Glos LUCID Series User manual
INSTALLATION MANUAL
Important Notes and Satety Instructions
Please read installation manual carefully before commencement of installation.
Before carrying out any installation, ensure all power is switched off and disconnected from the main
power supply.
This product must be installed by a qualified installer under local and national regulations.
The light source of the luminaire is not replaceable. When the light source reaches its end of life, the
whole luminaire shall be replaced.
Product Warranty
For any warranty claim, a valid Proof of Purchase is required.
Glos does not warrant any claim based on defects or damage caused by improper
installation, improper operation, wrongful cleaning agents that deteriorate the surface
appearance, force majeure, and/or modifications made by purchaser or third party. For
warranty duration, please contact your service agent or GLOS sales representative for
more information.
Cleaning and Care
Before cleaning, disconnect the luminaire from main supply and allow it to cool. Clean
external surface using lint free cloth with alcohol-free and non-abrasive cleaning agent.
Corrosion Protection
Do not expose luminaire to corrosive agents (e.g salt, acid, chemical & cleaning agents)
during installation or cleaning, it will cause corrosion on the surface of the luminaire.
Ambient Condition
LED luminaires performs best in an ambient temperature <25°C (+-5°C). High ambient
temperature can reduce the lifespan and efficiency of LED module and driver.
Dimming
Before installation of luminaire, ensure control gear, LED and dimmer combination are
compatible. Improper or unsuitable use of dimmer can cause damage to the components.
Sizing Variation
Product A B
LUCID 140 270
LUCID
SERIES
C
36
A
B
C
D
D
146
Wood board
1
5
4
3
2
Installation Instructions Before installation or servicing, turn off and disconnect from main power supply.
If the external core cable of this luminaire is damaged, it shall be replaced by the
manufacturer, service agent or a similar qualified person to avoid a hazard. Loosen the
bolt as illustrated on figure 1 and remove mounting base.
For concrete application; Drill mounting holes accordingly and pull cable through
mounting plate. Fix the mounting base to the wall using the screws and plugs provided.
For wood board application; Ensure thickness of wood board is more than 10mm.
Fix the mounting base to the wall using the screws and plugs provided.
Connect main incoming supply to the connection block and ensure cable is connected
correctly. Secure luminaire to the installed mounting base.
1
2
3
4
5
INSTALLATION MANUAL
www.glos.com.sg
Ensure power is off when switching the colour temperature. Tighten bolt and restore
power.
Concrete
green/yellow
brown
blue
N L
N
L
OFF
ON
2
1
OFF
ON 2
1
2
3
4
1
29MM
3
6MM
109MM
2
1
1
2
1
2
3
30°
3000K 4000K
Please ensure power is off
when switching the colour
temperature
