Gigabyte P37X User manual
P37P37
V3.0
English
1
English
PB Congratulations on your purchase of the GIGABYTE Notebook.
This manual will help you to get started with setting up your notebook. The final product
conguration depends on the model at the point of your purchase. GIGABYTE reserves the
right to amend without prior notice. For more detailed information, please visit our website at
www.gigabyte.com
1Connect the power cord to the AC adapter.
2Connect the AC adapter to the DC-in jack on the right side of the notebook.
3Connect the power cord to the power outlet.
Using GIGABYTE Notebook for the First Time
1
2
3
Switching on the Power
After you turn on the Notebook for the very
first time, do not turn it off until the operating
system has been configured. Please note that
the volume for the audio will not function until
Windows® Setup has completed.
IMPORTANT!
●Ensure that your Notebook PC is connected to a grounded power adapter before turning it on for the rst
time.
●When using your Notebook PC on power adapter mode, the socket outlet must be near to the unit and
easily accessible.
●Locate the input/output rating label on your Notebook PC and ensure that it matches the input/output
rating information on your power adapter. Some Notebook PC models may have multiple rating output
currents based on the available SKU.
●Power adapter information:
- Input voltage: 100-240Vac - Input frequency: 50-60Hz - Rating output voltage: 19V or 19.5V
English
3
English
2
Top View & Front View 1Light sensor
2Webcam
3Microphone
4Power Button
5TouchPad
6LED Indicators
7Battery Indicator Button
8Swappable Storage Bay
Bluetooth Status LED
Wireless Lan Status LED
HDD Status LED
Battery Status LED
Power Status LED
Press the right button of touchpad to
check the remaining battery power.
Right click to show the remaining power
percentage. As shown below, the
battery life indicator is available when
the laptop is shut down, in stand-by or
hibernation.(Battery mode)
<10%
11-30%
31-50%
51-70%
71-90%
>90%
2
1
Your GIGABYTE Notebook Tour
6
4
7
5
1
2
3
8
Booting Up the Notebook for the First Time
Depending on your conguration, the Microsoft®Windows® Boot Screen will be the rst screen that
you will see as the notebook starts up. Follow the on-screen prompts and instructions and enter
your personal information to complete the setup of the Windows®Operating System.
English
3
English
2Left View
21 3 6
4 5
1 4 5 6
2 3
1Kensington Lock Slot
2Ethernet Port
3USB 2.0 Port
4SD Card Reader
5Headphone Jack
6Microphone Jack
1Mini Display Port
2USB 3.0 Port
3USB 3.0 Port (USB Charge)
4HDMI Port
5External Display (VGA) Port
6DC-in Jack
1Memory Compartment
2Speakers
Base View
Right View
1
2
Warning:
DO NOT remove the built-in lithium battery. For any service needs, please contact your local GIGABYTE
Authorized Service Center.
English
5
English
4
The computer employs hotkeys or key combinations to access most of the computer’s controls like
screen brightness and volume output. To activate hotkeys, press and hold the <Fn> key before
pressing the other key in the hotkey combination.
Hotkey Function Description
Fn+ESC Eject ODD Eject ODD
Fn+F1 Sleep Put the computer in Sleep mode.
Fn+F2 Wireless LAN Enables/disable the Wireless LAN function.
Fn+F3 Brightness Down Decrease the screen brightness.
Fn+F4 Brightness Up Increase the screen brightness.
Fn+F5 Display Toggle
Switche display output between the display
screen, external monitor (if connected) and
both.
Fn+F6 Touchpad Toggle Turn the internal touchpad on and off.
Fn+F7 Speaker Toggle Turn the speaker on and off.
Fn+F8 Volume Down Decrease the sound volume.
Fn+F9 Volume Up Increase the sound volume.
Fn+F10 Screen Display Toggle Turn the screen display on and off.
Fn+F11 Bluetooth Enable/disable the Bluetooth function.
Fn+F12 Webcam Turn the internal webcam on and off.
Fn+Space Keyboard Backlight
Toggle Turn the keyboard backlight on and off.
Macro key
Macro keys can be set via Macro Hub, setting combination keys for complicated and/or general
operation.
Macro key Macro key Description
GMacro group switch, press around 3 secconds as hardware
switch on/off.
G1 User Programmable Macro key
G2 User Programmable Macro key
G3 User Programmable Macro key
G4 User Programmable Macro key
G5 User Programmable Macro key
Hotkeys
English
5
English
4Swappable bay Application
1Unlock swappable bay locker.
2Draw the swappable bay out.
1
2
Connect the HDD or SSD pin by sliding it into the connecter.
9.5mm/7mm HDD/SSD only
English
7
English
6
2
1
1Pull swappable bay back to slot.
2Lock swappable bay locker.
Gently push the plastic frame outwards. Slide in the HDD or SSD until it locks into place. There will
be a slight click.
English
7
English
6
Welcome to use Macro Hub ! Macro Hub makes it much easier for you to control your Macro Key
on P37. You can deal with complex key stroke combination by just one press on macro key, which
brings you benets both in work and game. Before using Macro Hub, please read following guide,
thanks.
1Launch Macro Hub
You can nd the shortcut of Macro Hub on desktop. Just double click it.
2The overview of Macro Hub
4
5
1 3
2
1Proles: View your current macro command settings.
2Macros: Edit macro command funtions anf settings.
3Settings: Update Macro Hub version or renew macro hub settings.
4Macro Key Group Indicators: Indicate the activated Macro Key Group (the atcivated
group indicator will light up)
5Macro Key Function: Show the programmed Macro functions under the Macro Key
Group, from G1 to G5.
Macro Hub Instruction
English
9
English
8
3Using Macro Hub
1Set Macro Key to basic function
a. Click the G button on the left-top of the
keyboard to switch to the Macro Key
group you would like to use
b. Click the Macro Key function brick
c. Double-click the function you would like to use(ex. Media Player) in the Basic or Macros
function area.
d. Complete the setting
English
9
English
8
2Edit macro command funtions anf settings.
a. Click "Macros" (you can set up to 100 sets of macro)
13
18
3
7
6
10
11
9
5
24
12
b. Overview of macro record panel (you can record your own macro here)
1. Start recording: Click when you’re about to record the macro
2. Pause key Switch: Enable/Disable Pause key to stop recording.
3. Macro Name: Set the name of this macro
4. Import icon: Set icon for this macro. You can use default icon or upload your own
icon
5. Record type: You can choose to record only mouse(or keyboard) movement, or
record both. You can also decide to or not to record mouse position.
6. Record interval: You can decide to or not to record the interval of each movement(or
You can set xed interval time between every movement)
7. Execution way: You can set the macro execution way (execution once, repeat
execution or repeat execution with deep press)
8. Export macro: Export your macro
9. Import macro: Import the macro
10. Delete all: Delete all movement in this macro
