Gefen VGA-141SR User manual
VGA Extender SR
USER MANUAL
www.gefen.com
Technical Support:
Telephone (818) 884-6294
(800) 545-6900
Fax (818) 884-3108
Technical Support Hours:
9:00 AM to 5:00 PM Monday thru Friday.
Write To:
Gefen Inc.
C/O Customer Service
6265 Variel Ave.
Woodland Hills, CA91367-9897
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
the VGA Extender SR is a trademark of Gefen Inc.
Macintosh is a trademark of Apple Computer Inc.
© 2005 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE
TABLE OF CONTENTS
INTRODUCTION
OPERATION NOTES
INSTALLATION INSTRUCTIONS
HOW TO ADJUST THE PICTURE
CAT5 WIRING DIAGRAM
WIRING DIAGRAM
SPECIFICATIONS
WARRANTY
1
2
3
4
5
6
7
8
Thank you for purchasing the new ex•tend•it VGA Extender SR by Gefen, Inc.
The ex•tend•it VGA Extender SR by Gefen allows users the benefits of extending VGA
signals beyond the desktop. The VGAExtender SR series can be used to extend a VGA
signal to cover the distance of 150 feet. Industry standard Category 5 (CAT-5) cable is
used for the extension.
CONTENTS
The VGA Extender SR system consists of:
(1) VGA Extender SR sender unit
(1) VGA Extender SR receiver unit
(1) 5 VDC power supply
(1) VGA M-F cables (6FT)
(1) User Manual
HOW IT WORKS
In its most basic application, the VGA Extender SR sender resides next to the computer.
With the supplied VGAcable, the VGAExtender SR sender is connected to the computer.
The VGA Extender SR receiver is then placed next to the monitor or projector. Industry
standard Category 5 (CAT-5) cable is used to link the VGAExtender SR sender and VGA
Extender SR receiver together.
INTRODUCTION
1
READ THESE NOTES BEFORE INSTALLING
OR OPERATING THE VGA EXTENDER SR SYSTEM
• UseindustrystandardCategory-5(CAT-5)cabletooperatetheVGAExtenderSRsystem.
CAT-5 e cable is preferred.
• Please connect all the cables between the computer and the VGA Extender SR before
powering up the VGA Extender SR unit.
• The VGA Extender SR units are housed in a metal box for better RF shielding.
OPERATION NOTES
2
Connect the VGA Extender SR sender unit to the VGA output on the back of your
computer. The supplied six foot M-F VGA cable connects the CPU and sender unit
together.
Connect the VGA Extender SR receiver unit to your monitor with the VGA cable
that is attached to your monitor.
Connect the CAT5 cable between the VGA Extender SR sender and receiver’s
CAT5 input.
Plug the 5 volt power supply into the sender unit. The VGAExtender SR receiver
will draw power from the sender.
INSTALLATION INSTRUCTIONS
1.
2.
3.
4.
3
HOW TO ADJUST THE PICTURE
4
The first step in adjusting the video quality is to display text and a graphic on your monitor
(i.e. desktop icons). Then set your computer to the resolution that you will be using most
frequently. The dip switches are used to set the focus and sharpness of the picture to the
best possible setting. Set the dip switches to the settings that are recommended for the
different lengths of CAT5 cable (see chart below). Verify that the picture quality is to your
satisfaction. If the recommended setting does not produce a great quality picture, try using
a different dip switch setting.
The dip switches are located underneath the Receiver Unit. Peel off the silver sticker to
reveal the dip switch bay.
0-25 Feet All dip switches OFF for all colors.
26-55 Feet Set dip switch #1 ON all colors. 2,3,4 remain OFF.
56-85 Feet Set dip switch #2 ON all colors. 1,3,4 remain OFF.
116-145 Feet Set dip switch #3 ON all colors. 1,2,4 remain OFF.
146 Feet and Up Set dip switch #4 ON all colors. 1,2,3 remain OFF.
NOTE: The dip switches are set to the OFF position when the switch is closest to the
number or in the down position.
White/Orange
Orange
White/Green
Blue
White/Blue
Green
White/Brown
Brown
RJ-45 Jack RJ-45 Jack
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
1818
CAT5 WIRING DIAGRAM
5
WIRING DIAGRAM
6
Video Amplifier Bandwidth .................................................................................. 350 MHz
Input Video Signal ......................................................................................... 1.2 Volts p-p
Video In .................................................................................................................. HD-15
Focus .......................................................................................................... 25 to 150 feet
Video Out ............................................................................................................... HD-15
Link Connector ........................................................................................................ RJ-45
Power Supply ......................................................................................................... 5V DC
Power Consumption .................................................................................... 5 watts (max)
Dimensions .................................................................................... 1.9”H x 1.6”W x 3.5”D
Shipping Weight ....................................................................................................... 2 lbs.
SPECIFICATIONS
7
