Geemarc Large Display Alarm Clock User manual
Wakenshake gti
Large display alarm clock with shaker
Réveil grand écran avec vibreur
User guide p.2
Notice d’utilisation p.12
GB
F
A l a r m C l o c k
2
DESCRIPTION
3
Snooze key / Flash
PM LED indicator
Alarm LED indicator
PM
AL
Alarmtone
Alarm + ring / Off / Ring function
switch
Alarm off for 24H.
Set hours & minutes
Shaker Lo / Hi switch
Alarm mode switch
Set alarm
Set clock
Alarm and ring
volume
(*) Adaptor jack
Dimmer switch
(*) Shaker jack
(*) Modular jack
(*) Classified TVN-3 according to EN60950 standard.
3
4
1
(**) 230V
PTT plug
ACadaptor
Shaker
2
3
4
5
1-CONNECTINGTHETELEPHONE
1 - Connect the PTT line cord.
2 - At your option you may connect your
telephoneinthedoublerplug.
3-Connect the PTT doubler plug in the wall
socket.
4 - Connect the adaptor line cord.
5 - Connect the adaptor in the wall socket. (**)
(**) Classified “hazardous voltage” according to EN60950 standard.
Electrical connection : The apparatus is designed to operate from a 230V 50Hz
supply only. (Classified as «hazardous voltage» according to EN60950 stan-
dard).
The apparatus does not incorporate an integral power on/off switch. To
disconnect the power, either switch off supply at the mains power socket or
unplug the AC adaptor. When installing the apparatus, ensure that the mains
power socket is readily accessible.
Telephone connection : Voltages present on the telecommunication network are
classified TNV-3 (Telecommunication Network Voltage) according to the
EN60950 standard.
2 - SETTING THE TIME ( )
- Press and hold (set clock) button.
- Press H(hour) and M (minute) until correct
hourandminutesappearonthedisplay.
- Release (set clock) button.
- For p.m. hours, the p.m. indicator will appear
on the display near the inscription PM.
3 - SETTING THE ALARM TIME ( )
- Press and hold (set alarm) button.
- Press H(hour) or M(minute) until correct hour
andminutes appearonthedisplay.
- Release (set alarm) button.
- Press , H and Mto reset the alarm clock to
12.
5
4- SETTINGTHE ALARM MODE
Put the function switch on A+T position.
Choose which alarm mode you wish to be
awakenedto by moving the alarm mode switch
to one of the following selections :
V: only shaker activated
V+S : both sound and shaker alarm activated
S+F :bothstrobe lightandsoundalarm
activated
F+V : both strobe light and shaker alarm
activated
When the alarm is set to one of the alarm mo-
des, the alarm indicator will appear on the
display near the inscription AL.
Thetablebelowshows how thealarmmodes
indicateanincomingcallfromthealarmclock.
ALARMMODE
SOUND
SHAKER
STROBE LIGHT
ACTION
Buzzer
Vibrates
Flashes
ALARMCLOCK
Continuous
Continuous
Continuous
INCOMINGCALL
With pauses
With pauses
With pauses
6
5 - SNOOZE KEY ( )
When the alarm mode you have chosen is
switched on by the alarm time setting, pressing
the button will stop the alarm mode for
approximately9minutes.Thealarmwillthen
switch the alarm mode on again for a further 9
minutes. This sequence can be carried out for
up to 2 hours after which the alarm mode will be
automaticallyswitched off.
6 - SWITCHING THE ALARM OFF FOR 24H.
(OFF)
Press the alarm off button (OFF), the alarm will
then operate at the same time the next day. The
alarm if not switched off will continue to sound
for up to 2 hours and then be automatically
switched off.
7 - RINGER On/Off SWITCH ( A+T / OFF / T )
- A+T (alarm + telephone) : for the alarm and
telephoneringposition.
- OFF : alarm and ring off.
- T(telephone) : for the telephone ring position.
7
8-TELEPHONEOPERATION
- Ensure that the telephone has been set up in
accordancewiththetelephoneuserguideand
has been connected as shown in the installation
section.
- Select the ringer On/Off switch on the A+T or T
position for the ring.
- Choose which of the alarm modes you wish to
alert you of your incoming telephone calls (see
page 6 : V, V+S, S+F or F+V).
- When the alarm mode selected indicates there
isan incoming telephone call, lift the telephone
handset and answer the call. When you have
finished the call replace the handset and the
alarm will be ready to indicate the next call.
9 - DIMMER SWITCH ( )
Adjustthebrightnessofthedisplaybymoving
the control at the rear of your Wake n
ShakeGTI.
10-VOLUME(VOLUME)
Sets the volume of the ring and the alarm sound.
8
11 - TONE (TONE)
Sets the tone of the alarm sound.
12 - SHAKER SWITCH ( - / + )
Sets the motion of the shaker to Lo (-) or Hi (+).
13- BATTERYBACK-UP
It’s not necessary to insert a battery for the
clock to function. With battery back-up installed,
the clock will keep the time and alarm settings in
the event of a power cut or the AC adaptor being
unplugged.
Check the battery condition after one year,
replacingoldbattery.Aleakingbatterycan
destroy your clock.
9
10
GUARANTEE
FromthemomentyourGeemarcproductispurchased,
Geemarcguaranteeitfortheperiodofone year. Duringthis
time,allrepairsorreplacements(atouroption)arefreeof
charge.Shouldyouexperienceaproblemthencontactour
helplineorvisitourwebsiteatwww.geemarc.com.The
guaranteedoesnotcoveraccidents,negligenceor
breakagestoanyparts. Theproductmustnotbetampered
withortakenapartbyanyonewhoisnotanauthorised
Geemarcrepresentative.TheGeemarcguarantee innoway
limitsyourlegalrights.
IMPORTANT:YOURRECEIPTISPARTOFYOURGUARANTEE
ANDMUSTBERETAINEDANDPRODUCEDINTHEEVENT
OFAWARRANTYCLAIM
Please note: The guarantee applies to the United Kingdom
only.
Declaration:HerebyGeemarcTelecomSAdeclaresthatthis
productisincompliancewiththeessentialrequirementsand
otherrelevantprovisionsoftheRadioandTelecommunications
TerminalEquipmentDirective1999/5/EECandinparticularar-
ticle3section1a,1bandsection3.
Caution:Radiofrequencyinterferencemaycausediscernible
sound on the unit. The sound will end when the interference
stops.
