Gigaset DL580 User manual

Template A6 for NEO, Version 1, 20.04.2016

DL580 / SUG UK-IE-IM en / A30350-M216-L101-3-7643 / Cover_front_bw.fm / 11/29/18

DL580

Template A6 for NEO, Version 1, 20.04.2016

DL580 / SUG UK-IE-IM en / A30350-M216-L101-3-7643 / overview.fm / 11/29/18

Overview

Template A6 for NEO, Version 1, 20.04.2016

DL580 / SUG UK-IE-IM en / A30350-M216-L101-3-7643 / overview.fm / 11/29/18

Overview

1Handset

2Display

Shows current date and time and further

information depending on situation

3 Quick-dial keys A - D

Save special phone numbers for easy

access

4 Speaker

5 Incoming call indicator

6 Sound boost key

During a call: boost the receiver/loud-

speaker volume

In the menu: return to idle mode

7Directorykey

Open the directory: short press

Open the black list: long press

8Up/Downkeys

In the menu and lists: scroll up/down

In idle mode: open the incoming calls list

In input fields: move the cursor to the

left/right

Incoming call: adjust ringtone volume

9OK/Menukey

In idle mode: open the menu

In the menu: confirm selection

10 Back / Mute key

During a call: mute the microphone

Incoming call: mute the ringtone

In the menu: return to the previous

menu level

In input fields: delete characters

11 Recall / Flash key

In idle mode: open the outgoing calls list

12 Handsfree key

Incoming call: accept call through the

handsfree function

During a call: switch from handset to

handsfree mode

13 Star / Do not disturb key

Disable ringtone

Template A6 for NEO, Version 1, 20.04.2016

DL580 / SUG UK-IE-IM en / A30350-M216-L101-3-7643 / security.fm / 11/29/18

Safety precautions

Read the safety precautions and the user guide before use.

The device cannot be used in the event of a power failure. In case of a power failure

it is also not possible to make emergency calls.

Do not use the devices in environments with a potential explosion hazard

(e.g. paint shops).

The devices are not splashproof. For this reason do not install them in a damp envi-

ronment such as bathrooms or shower rooms.

Use only the power adapter indicated on the device.

Remove faulty devices from use or have them repaired by our Service team.

Do not use the device if the display is cracked or broken. Broken glass or plastic can

cause injury to hands and face. Send the device to our Service department to be

repaired.

Extra loud / Sound boost function

• This setting can result in harm to health in persons with a normal hearing abil-

ity and is only intended for persons with a hearing impairment or reduced

hearing.

• Disruptive noises on the phone line can be increased.

Template A6 for NEO, Version 1, 20.04.2016

DL580 / SUG UK-IE-IM en / A30350-M216-L101-3-7643 / operating.fm / 11/29/18

Getting started

Connecting the phone

¤Insert one end of the supplied

telephone line cord into the con-

nection socket at the base of

the phone, then insert the other

end into the receiver .

¤Insert one end of the supplied

phone cable into the connection

socket at the rear of the device,

then insert the other end into the

phone socket .

¤Insert the power cable of the

power adapter into the connec-

tion socket at the rear of the

device, then insert the power

adapter into the power socket .

The device is designed for use in enclosed, dry rooms within a temper-

ature range of +5 °C to +45 °C.

The device's feet do not usually leave any marks on surfaces. However,

due to the multitude of different varnishes and polishes used on furni-

ture, contact marks on the surfaces cannot be completely ruled out.

Never expose the telephone to heat sources, direct sunlight or other

electrical devices.

Protect your telephone from moisture, dust, corrosive liquids and

vapours.

Template A6 for NEO, Version 1, 20.04.2016

DL580 / SUG UK-IE-IM en / A30350-M216-L101-3-7643 / operating.fm / 11/29/18

Making calls

Calling

Dialling

¤In idle mode, enter the number lift the receiver or press the

key . . . the number is dialled

Redial

¤Press lift the receiver or press the key . . . the last dialled

number is dialled

Quick-dial

If a telephone number is assigned to one of the keys to

¤Press the concerning key . . . the assigned number is dialled immediately

If a telephone number is assigned to one of the keys to

¤Press and hold the digit key . . . the assigned number is dialled immediately

The call is established via loudspeaker. If requested, pick up the receiver .

Dialling from a calls list

¤Press the key (incoming calls) or the key (outgoing calls) . . . the

calls list is opened use to select the number to be dialled pick up the

receiver or press the key

Dialling from the directory

¤Press the key . . . the directory is opened use to select the num-

ber to be dialled pick up the receiver or press the key

The quick-dial keys are set up via the directory configuration.

Template A6 for NEO, Version 1, 20.04.2016

DL580 / SUG UK-IE-IM en / A30350-M216-L101-3-7643 / operating.fm / 11/29/18

Making calls

Incoming calls

An incoming call is indicated by a ringtone, a display on the screen and the flash-

ing call indicator. The caller's phone number is displayed, if available. If the caller's

number is saved in the directory, the name is displayed.

Accepting a call

¤Pick up the receiver or press the key

Adjusting the ringer volume

¤Use to adjust the ringer volume during an incoming call

Muting the ringtone

If you do not want to be disturbed by an incoming call, you can mute the ringtone.

¤Press the key

Do not disturb

If activated, the telephone will not ring in the case of an incoming call.

¤Press and hold the key . . . the display shows the symbol

Reactivating the ringtone: press and hold the key again

The number of new incoming calls that have not been answered is

shown on the top right of the display next to the symbol.

The function can also be activated/deactivated in a time-controlled

manner via the menu setting DO NOT DISTURB.

Template A6 for NEO, Version 1, 20.04.2016

DL580 / SUG UK-IE-IM en / A30350-M216-L101-3-7643 / operating.fm / 11/29/18

Making calls

During a call

Switching to handsfree mode

¤Press the key hang up the receiver

Adjust earpiece/loudspeaker volume

¤Adjust the earpiece and loudspeaker volume by pressing during the call.

Boosting the receiver/loudspeaker volume

If the volume is not loud enough during a call, you can temporarily enhance it. The

setting will then apply until you end the call.

¤During the call, press the key

Muting the microphone

When the microphone is switched off, callers will no longer be able to hear you.

¤During the call, press the key

Reactivating the microphone: press the key again

Terminating a call

¤Hang up the receiver

Template A6 for NEO, Version 1, 20.04.2016

DL580 / SUG UK-IE-IM en / A30350-M216-L101-3-7643 / operating.fm / 11/29/18

Making calls

Calls lists

The phone saves up to 99 incoming and 15 outgoing calls in calls lists.

Opening a calls list

Incoming calls list: press the or key

Outgoing calls list: press the key

¤Use to scroll through the list

The caller‘s phone number is displayed. The number of the currently displayed

entry in the list is shown on the top right of the display next to the symbol.

Missed calls

Missed calls are stored in the incoming calls list. If there are missed calls, the sym-

bol in the top right corner of the display will flash. The number of new missed

calls is shown alongside this.

¤Open the incoming calls list . . . the last received missed call is shown

first, the caller‘s number is displayed

¤Use to scroll through the list.

If you have viewed a missed call, the symbol changes to .

Copying a number from the calls list to the directory

You can save numbers contained in a calls list to the directory.

¤Open the calls list use to select the desired entry

¤select COPY TO DIR. use to enter the relevant name

. . . the entry is stored

Deleting an entry/the list

You can delete one specific entry or the entire calls list.

¤Open the calls list

Deleting an entry: ¤use to select an entry select

DELETE ENTRY DELETE?

Deleting the list: ¤select DELETE LIST

DELETE?

Template A6 for NEO, Version 1, 20.04.2016

DL580 / SUG UK-IE-IM en / A30350-M216-L101-3-7643 / operating.fm / 11/29/18

Making calls
