Giant AVAIL 1 - DATASHEET 2 User manual
aVAIL 1
Spec Features
— Shimano 105, 5700-series 10-speed component group w/ compact crankset
— Giant Connect handlebar & stem, Connect carbon composite seatpost
— Wheelset: Giant P-R2 rims/ Formula Alloy hubs
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
frame geometry
Specifications and availability subject to change without notice.
Specifications
frame
SIZES XS,S,M
COLOUR White / Red
FRAME ALUXX SL-Grade aluminum
FORK Advanced-Grade composite w/
alloy OverDrive steerer
SHOCK N/A
componentS
HANDLEBAR Giant for Women Connect 31.8mm
STEM Giant Connect
SEATPOST Giant Connect carbon 30.9x350mm
SADDLE Selle Royal Seta W
PEDALS Not included
DriVetrain
SHIFTERS Shimano R700 w/ reach adjust
FRONT DERAILLEUR Shimano 105
REAR DERAILLEUR Shimano 105
BRAKES Tektro R540
BRAKE LEVERS Shimano R700 w/ reach adjust
CASSETTE Shimano 105 11-28T 10SPD
CHAIN Shimano 105
CRANKSET Shimano 105 34/50T compact
BOTTOM BRACKET Shimano external
WHeeLS
RIMS Giant P-R2 F:24H / R:28H
HUBS Formula Alloy
SPOKES Sapim Race 14g
TIRES Giant P-R3 700x25c
EXTRAS
A B C D E F G H
$
on-road | performance | Endurance
Actual
Frame Size Part
Number Head
Angle Seat
Angle* Toptube** Headtube Chainstay Wheelbase Standover
Height***
centimeters degrees degrees centimeters centimeters centimeters centimeters inches
XS 43.0 2114506 71.0 74.5 51.0 13.0 42.0 98.3 28.9
S 46.5 2114507 72.0 74.0 52.5 15.0 42.0 98.5 29.6
M 50.0 2114508 72.5 73.5 54.0 17.5 42.0 99.0 30.6
117
