GoPro ROCKY POINT User manual

USER MANUAL

ROCKY POINT

2 3

/ Join the GoPro Movement

twitter.com/GoPro

facebook.com/GoPro youtube.com/GoPro

instagram.com/GoPro

To download this user manual in a diﬀerent language, visit gopro.com/support.

Pour télécharger ce manuel de l’utilisateur dans une autre langue, rendez-vous

sur gopro.com/support.

Wenn Sie dieses Benutzerhandbuch in einer anderen Sprache herunterladen

möchten, besuchen Sie gopro.com/support.

Per scaricare questo manuale utente in un’altra lingua, visita gopro.com/support.

Para descargar este manual de usuario en otro idioma, visite gopro.com/support.

Para baixar este manual do usuário em outro idioma, acesse gopro.com/support.

このユーザーマニュアルの他言語版をダウンロードするには、

gopro.com/supportにアクセスしてください。 

若要下載其他語言版本的使用說明書，請前往：  gopro.com/support。

如需下载本用户手册的其他语言版本，请访问gopro.com/support。

Чтобы загрузить это руководство пользователя на другом языке, посетите

страницу gopro.com/support.

4 5

The Basics

Getting Started

Capturing Video and Time Lapse Photos

Accessing Camera Settings

Camera Icons

Camera Modes and Settings

Video Mode

Photo Mode

Multi-Shot Mode

Setup Mode

Protune™

Transferring Files to a Computer

Playing Back Video and Photos

Important Messages

The Frames

Using the Mounts

Battery

Troubleshooting

Customer Support

Regulatory Information

/ Table of Contents / Table of Contents

6 7

/ The Basics

1. Camera Status Screen

2. Shutter/Select Button [ ]

3. Microphone

4. Camera Status Light (red) /

Wireless Status Light (blue)

5. Micro USB Port

6. microSD Card Slot

7. Camera Status/Wireless

Button

/ Getting Started

CHARGING THE BATTERY

The integrated battery comes partially charged. No damage occurs to

the camera or battery if used before being fully charged.

To Charge the Battery:

1. Open the side door.2. Charge the battery using the

included USB cable.

For #3, show

dots like in ﬁrst

drawing, but in

square pattern

(3 across,

3 down) Note: The battery cannot be removed from the camera.

8 9

/ Getting Started

The camera status lights (red) turn on during charging and turn

oﬀ when charging is complete. When charging the camera with a

computer, be sure that the computer is connected to a power source.

If the camera status lights do not turn on to indicate charging, use a

diﬀerent USB port.

NOTICE: Using a wall charger other than a GoPro Wall Charger can

damage the battery. Only use USB charging adapters marked 5V 1A.

If you do not know the voltage and amperage of your charger, use the

included USB cable to charge the camera from your computer.

For more battery information, see Battery (page 89).

WARNING: Use caution when using your GoPro as part of your

active lifestyle. Always be aware of your surroundings to avoid

injury to yourself and others. Abide by all local laws when using

your GoPro and related mounts and accessories, including all

privacy laws, which may restrict recording in certain areas.

/ Getting Started

10 11

/ Getting Started

INSERTING + REMOVING MEMORY CARDS

Use brand name memory cards (sold separately) that meet these

requirements:

• microSD, microSDHC, or

microSDXC

• Class 10 or UHS-1 rating

• Capacity up to 64GB

For a list of the recommended

microSD cards, visit

gopro.com/support.

/ Getting Started

NOTICE: Use care when handling memory cards. Avoid liquids, dust,

and debris. As a precaution, power oﬀ the camera before inserting or

removing the card. Check manufacturer guidelines regarding use in

acceptable temperature ranges.

CAMERA SOFTWARE UPDATES

To get the latest features and best performance from your

HERO4 Session camera, make sure you are using the most current

camera soware. You can update your camera soware with the

GoPro App, GoPro Studio, or at gopro.com/getstarted.

12 13

/ Getting Started

POWERING ON + OFF

HERO4 Session automatically powers on when

you short press the Shutter/Select button [ ] to

begin capturing video or Time Lapse photos. When

you press the Shutter/Select button [ ] again to

stop recording, the camera automatically powers

oﬀ to conserve battery power.

PRO TIP: When carrying your camera in a bag or pocket, place the

camera upside down in a frame with the Shutter/Select button [ ]

covered to prevent the camera from accidentally powering on.

/ Getting Started

DISPLAYING THE CAMERA STATUS

Short press the Camera Status/Wireless button. The status screen

cycles through the information below, then automatically turns oﬀ.

1. Capture Mode/Soware Version

2. Available Memory/

Capture Mode Settings

3. Wireless (when on)

4. Battery Status

5. Wireless Connection

Conﬁrmation

6. Current Wireless Option

7. Additional Wireless Options

Add “7” here

14 15

/ Getting Started

GEAR CHECK

Follow these guidelines to get the best performance from your

camera:

☑ The camera is waterproof to 30’ (10m)—no housing needed.

Ensure that the side door is closed before using the camera in or

around water, dirt, or sand.

☑ Before opening the side door, be sure the camera is free of water

or debris.

☑ If sand or debris hardens around the side door, soak the camera

in warm tap water for 15 minutes and then rinse thoroughly to

remove the debris before opening the door.

☑ For best audio performance, shake the camera to remove water

and debris from the microphone holes. (Blowing on the mic holes

does not remove water and debris.)

☑ Aer every use in salt water, rinse the camera with fresh water,

and dry with a so cloth.

☑ If the camera lens becomes foggy, let it sit until it dries.

PRO TIP: During water activities, tether your camera for added

security and use a Floaty to keep your camera aﬂoat (sold separately).

For more information, visit gopro.com.

/ Getting Started

16 17

When your camera is not connected to the remote (sold separately)

or the GoPro App, two capture modes are available: Video and Time

Lapse. To access more modes or change camera settings, see

Accessing Camera Settings (page 20).

CAPTURING VIDEO

The default video resolution is 1080p48 SuperView.

To Start Recording Video:

Short press the Shutter/Select button [ ]. Your camera

automatically powers on, emits three beeps, and begins recording

video. The camera status lights blink while the camera is recording.

/ Capturing Video and Time Lapse Photos / Capturing Video and Time Lapse Photos

If the memory card is full or the battery is out of power, your camera

automatically stops recording and saves the video before powering

oﬀ.

To Stop Recording:

Short press the Shutter/Select button [ ]. The camera

automatically stops recording (indicated by one beep), saves the ﬁle

(three beeps), and then powers oﬀ (seven beeps).

18 19

/ Capturing Video and Time Lapse Photos

Show rear 3/4 view with arrow pointing

to Wireless button (back bottom of

camera), not Shutter button

/ Capturing Video and Time Lapse Photos

HILIGHT TAGGING

You can mark speciﬁc moments in your video as they happen with

HiLight Tags. HiLight Tags make it easy to ﬁnd the best moments to

share.

Note: HiLight Tags are visible during playback on the GoPro App or in GoPro Studio.

To Add HiLight Tags During Recording:

Short press the Camera Status/Wireless button.

PRO TIP: You can also add HiLight Tags during

recording with the GoPro App or the Smart Remote.

CAPTURING TIME LAPSE PHOTOS

The default interval for Time Lapse photos is 0.5 second.

To Start Capturing Time Lapse Photos:

Press and hold the Shutter/Select button [ ] for two seconds until

the Time Lapse photo icon [ ] appears on the camera status

screen. Your camera automatically powers on, emits two beeps, and

begins capturing Time Lapse photos. The camera status lights blink

while the camera is capturing photos.

To Stop Recording:

Short press the Shutter/Select button [ ]. The camera

automatically stops recording (indicated by one beep), saves the ﬁle

(three beeps), and then powers oﬀ (seven beeps).
