Gefen EXT-HDMATE-S User manual
HD Mate Scaler
USER MANUAL
www.gefen.com
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday through Friday PST
Write To:
Gefen Inc.
c/o Customer Service
20600 Nordhoff St
Chatsworth CA 91311
www.gefen.com
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
The HD Mate Scaler is a trademark of Gefen Inc.
© 2007 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE
TABLE OF CONTENTS
Introduction / Operation Notes
Features
Panel Layout
Operation Controls and Functions
Operation Controls and Functions
Operation Controls and Functions / Color Settings
Output Settings / OSD Adjustment / Information
Using the HD Mate Scaler
RMT-SR-IR Installation
Pin Conguration
Specications
Terminology
Warranty
1
2
3
4
5
6
7
8
9
10
11
12
13
INTRODUCTION
Thank you for purchasing the HD Mate Scaler.
The HD Mate Scaler switches two Component sources and one DVI source, all with digital
TOSlink and analog audio inputs.
The Gefen HD Mate Scaler allows you to upscale and switch your standard denition or
high denition component sources to resolutions up to 1080p. Anything from set-top boxes,
DVD players to the next generation of gaming consoles including the Xbox 360 and PS3
can be plugged into the HD Mate Scaler.
Note: The switching is done by using the RMT-SR-IR remote control. Any HDTV with
HDMI inputs can be connected to the DVI output of the HD Mate by using a DVI to HDMI
adapter, if the cable being used is HDMI.
1
OPERATION NOTES
READ THESE NOTES BEFORE INSTALLING
OR OPERATING THE HD MATE
• The HD Mate works with all DVI and HDMI displays.
• The HD Mate is fully HDCP compliant.
2
FEATURES
Features
• Both digital and analog inputs are format converted and pixel re-scaled through the
HD Mate Scaler. It outputs a large range of formats and resolutions that will easily
match the native resolution/ format of your display to ensure highest picture quality.
• DVI/HDCP compliant input: Operates up to 165Mhz (Up to UXGA @60Hz)
• Supports digital HD output up to 1080p.
• Integrated 8-bit triple-ADC/PLL.
• Integrated DVI/HDCP compliant receiver.
• Dual high quality scaling engines.
• Dual 3-D motion video adaptive de-interlacers with smooth low-angle edge.
• Automatic 3:2 pull-down & 2:2 pull-down detection and recovery.
• High performance frame rate conversion engine.
• Operates through on-screen OSD menu control and remote control.
Includes:
(1) HD Mate Scaler
(1) 6 ft DVI cable (M-M)
(1) 5V Power Supply
(1) IR Remote control
(1) User’s Manual
PANEL LAYOUT
3
DVI Output DVI Input
Component 1 Input
Component 2 Input
Mini Audio
Jack Inputs
Optical
Input 1
Optical
Input 2
Optical
Input 3
Analog Audio
Outputs
Optical
Output Connects 5V
Power Supply
IR Eye
OPERATION CONTROLS AND FUNCTIONS
PC INPUT: RGBHV VGA/SVGA/XGA/SXGA/UXGA/WXGA/WSXGA/WUXGA
VGA@ (60//72/75/85/SVGA @ (56/60/72/75/85)
XGA @ (60/70/75/85)/SXGA @ (60/75/85)/UXGA @
60/WXGA @ 60(1280x800)/WSXGA @ 60(1680x1050)/
WUXGA @ 60(1920x1200)/1360x768
DVI INPUT: Digital VGA @ (60/72/75/85)/SVGA @ (56/60/72/75/85)/
XGA @ (60/70/75/85)/SXGA @ (60/75/85)/UXGA @ 60/
WXGA @ (1280x800)/WSXGA @ 60(1680x1050)/
WUXGA @ 60(1920x1200)/1360x768
COMPONENT YPbPr 480p @ 50/60Hz
576p @ 50Hz
720p @ 50/60Hz
1080i @ 50/60Hz
1080p @ 50//60Hz
YCbCr 480i @ 60Hz
576i @ 50Hz
When connecting to a VGA PC source use a 15-pin D-sub cable to connect the output
of a PC to the DVI-I input connector of the HD Mate via a VGA to DVI.
When connecting to a component source (either SD or HD resolution) use a 3RCA to
3RCA cable to connect the YPbPr or YCbCr output of a DVD or Set Top Box to the
y-Cb/Pb-Cr/Pr input connector of the HD Mate.
When connecting to an HDMI source, use an HDMI to DVI cable to connect the HDMI
output of a STB or DVD to the DVI input connector of the HD Mate.
When connecting to a DVI source, use a DVI cable to connect to the DVI output of a
DVI source, such as a DVD or PC, to the DVI input of the HD Mate.
The HD Mate can automatically detect the input resolution of all three inputs.
The HD Mate accepts two component and one DVI inputs with audio inputs on each.
The formats supported by these inputs are as follows:
4
After you power on the unit, press the menu button and it will bring up the main menu
as follows:
OPERATION CONTROLS AND FUNCTIONS
Video (or PC): When Video is selected, a sub menu as shown below, will come up.
5
OPERATION CONTROLS AND FUNCTIONS
Picture mode: There are four picture modes for customers to choose from.
User: Select to adjust to your favorite setting and store it.
Standard: Standard factory default setting for optimal display in a normal
environment.
Vivid: High saturation picture for optimal display in a bright room.
Movie: Picture for comfortable low brightness display in a dark room.
Scale: Select overscan when input source is SD or HD video to ensure there will be no
black band around the screen border. Select underscan when input source is PC signal
to ensure full picture content will fall within the screen border.
Noise Reduction (NR): This function only works when the input source is analog RGB
or component, It will not work for the DVI input. There are four settings for Noise
Reduction-Off, Low, Middle, and High. The Noise Reduction will remove the noise that
results from the analog to digital conversion and digital scaling process.
H & V position: Adjust for the best horizontal and vertical position of the picture on the
screen.
User: Select to adjust to your favorite color temperature setting.
Normal: Normal color tone setting where white is pure white.
Warm: Warm color tone makes white a little reddish.
Cool: Cool color tone makes white a little bluish.
COLOR SETTINGS
6
Value of normal setting
OUTPUT SETTINGS
VGA (up to 100MH) DVI/HDMI (up to 165 MH) Resolution i/p* Format
480i 480i 720x480 i RGBHV
480p 480p 720x480 p RGBHV
576i 576i 720x576 i RGBHV
576p 576p 720x576 p RGBHV
720p @ (50/60) 720p @ (50/60) 1280x720 p RGBHV
1080i @ (25/30) 1080i @ (25/30) 1920x1080 i RGBHV
1080p @ (50/60) 1080p @ (50/60) 1920x1080 p RGBHV
VGA @ 60 VGA @ 60 640x480 p RGBHV
SVGA @ 60 SVGA @ 60 800x600 p RGBHV
XGA @ 60 XGA @ 60 1024x768 p RGBHV
SXGA @ 60 SXGA @ 60 1280x1024 p RGBHV
UXGA UXGA 1600x1200 p RGBHV
WXGA @ 60 WXGA @ 60 1280x800 p RGBHV
WSXGA @ 60 WSXGA @ 60 1680x1050 p RGBHV
WUXGA @ 60 WUXGA @ 60 1920x1200 p RGBHV
* i: interlaced p; progressive
Native: When selected, the HD Mate will automatically adjust its output
timing to match the native timing of the display.
Output: The HD Mate can output a wide variety of PC and HD resolutions as
follows.
H. Position: Adjust the horizontal position of the OSD graphic.
V. Position: Adjust the vertical position of the OSD graphic.
Time out: Set a pre-determined Time to turn off OSD menu on the screen.
Background: To select transparent or solid background of OSD graphic.
OSD ADJUSTMENT
Project: Show product model number.
Input: Show input resolution i.e. XGA.
Output: Show output resolution i.e. 720p.
Date: Show date of rmware version.
INFORMATION
7
