GEONAUTE G-Eye Escape User manual
1
GB CONTENTS
VIDEO CAMERA DESCRIPTION ............................................................ 2
GETTING STARTED ............................................................................... 3
Insert battery...................................................................................................................3
Charge..............................................................................................................................3
Insert micro-SD card ......................................................................................................3
USING YOUR G-EYE.............................................................................. 4
Power ON / OFF...............................................................................................................4
Record a video ................................................................................................................5
Take a photo ....................................................................................................................5
Camera functions overview...........................................................................................5
Default settings...............................................................................................................6
CAMERA SETTINGS .............................................................................. 7
Video settings .................................................................................................................7
Photo settings .................................................................................................................8
General settings..............................................................................................................9
LASER POINTER ................................................................................. 11
TRANSFER FILES ON COMPUTER...................................................... 12
DISPLAY VIDEOS / PHOTOS ON TV/HDTV.......................................... 12
ERROR MESSAGES ............................................................................. 12
TECHNICAL FEATURES ...................................................................... 13
PRECAUTIONS FOR USE..................................................................... 13
WARRANTY, LEGAL WORDING........................................................... 14
Limited liability.............................................................................................................. 14
warranty......................................................................................................................... 14
Legal wording................................................................................................................ 14
2
VIDEO CAMERA DESCRIPTION
Record button
Photo button LCD screen
Video recording /
photo capture red
indicator
Laser
Slot for μSD card
Power / Charge red
indicator
Video recording /
Data transfer green
indicator
Microphone
Speakers
Micro-HDMI
connector
Micro-USB
connector
AV-Out connector
Screw to fasten the video
camera ("Kodak" standard)
Power / Stop
button
Power indicator
Audio recording
indicator
Video recording
Photo capture
Duration of recording
underway
Battery level
Active USB connection
Remaining memory
available
LCD SCREEN
3
GETTING STARTED
INSERT BATTERY
11
2
check that the battery is inserted in the right direction. Do not force it : it could damage
the camera and make it unusable.
CHARGE
4h
12
6
39
Fast Charging : When device is connected to computer, to have a more efcient charging process, you
can make a long press on "power" button to shut down the camera. Then, the green LED will be powered
off, and the red LED will be blinking during charging and stable when charge is completed. The charging
time will be around 3 hours in that case. (Warning : data transfer is not possible during this charging mode).
INSERT MICRO-SD CARD
Compatible Cards Micro-SD cards of 2GB to 32GB (Class 10 recommended)
4
USING YOUR G-EYE
POWER ON / OFF
POWER ON
3 s
STANDBY
After 5 minutes without being used, the camera turns automatically to the standby mode.
To record a video, p. 5
To take a photo, p. 5
POWER OFF
3 s
5
RECORD A VIDEO
START
STOP
TAKE A PHOTO
CAMERA FUNCTIONS OVERVIEW
CAMERAS MODES
Burst mode Page 8
Self timer Page 8
Time lapse Page 9
6
CAMERA SETTINGS
Video
Resolution Page 7
Video bitrate Page 7
Laser Page 7
Video recording mode Page 7
Resolution Page 8
General
Key beep Page 10
Date and time display Page 10
Continuous recording Page 10
Automatic sleep mode Page 10
TV standard Page 10
Frame rate Page 10
Date and time Page 10
OTHER FUNCTIONS
Laser pointer Page 7
Format memory Page 10
Return to default settings Page 10
DEFAULT SETTINGS
Video ( )
Resolution 1920 x 1080 @ 30 fps
Video bitrate High video bitrate
Laser Off
Video recording mode Video + audio
Photo ( )
Single/triple shot mode Single
Timer Off
Time-laps Off
Resolution 2592 x 1944 / 5 megapixel
General ( )
Beep On
Date and Time display Off
Continuous recording Off
Automatic sleep mode After 5 min
TV standard PAL
Frame rate 50 Hz
Language English
Return to default settings, see p. 10.
7
CAMERA SETTINGS
VIDEO SETTINGS
ACCESS TO VIDEO SETTINGS
3 s
1Navigate in the settings menu
2Enter in the setting
3Scroll between the setting choices
4Conrm the setting selection and return to upper menu
VIDEO SETTINGS LIST
SETTING SETTING CHOICES DETAILS
Resolution
1920 x 1080
30 fps, 16:9
1280 x 720
60fps, 16:9
1280 x 720
30fps, 16:9
Video bitrate
High video bitrate High video bitrate will provide a higher
denition of colours, but will use two times
more memory space than in Low bitrate
setting.
Low video bitrate
Laser
Disabled
Enabled
Automatic
The laser is automatically activated when
you record a video, and stops when you
stop recording.
Video recording
mode
Video and audio
Audio only is displayed.
Return to upper menu
8
PHOTO SETTINGS
ACCESS TO PHOTO SETTINGS
3 s
1Navigate in the settings menu
2Enter in the setting
3Scroll between the setting choices
4Conrm the setting selection and return to upper menu
PHOTO SETTINGS LIST
SETTING SETTING CHOICES DETAILS
Resolution
8MP, 4:3 3200 x 2400
5 M P, 4:3 2592 x 1944
3 M P, 4 :3 2048 x 1536
Shot mode
Single-shot mode In Burst Mode, the cameras takes
3 photos / second.
Burst mode
Self-timer
Disabled
When this function is activated, photos
are taken after 5 s or 10 s delay.
After 5 s
After 10 s
