Genius MEDIA POINTER E540 User manual

Media Pointer E540

User’s Manual

ENGLISH

INDEX

1. Introduction……………………………………………...……………3

2. Features…………..…………………………………………………...4

3. Package contents………………………………………………...……5

4. System Requirements.....…………………………...…………………5

5. Mode Feature………….………….………………………………..…5

6. Installation and Operation……..…...………………………..…….….6

7. Light Signal………………………………………………….………20

8. Function Description………...……………….……………………...21

9. Functions in Microsoft® Office……….….………….……….……..24

10.Functions in OpenOffice………...........….…………..……….……..26

11.Troubleshooting………………………..…………….…..…….…….28

ENGLISH

!!! Attention!!!

Do not allow minors to use the laser pointer unsupervised. Laser

pointers are not toys.

Avoid direct eye exposure.

Never shine the laser pointer at anyone. The laser pointer is

designed to illustrate inanimate objects.

Do not point the laser pointer at mirror-like surfaces. A reflected

beam can act like a direct beam on the eye.

ENGLISH

Introduction:

This Presenter is more than an ordinary presenter. Its stylish shape

makes it more like an art piece to enhance your experience and

enjoyment.

RF wireless technology makes this Presenter transmit data up to 60 feet

(20 meters). Conveniently placed page up and page down buttons help

you page through slides effortlessly.

With its omni-directional feature, you can confidently conduct business

meetings, hold conference meetings, and give teaching lessons.

The Presentation hotkey is conveniently placed so you can open

PPT/PPS/PDF/OPD/ABW files. The Laser pointer keeps your audience’s

attention.

ENGLISH

Features:

1. Innovative design and omni-directional Presenter for delivering perfect

presentations

2. Simple pairing design

3. Presentation hotkey allows you to open PPT/PPS/PDF/OPD/ABW

files conveniently

4. Laser pointer helps you keep your audience’s attention.

5. Works with bundled software

6. User-friendly interface is easy to use

ENGLISH

Package contents: System Requirements:

Presenter

USB type RF Dongle

Value Software CD-ROM

CR2032 battery

Multi-language user’s

manual on CD

Microsoft®Windows®Win2000, XP,

Vista.

512MB RAM recommended.

CD-ROM drive or DVD-ROM drive.

USB Port; PC platform

Mode Feature:

11 button Presenter

Use Cypress wireless solution.

RX side conforms to USB Specification Version 2.0

RX side conforms to USB HID Specification Version 1.1

TX side supports one LED indicator

RX side supports one LED indicator

Supports Laser pointer function

Use DC 3V power operation: CR 2032

Receiver with USB Port is easy to connect with your computer

RX side supports one low speed USB device

ENGLISH

Installation and operation:

1. Separate presenter and receiver

Rotate the presenter and receiver

according to the arrow.

Pull receiver away from presenter.

Separate presenter and receiver.

ENGLISH

2. Installing the battery

Open the battery cover of the presenter and put in the coin type lithium

battery (CR2032).

3. Installing the receiver

Plug the receiver into the USB port of your computer with the golden

pins on top. The blue indicator on the Presenter will flash if you press a

key and the receiver is inserted in the correct direction.

4. Installing the CD-ROM

Insert the autorun CD-ROM and the “Media Pointer E540 Remote

Master” installation will start automatically.

ENGLISH

XP Installation

ENGLISH

Table of contents

Other Genius Remote Control manuals

Genius

Genius ECHO TX4 RC User manual

Genius

Genius 07R - 10 User manual

Genius

Genius AMIGO TX2 868 User manual

Genius

Genius coralis CRH-01-T-00 User manual

Genius

Genius TRAVELER 600 User manual
