GoPro Hero3plus Black Edition User manual

User ManUal

2 3

table of contents

Join the GoPro party at facebook.com/gopro to see what

other GoPro owners are capturing and sharing. Share your

footage and be a part of the GoPro movement!

Accessories 4

Mounts + Accessories 5

HERO3 Features 6

Camera LCD Status Screen 8

Camera User Interface Flow Chart 9

Soware Updates 10

Basics 10

Camera Modes 13

Camera Settings 20

Delete 26

Set Up 28

Wireless Controls 36

Storage/SD Cards 38

System Requirements 39

Transferring Files 40

Playback 41

Battery Life 43

Important Warning Messages 45

Camera Assembly 46

Customer Support 52

4 5

HERO3 ACCESSORIES

Wrist Housing

Replacement Housing

Rechargeable Li-Ion Battery

Lens Replacement Kit

Caps + Doors

32GB/16GB microSD™

More HERO3 accessories available at gopro.com

PREMIUM ACCESSORIES

LCD Touch BacPac™

Battery BacPac™

Wi-Fi Remote™

The Frame Mount

(HERO3 accessory)

MOUNTS + ACCESSORIES

Helmet Front

Mount

Chest Mount

Harness

Handlebar/Seatpost/

Pole Mount Surfboard Mounts

Floaty Backdoor Head Strap Suction Cup Mount Vented Helmet

Strap

Roll Bar Mount Tripod Mount Anti-Fog Inserts Grab Bag of

Mounts

Curved + Flat

Adhesive Mounts Side Mount Camera Tethers Wi-Fi Remote

Mounting Kit

see More at gopro.comwear it. MoUnt it. love it.

6 7

Hero3 featUresHero3 featUres

1. Status Indicator Lights (Red)

2. SHUTTER/SELECT Button

3. LCD Status Screen

4. Wi-Fi Indicator Light (Blue)

5. POWER/MODE Button

6. Micro HDMI Port

(Cable not included)

7. microSDTM Card Slot

(SD card not included)

8. mini-USB Port

(Supports Composite A/C

cable/3.5mm stereo mic adapter,

not included)

9. HERO Port

10. Battery Door

11. Wi-Fi ON/OFF Button

12. Audio Alert

8 9

caMera lcd statUs screen caMera User interface flow cHart

MODES

CAMERA SETTINGS

SET UP

WI-FI

The LCD screen displays the following information about HERO3 modes and

settings:

1. Camera Modes/FOV (Field of View)

2. Capture Setting Modes (not shown)

3. Resolution/FPS (Frames Per Second)

4. Time Interval Settings: (not shown)

5. Counter

6. Time/Storage/Files

7. Battery Life

Note: The icons displayed above will vary depending on what mode your camera is in. *Note: White Balance only appears in your camera display if Protune mode is

turned ON. Playback only appears if Playback is activated.

10 11

UsinG YoUr Hero3: basics

GETTING STARTED

Before using your HERO3 for the ﬁrst time:

1. Insert a microSD™, microSDHC™ or microSDXC™ card into the card

slot with label facing forward, narrowest part of the card ﬁrst.

Speed Class 4 or higher cards are recommended. When using 0.5 second Time

Lapse, a Speed Class Rating 10 is required.

2. Place battery into the camera.

3. Charge battery. The included lithium-ion battery comes partially charged. To

charge, connect the included USB cable to camera and connect the other end

of the cable to a power source such as a computer, GoPro Wall Charger or

GoPro Auto Charger. No damage will occur to the camera or battery if used

prior to a full charge.

PRO

TIP:

Status Indicator Lights when camera is OFF and

charging, show:

• Status Indicator Lights are ON when charging.

• Status Indicator Lights are OFF when charging is complete.

▶See BATTERY LIFE for more information.

▶See PROTUNE for more information.

software UPdates

GoPro releases product updates through soware updates. Check

to see if any updates are available for your camera or other GoPro

products. Visit: gopro.com/update.

UsinG YoUr Hero3: basics

CAMERA DEFAULT SETTINGS

The HERO3 White Edition camera powers up with the following default settings:

Video Resolution 1080p30fps

Photo Resolution 5 Megapixels (MP)

Photo Burst 3 photos in 1 second

Time Lapse 0.5 seconds

Wi-Fi OFF

PRO

TIP:

Want to change your VIDEO and PHOTO settings?

▶See SETTINGS MENU to make changes.

12 13

POWERING ON AND OFF

To power ON:

Press and release . The red Status Indicator Lights ﬂash three times and

the Sound Indicator emits three beeps.

To power OFF:

Press for two seconds, then release. The red Status Indicator Lights ﬂash

several times and the Sound Indicator emits seven beeps.

PRO

TIP:

Want to turn your HERO3 into a “one-button” camera that

automatically starts recording Photos or Videos once it

turns ON? Set the camera to ONE BUTTON mode.

▶See ONE BUTTON mode for more information.

UsinG YoUr Hero3: basics

OVERVIEW

The HERO3 features several camera modes. To cycle through the modes, press .

The modes will appear in the following order:

VIDEO

Record Video


Capture single Photo

PHOTO BURST

Capture Burst photos

TIME LAPSE

Capture Time Lapse photos

PLAYBACK

Appears only if the camera is plugged into a TV/HDTV.

PLAYBACK allows you to play Photos and Videos

on a TV/HDTV (via optional Micro HDMI cable or A/V

composite cable).

PRO

TIP:

Use PHOTO BURST to capture fast moving subjects.

▶See PLAYBACK for more information.

UsinG YoUr Hero3: caMera Modes

14 15

UsinG YoUr Hero3: caMera Modes

VIDEO

To record Video, verify the camera is in Video mode. If the Video icon

your camera’s LCD screen

is not showing, press repeatedly until it appears.

To start recording:

Press and release . The camera will emit one beep and the red Status

Indicator Lights will flash while recording.

To stop recording:

Press and release . The red Status Indicator Lights ﬂash three times and the

camera emits three beeps to indicate recording has stopped.

The HERO3 automatically stops recording when the memory card is full or the

battery is out of power. Your video will be saved before the camera powers oﬀ.

▶See VIDEO mode for instructions on how to change resolution settings.

UsinG YoUr Hero3: caMera Modes


To capture a Photo, verify the camera is in Photo mode. If the Photo icon on

your camera’s LCD is not showing, press repeatedly until it appears.

To take a photo:

Press and release . The camera beeps two times and the red Status

Indicator Lights ﬂash.

▶See PHOTO modes for instructions on how to change resolution settings and

other Photo features.

16 17

UsinG YoUr Hero3: caMera Modes

PHOTO BURST

In Photo Burst mode, your camera takes multiple photos in short time intervals—

3 photos/1 second.

To capture a Photo Burst series, verify the camera is in Photo Burst mode. If the

Photo Burst icon on your camera’s LCD screen is not showing, press

repeatedly until it appears.

To take a Photo Burst series:

Press and release . The red Status Indicator Lights ﬂash and the camera

beeps multiple times.

PRO

TIP:

Sometimes 30 photos/1 second is too fast. Try a slower

Burst setting to better match the action.

▶See PHOTO BURST for instructions on how to change the interval settings.

UsinG YoUr Hero3: caMera Modes

TIME LAPSE

Time Lapse mode captures a series of photos at 0.5, 1, 2, 5, 10, 30 or 60 second

intervals. When using the 0.5 seconds setting, an SD card with a Speed Class 10

Rating is required.

To capture a Time Lapse series, verify the camera is in Time Lapse mode. If the

Time Lapse icon is not showing on your camera’s LCD screen, press

repeatedly until it appears.

To take Time Lapse:

Press and release . The camera initiates countdown and the red Status Indicator

Lights ﬂash each time a Photo is taken.

To stop Time Lapse:

Press and release . The red

Status

Indicator Lights ﬂash three times and the

camera emits three beeps to indicate that Time Lapse has stopped.

▶See TIME LAPSE for instructions on how to change the interval settings.

18 19

UsinG YoUr Hero3: caMera Modes

SETTINGS

The Settings menu allows you to adjust a variety of camera settings including:

Video Resolution

Photo Resolution

Time Lapse

Photo Burst

•and more

▶See SETTINGS MENU to make changes, learn how to navigate menu options

and read more details on each setting.

UsinG YoUr Hero3: caMera Modes

PLAYBACK

You can playback your GoPro Photos and Videos on a TV/HDTV or with the

LCD Touch BacPac™(optional accessory). Playback appears as a camera mode

when camera is powered ON and plugged into a TV/HDTV.

▶See PLAYBACK for more information on viewing your Videos and Photos.
