Gigabyte T1006 User manual



English

This manual will help you to get started with setting up your netbook. The nal product

conguration depends on the model at the point of your purchase. GIGABYTE reserves

the right to amend without prior notice. For more detailed information, please visit our

website at http://www.gigabyte.com.

Using GIGABYTE Netbook for the First Time

Check Supplied Items

Congratulations on your purchase of the GIGABYTE netbook!

AC Adapter Battery Pack Manual Handy Bag (Optional)

Power Cord Driver CD Global Warranty

Card

Stylus (Optional)

* The illustrations in this document may appear differently from your model.

To install the battery please follow these steps:

1Insert the battery pack into the compartment.

2Remember to slide the switch to the “Lock” position.

English

Switching on the Power:

After you turn on the T1006 for the very rst time, do not turn it off until the operating

system has been configured. Please note that the volume for the audio will not

function until Windows® Setup has completed.

Booting Up the T1006 for the First Time:

Depending on your conguration, the Microsoft® Windows® Boot Screen will be the rst

screen that you will see as the netbook starts up. Follow the on-screen prompts and

instructions and enter your personal information to complete the setup of the Windows®

Operating System.

1Connect the the power cord to the AC adapter.

2Connect the AC adapter to the DC-in jack on the left side of the Netbook.

3Connect the power cord to the power outlet.

34 5 6

1 2

3 2

English

1Webcam

2LED Indicators 

3Touchpad

4LED Indicators 

5Microphone

Bluetooth Status Indicator

Wireless LAN Status Indicator

HDD Status Indicator

Battery Status Indicator

Power Status Indicator

Num. Lock Indicator

Caps Lock Indicator

3.5G Status Indicator(Optional)

Left View

Your GIGABYTE Netbook Tour

Panoramic View

1External Display (VGA) Port

2USB Port

3Air Vent

4HDMI Port

5Headphone Jack

6Microphone Jack

3 4 5 6

2 3

English

Base View

Right View

1Multi Card Reader 

2eSATA/USB Combo

3USB Port

4Power Button

5Ethernet Port

6DC-in Jack

Supports Secure Digital (SD),

Multi Media Card (MMC),

Memory Stick (MS),

Memory Stick PRO (MS PRO) Card.

1Kensington Lock

2Battery Bay

3SIM card slot 

4Speakers

To insert of a mobile SIM card for 3.5G

function (Optional)

English

The computer employs hotkeys or key combinations to access most of the

computer’s controls like screen brightness and volume output. To activate

hotkeys, press and hold the <Fn> key before pressing the other key in the

hotkey combination.

Hotkey Function Description

Fn+F1 Sleep Puts the computer in Sleep Mode.

Fn+F2 Wireless LAN Enables/disables the Wireless LAN function.

Fn+F3 Brightness Down Decrease the screen brightness.

Fn+F4 Brightness Up Increases the screen brightness.

Fn+F5 Display Toggle

Switches display output between the display

screen, external monitor (if connected) and

both.

Fn+F6 Touchpad Toggle Turns the internal touchpad on and off.

Fn+F7 Speaker Toggle Turns the speaker on and off.

Fn+F8 Volume Down Decreases the sound volume.

Fn+F9 Volume Up Increases the sound volume.

Fn+F10 WWAN (Optional) Enables/disables the WWAN fucntion.

Fn+F11 Bluetooth Enables/disable the Bluetooth function.

Fn+F12 Webcam Turns the internal webcam on and off.

Hotkeys

English

The screen of T1006 is convertible to simulate a Tablet PC. Follow the Steps to

use this function:

Use your T1006 as a Tablet PC

1Open the lid (the screen display of T1006.)

2On the top center above the keyboard is the pivot connecting the display

panel to the bottom case. There Is a sign

3Follow the sign to turn the screen clockwise up to 180 degree so that the

screen is facing out.

4FLay the turned screen down into the flat position. The keyboard will be

covered by the display. Use the stylus or simply touch the screen to operate

T1006 as a Tablet PC.

5When done with Tablet PC. Reverse the screen to 90 degree,turn counter-

clockwise set T1006 back to original position.

Attention:

Please note that the screen can only rotate at 180 degree Clockwise. Be

sure to turn the screen according to the sign. Forcing the screen to turn at the

wrong angle will cause serious damage to the T1006.

English

●GIGABYTE Smart Manager:

You can activate GIGABYTE Smart Manager by double clicking on the

shortcut icon on the desktop if the machine you purchased has the operation

system built-in. GIGABYTE Smart Manager is an icon-based control interface,

enabling users to intuitionally access common system setup as well as

GIGABYTE exclusive utilities. Please be noted that the GIGABYTE Smart

Manger interface, icons, utilities and software versions may vary based on the

purchased models. Please operate GIGABYTE Smart Manager according to

the default built-in version.

●GIGABYTE Smart Recovery:

If the machine you purchase already has operating system built-in, you

can restore the system back to factory default by using GIGABYTE Smart

Recovery. Please be noted that the GIGABYTE Smart Recovery according to

the default built-in version.

1.If the machine you purchase already has operating system built-in, you

can restore the system back to factory default by using GIGABYTE Smart

Recovery. Please be noted that the GIGABYTE Smart Recovery according

to the default built-in version.

2.Please be noted that personal data will be lost after recovery, do remember

to backup any data before operating this function.

Therefore will briey describe how to launch the Recovery Tool and to get the

recovery started.

1.Turn off or restart the netbook.

2.Turn the netbook on and press and hold the F9 key to launch the tool.

3.There shows the “Recovery” and “Exit” in Recovery System, click the

“Recovery” to start the restore back to factory default. 1

4.Recovery window shows the processing status. 2

5.You could restart the computer when restore has been done. 3

GIGABYTE Software Application

12 3

English

SKU Type Specication

CPU Intel® Atom™ Processor

Operation System Microsoft® Windows® 7 Compliant

LCD 10.1” Multi-Touch Panel.1366X768/1024X600, with LED

back-light

System Memory DDRIII SO-DIMM 1 slot (Max 4GB)

Chipset Mobile Intel® NM10 Express Chipset

Hard Disk Drive 2.5” 9.5mm SATA HDD 5400rpm

Audio 1.5 Watt Speaker*2, Internal Microphone

I/O Port

USB 3.0*1, USB 2.0*1, eSATA/USB 2.0 Combo*1, HDMI,

D-Sub, RJ45, Mic-in, Earphone-out, 4-in-1 Card Reader

(SD/MMC/MS/MS Pro) and DC-in Jack.

Communications

10/100/1000Mbps Ethernet

802.11b/g/n Wireless

Bluetooth v2.1 + EDR

3.5G Antenna built-in, 3.5G Module supported (Optional)

Webcam 1.3 Megapixel

Battery Li-ion 6-cell

Dimensions 265(W) x 214(D) x 41.4 (H)mm

Weight ~1.48kg (w/battery)

Specication

Appendix

■ Warranty & Service:

Warranty and service and related information please refer to the warranty card

or GIGABYTE service website as the below link :

http://www.gigabyte.com/support-downloads/technical-support.aspx

■ FAQ:

For FAQ (Frequent Asked Questions), please refer to the following link:

http://www.gigabyte.com/support-downloads/faq.aspx
