Adult Assembly Required
1. Attach Headrest to Seat Back
Squeeze the adjustment button and slide the headrest into the
seat back.
CHECK to make sure the two pieces are securely snapped
together by pulling on them.
This car seat is for children:
Highback Booster:
40-100 lb (18.1-45 kg) 43-57 in. (110.1-145 cm) at least 4 years old
Backless Booster:
40-110 lb (18.1-50 kg) 43-57 in. (110.1-145 cm) at least 4 years old
RightGuide™ Seat Belt Trainer:
50-120 lb (22.5-54 kg) 43-60 in. (110.1-152 cm) at least 5 years old
6
2. Headrest Seat Pad
With the headrest all the way up, insert the pad from the
headrest underneath the seat back pad.
3. Attach Seat Back to Base
The “U”-shaped hooks on bottom
of the seat back will interlock with
bars on the base. Make sure that no
part of the seat pad interferes when
attaching the backrest to the base.
4. Raise Seat Back
Once the seat back is securely attached to the base, push
backrest up.
CLICK!
7
5. Attach Cup Holder and Storage
Compartment
Align locking tabs with the holes in the base.
Push down to lock them in.
Circular cup holder goes on the left and the
oval storage compartment goes on the right
as shown.
Assembly Complete
Your Graco booster seat is now ready to use.
CLICK!CLICK!
8
Get to Know Your Car Seat
What Seating Location Should I Use?
Review section 2-A to see all of the features of this booster seat.
The best seating location for this booster seat is one that:
• Is recommended by your vehicle owner’s manual, and
• Results in a secure installation of this booster seat.
Some vehicles have specific requirements for where the booster seat can be installed, so be sure to
check your vehicle owner’s manual for available seating positions, if any. For example, sometimes the
center rear seat has a lap belt only vehicle seat belt, which cannot be used with this booster seat.
Review section 7-B, 7-C, 7-D of this manual AND your vehicle owner’s manual.
According to accident statistics, the safest place for your
child in any vehicle is the back seat. The center of the back
seat can be the safest during a possible side impact.
9
When Installing As a Booster
Vehicle Seat Belt
There is one type of vehicle seat belt that can be used: Lap/
Shoulder Seat Belt.
Review section 3 of this manual AND your vehicle owner’s
manual.
Lower Anchor System
The lower anchor system consists of lower anchor bars, which are built-in
to your vehicle, and connectors that are built-in your car seat.
Review section 3 of this manual AND your vehicle owner’s manual.
Using The Car Seat Correctly
To make sure your child is secured properly, review section 3 and 4 to fit your child.
10
Use Lap/Shoulder Belt Only
Review section 3
Booster Installation
Highback Backless
Position Lap Belt
Be sure the lap portion of the vehicle seat belt goes in front of
both armrests and the shoulder belt goes under the armrest
on the buckle side.
Review section 3
Position Lap Belt on RightGuide™ Seat Belt Trainer
Be sure the lap portion of the vehicle seat belt goes through
both seat belt guides and the shoulder belt goes through the
seat belt guide on the buckle side.
Review section 3 RightGuide™
Seat Belt Trainer
