1MODEL # 436980
User's manual Manual del usuario Manuel de l'utilisateur
Customer Service
US: 1-800-645-2986
Servicio de atención al Cliente
US: 1-800-645-2986
Service à la clientèle
Canada: 888-645-2986
Converts the power of a DC 13V Lead-Acid Battery to AC 100-120V/60Hz
AC Voltage through an inverter to supply power to electric hardware.
This product has: under-voltage protection, overload protection, power display and low-
voltage prompt
Product Composition
This product is composed of:
Main housing, Lead-acid battery, Charger,
Inverter, Relay, American Standard power
strip, Power display, 12V DC power
supply, Heat dissipation fan
Product Parameters
Overall Size: 14" x 12" x 11"
Weight: Net: 46.5 lbs, Gross: 55lbs
Charging Input Voltage: 100-240VAC 50/60 Hz, 9.9A (max)
Load Output Parameters AC: 100-120V, 60Hz, 500W
USB Output Parameters DC: 5V 2.1A
Charging time: ~4.5 Hours using built-in 9.9A Charger
Operating Ambient Temperature: 32-104 °F
Power Display: 7 Bar Voltage and Percentage Display
Warnings:
• The voltage of each electrical appliance is different. Before using any device with this power
supply, check whether the rated voltage range of the product is compatible with the output of
the power supply. Mis-matched voltage can cause damage and injury to the device, the power
supply, and the user.
• If the battery is discharged to the cut-off voltage, further discharge is called over-discharge.
Over-discharging can easily cause severe loss of battery power and shortens battery life. Avoid
over-discharging the batter when in use by charging it once the cut-off voltage is reached.
• Keep the battery away from re, high temperatures, humid or rainy environments during use
and storage.
• Do not disassemble the power supply. This item has a built-in high voltage power supply.
• Do not throw this power supply in general trash at the end of its life. Please recycle this item
according to local laws and regulations.
• The product's casing should be effectively and rmly grounded before use.
• Disconnect charging power cord before removing the case lid to remove or replace the battery.
• Disconnect the charging power cord before plugging any devices into the power supply.
This product charges the internal lead-acid battery through the charger. After the battery is fully charged,
the battery voltage (DC 13V) is converted to 100-120V AC through the inverter for output. When the battery
is fully charged, the charger will automatically protect the battery by disconnecting the charger plug,
and the relay coil to the inverter is closed. At this time, the inverter can be used with a load. During the
use of this product, the power display shows the corresponding voltage prompt according to the power
consumption proportion of the battery voltage. When the voltage of the lead-acid battery is lower than
10%, a buzzer will start an alarm. When charging, the charger must be connected to an external power
supply to charge the lead-acid battery. During charging, the relay disconnects the lead-acid battery from
the inverter. The inverter cannot supply a load while charging. This product has over-load and over-current
protection, as well as under-voltage protection and charging surge protection.
Model: 436980
40 AH / 500W Pure Sine Wave
Portable Power Supply
