Genexis FiberTwist Series User manual
FTU-
FiberTwist–Series
Installation Guide
In the box
Fiber Termination Unit
(FTU) transparent demarcation cover
warrany seal splice
holders
cover
screw
wall plugs
& screws
adhesive
foam
zip ties
Installation guide
Choose coniguration
• Choose one of the four ingress pots to use for the feeder iber.
• If using ingress pot or , cut out the oblong blank of the FTU.
• If installing a patch-out, cut out the rectangle blank at the botom of the FTU.
• Inset zip ties in the set of holes matching your chosen coniguration.
Ingress
Ingress
Ingress
Ingress
Mount FTU to the wall
Use the drilling template provided to mount the FTU to the wall.
The FTU can also be mounted directly on a wall junction box.
The drilling template is available on htps:genexis.eudownload-potalibewist
mm
Atach pitail or patch cable
• Remove the SCAPC coupler from the FTU.
• Take the protective cap o the top end and
plug the iber into the coupler.
• Put the coupler and iber back in the FTU.
There is only one correct way to put the
connector back in the FTU:
• The slots must be facing upwards.
• The single metal clip on the right hand side
must face towards the middle of the FTU.
Clip
Atach feeder iber
• Strip the outer sheath o the feeder iber.
• If required, install a gasblocker. The
gasblocker should rest in the recess.
• Peel the backing o the foam padding
before wrapping it around the base of the
feeder iber.
• Position the feeder iber in the FTU and
secure in place using the zip ties. Trim the
excess ends o the zip ties.
Splice iber(s)
• Place the appropriate splice holder.
• Splice the feeder iber and pitail together
• Place the splice in the splice holder.
• Store the overlenth iber in the FTU.
• Peform any tests required to guarantee the qualiy of the splice.
•
Peform any tests required to guarantee the qualiy of the splice.
Thick cable suppot (optional)
The FTU suppots the abiliy to connect to a – potentially pre-connectorized –
thicker cable. If needed, the highlighted pillars can be removed with pliers to create
additional room for the thicker cable.
Removable pillars
Patch out (optional)
The device suppots the abiliy to patch out multiple feeder ibers. The patch pot
can be used with a duplex SC coupler or with a quad LC coupler.
• Connect the pitails to the patch out coupler, running the pitails through the
centre “S-bend” in order to orient the cables the correct way for the splice.
• Splice the pitails with the feeder ibers.
• Place the splices in the splice holder.
S-bend
SC(U)PC to SCAPC (optional)
The device suppots using a pre-connectorized iber with a SC(U)PC connector.
• Inset a SC(U)PC coupler as shown in the image.
• Connect the pre-connectorized iber to the SC(U)PC coupler.
• Connect the SC(U)PC to SCAPC patch cable to the SC(U)PC and SCAPC couplers.
Finish installation
• Remove the remaining protective cap from the FiberTwist coupler.
• Click the transparent cover on the FTU.
• Fasten the cover to the baseplate with the screw provided.
• If required, place a seal over the screw.
• Install the active unit or blind cover.
Genexis assumes no responsibiliy for any inaccuracies in this document. Genexis reseves
the right to change, modify, transfer, or othewise revise this publication without notice.
Revision . October , Copyright © Genexis B.V. All rights reseved.
