GEO Calibration 2000 SHR User manual
2
TABLE OF CONTENTS
INTRODUCTION ............................................................... 4
PRODUCT WARRANTY.............................................................................................................. 5
UNPACKING INSTRUCTIONS.................................................................................................... 6
CALIBRATOR APPLICATIONS................................................................................................... 6
STANDARD PACKING CHECK LIST.......................................................................................... 7
STANDARD PACKING CHECK LIST.......................................................................................... 8
VISUAL ITEM CHECK LIST ........................................................................................................ 9
ACCESSORIES KIT CONTENTS.............................................................................................. 10
ACCESSORIES BOX CONTENTS.............................................................................................11
AVAILABLE ACCESSORIES..................................................................................................... 12
UNIT DIAGRAM AND PARTS LISTING .................................................................................... 16
QUICK START GUIDE.................................................... 17
VIDEO VERSION ....................................................................................................................... 17
FILLING THE RESERVOIR ....................................................................................................... 19
POWERING THE UNIT.............................................................................................................. 21
SCREEN OVERVIEW ................................................................................................................ 22
ENTERING TEMP & RH SET-POINTS...................................................................................... 24
BUTTON OPERATION............................................................................................................... 24
STATUS LIGHTS........................................................................................................................ 25
UNIT SCREEN NAVIGATION.................................................................................................. 26
CHANGING THE DOOR / OPENING THE CHAMBER............................................................. 28
GENERAL SPECIFICATIONS ................................................................................................... 29
CONSUMABLES........................................................................................................................ 30
MECHANICAL............................................................................................................................ 30
CALIBRATION................................................................. 31
UUTs (UNITS UNDER TEST) .................................................................................................... 31
CONTROL / REFERENCE PROBE CONFIGURATION............................................................ 32
TWO-POINT CALIBRATION - CLEAR OFFSETS, SLOPE AND INTERCEPT........................ 33
TWO-POINT CALIBRATION - TEMPERATURE ...................................................................... 34
TWO-POINT CALIBRATION - HUMIDITY................................................................................. 35
TWO-POINT CALIBRATION - VERIFICATION ......................................................................... 35
SYSTEM RECALIBRATION........................................... 36
SYSTEM UNCERTAINTY .......................................................................................................... 36
AUTO-CALIBRATION | PC SOFTWARE .................................................................................. 36
REFERENCE STANDARD RECALIBRATION............. 37
CONTROL PROBE / REFERENCE SENSOR........................................................................... 37
ENTERING MODEL 2000 SHR OFFSETS.................... 39
UNIT OFFSET CALIBRATION VIA PUTTY............................................................................... 39
ACCESSING THE DEVICE MANAGER.................................................................................... 39
READING THE COM PORT....................................................................................................... 40
INSTALLING PUTTY.................................................................................................................. 40
PUTTY SETUP........................................................................................................................... 40
3
CONNECTING THROUGH PUTTY............................................................................................ 41
READING TEMPERATURE AND HUMIDITY OFFSETS .......................................................... 41
CHANGING HUMIDITY AND TEMPERATURE OFFSETS ....................................................... 42
SAFETY WARNING ........................................................ 43
GENERAL SAFETY INFORMATION......................................................................................... 43
DISPOSAL SAFETY INFORMATION........................................................................................ 44
TECHNICAL SUPPORT ................................................. 44
REPAIRS.......................................................................... 45
UNIT REPAIR PROCEDURES................................................................................................... 45
MAINTENANCE............................................................... 46
SERVICE SCHEDULE............................................................................................................... 46
ERROR CODES AND DESCRIPTIONS .................................................................................... 47
DESICCANT CHANGE VISUAL GUIDE.................................................................................... 48
REPLACING THE CANISTER................................................................................................... 49
REFILLING DESICCANT CANISTER ....................................................................................... 50
DRAINING THE RESERVOIR.................................................................................................... 51
CONDENSATION IN THE CHAMBER....................................................................................... 52
CHANGING THE CONTROL PROBE ....................................................................................... 53
4
INTRODUCTION
WARNING As you read through this product manual, please familiarize yourself with
our recommended best practices. By following the proper procedures,
you will ensure your unit consistently performs to its highest potential.
Once you have removed the Model 2000 SHR from its external
packaging, please visually inspect the unit for damage. If damage is
found, please immediately contact your supplier.
MESSAGE FROM GEO CALIBRATION
Thank you for purchasing the GEO Calibration Model 2000 SHR humidity and temperature generator/
calibrator. We look forward to providing you the highest quality technical support as you become
familiar with your new humidity and temperature calibrator.
To better familiarize yourself with the Model 2000 SHR, please visit our Youtube Channel by
searching GEO Calibration for user friendly videos.
To start using your GEO Model 2000 SHR immediately, you may proceed to our Quick Start Guide
(page 17).
For a deeper review of the Model 2000 SHR, See our Calibration Technical Recommendations
(page 29).
Regards,
GEO Calibration Service Team
5
LIMITED WARRANTY AND LIMITATION OF LIABILITY
Each GEO Calibration product is warranted to be free from defects in material and workmanship under
normal use and service. The warranty period is one year and begins on the date of shipment. Parts,
product repairs, and services are warranted for 90 days. This warranty extends only to the original
buyer or end-user customer of a GEO Calibration authorized reseller, and does not apply to fuses,
disposable batteries, desiccants, distilled water, or to any product which, in GEO Calibration’s opinion,
has been misused, altered, neglected, contaminated, or damaged by accident or abnormal conditions
of operation or handling. GEO Calibration does not warrant that software will be error free or operate
without interruption.
GEO Calibration authorized resellers shall extend this warranty on new and unused products to end-
use customers only but have no authority to extend a greater or dierent warranty on behalf of GEO
Calibration. Warranty support is available only if your product is registered at:
https://www.geocalibration.com/register
and is purchased through a GEO Calibration authorized sales outlet or Buyer has purchased unit
directly from GEO Calibration. GEO Calibration reserves the right to invoice Buyer for importation
costs of repair/replacement parts when product purchased in one country is submitted for repair in
another country. GEO Calibration’s warranty obligation is limited, at GEO Calibration’s option, to
refund of the purchase price, free of charge repair, or replacement of a defective product which is
returned to a GEO Calibration authorized service center within the warranty period.
To obtain warranty service, contact your nearest GEO Calibration authorized service center to obtain
return authorization information, then send the product to that service center, with a description of the
diculty, postage and insurance prepaid (FOB Destination). GEO Calibration assumes no risk for dam-
age in transit. Following warranty repair, the product will be returned to Buyer, transportation prepaid
(FOB Destination). If GEO Calibration determines that failure was caused by neglect, misuse, con-
tamination, alteration, accident, or abnormal condition of operation or handling, including over voltage
failures caused by use outside the product’s specied rating, or normal wear and tear of mechanical
components, GEO Calibration will provide an estimate of repair costs and obtain authorization before
commencing the work. Following repair, the product will be returned to the Buyer, shipped Ex Works
FOB Suolk County NY.
THIS WARRANTY IS BUYER’S SOLEAND EXCLUSIVE REMEDYAND IS IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WAR-
RANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. GEO CALIBRA-
TION SHALL NOT BE LIABLE FORANY SPECIAL, INDIRECT, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES OR LOSSES, INCLUDING LOSS OF DATA, ARISING FROM ANY CAUSE OR THEORY.
Since some countries or states do not allow limitation of the term of an implied warranty, or exclusion
or limitation of incidental or consequential damages, the limitations and exclusions of this warranty may
not apply to every buyer. If any provision of this Warranty is held invalid or unenforceable by a court or
other decision-maker of competent jurisdiction, such holding will not aect the validity or enforceability
of any other provision.
GEO Calibration Inc.
2190 Smithtown Avenue
Ronkonkoma, NY, 11779
U.S.A.
PRODUCT WARRANTY
6
Once you have removed the Model 2000 SHR from its external packaging, please visually inspect the
unit for damage. If damage is found, please immediately contact your supplier.
The GEO Model 2000 SHR Humidity Calibrator generates and maintains a controlled humidity and
temperature environment for the purpose of testing or calibrating humidity and temperature sensors,
also known as hygrometers. The humidity calibration range is 5% up to 95%, while the temperature
range is from 5°C to 55°C.
See the full technical specications (page 29).
The system’s accuracy is achieved via a NIST traceable internal control and reference probe.
The Model 2000 SHR can calibrate many hygrometer types, including but not limited to:
• Probes
• Data-loggers
• Chart Recorders
• Additional Assorted Hygrometers
Before purchasing a Model 2000 SHR, please review the dimensions of the calibration chamber to
ensure compatibility with the size requirements of any Hygrometers you intend to calibrate.
The Model 2000 SHR allows for multiple types and sizes of hygrometers, please review the complete
list.
To view the full list of compatible hygrometers, please download our compatibility spreadsheet at:
https://www.geocalibration.com/humidity-generators/model-2000-shr/
UNPACKING INSTRUCTIONS
CALIBRATOR APPLICATIONS
7
STANDARD PACKING CHECK LIST
Contents of Shipment
QTY Part Number Description
101-201-00-0000 Model 2000 SHR Humidity Generator
101-201-11-0001 Model 2000 SHR Desiccant Canister
101-200-36-0002 Reference Standard / Control Probe
101-200-01-0035 2000 SHR Accessories Kit
101-200-36-0013 2000 SHR Accessories Box
101-200-08-0025 Chamber Insert for Air Circulation
1N/A Calibration Documents / Trace Paperwork
12000SHR_UM Model 2000 SHR User Manual
Contents of GEO Accessories Kit
QTY Part Number Description
101-200-82-0001 GEO Accessories Bag
101-200-36-0006 Fill Syringe (20ml)
101-200-69-0001 Type A Male to Type A Male USB Cable
101-200-46-0001 Mains Power Cord (220 Vac or 110 Vac)
101-200-30-0001 Banana Jack to Aligator Connectors Red and
Black Cable
101-200-85-0001 4 AMP Fuse (2 pack)
101-200-85-0002 1 AMP Fuse (2 pack)
101-400-80-0001 USB Dongle with GEO Software
8
Contents of GEO Accessories Box
QTY Part Number Description
101-001-00-0014 5 Port Door Square with 5 Plugs
401-001-66-0001 GEO Knobs (1 piece)
101-200-01-0036 GEO Bungs (7 pack)
Calibration Documents
QTY Part Number Description
1NO REORDER Factory Calibration Report
101-999-99-0001 3rd Party Calibration Certication (IF ORDERED)
STANDARD PACKING CHECK LIST
9
Listed below are standard contents included with the purchase of a new Model 2000 SHR .
Humidity Generator
GEO Calibration
Model 2000 SHR
P/N: 01-201-00-0000
Desiccant Canister
Pre-Filled with molecular sieve
P/N: 01-201-11-0001
Control Probe
HC2-S HygroClip
control probe (pre-installed)
P/N: 01-200-36-0002
2000 SHR Accessories
Kit
Contents:
See Page 10
P/N: 01-200-01-0035
Chamber Insert for Air
Circulation
P/N: 01-200-08-0025
VISUAL ITEM CHECK LIST
Calibration Documents
CALIBRATION
2000 SHR Accessories
Box
Contents:
See Page 10
P/N: 01-200-36-0013
USB Cable
(A to A)
P/N: 01-200-69-0001
10
USB Stick
Contains GEO Software
P/N: 01-400-80-0001
1 AMP Fuse (2 pack)
P/N: 01-200-85-0002
Banana Jack to Aligator
Connectors Red and
Black Cable
P/N: 01-200-30-0001
7 Piece Bung Kit
P/N: 01-200-01-0036
4 AMP Fuse (2 pack)
P/N: 01-200-85-0001
Fill Syringe (20ml)
P/N: 01-200-36-0006
Mains Power Cord
ACCESSORIES KIT CONTENTS
P/N: 01-200-46-0001 US
P/N: 01-200-46-0002 EUR
