For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Dimensions and Installation Information (in inches)

†Water hook-up fits in back air clearance when calculating

installation depth.

If installed against a wall, allow clearance of 14-3/16" on freezer

side to remove bin.

Clearance required to remove fresh food full-size pan without

disassembling is 18-15/16".

Allow additional space for any necessary leveling adjustments.

"94 SxS Refer

A

Front View

Top View

G

D

C

F

BE

H

GSF25IGX

GE®25.0 Cu. Ft. Side-By-Side Refrigerator with Dispenser

Overall

Dimensions

Height to top of hinge (in.) A 69-3/4

Height to top of case (in.) B 68-3/4

Case depth without door (in.) C†28

Case depth less door handle (in.) D†31-1/4

Case depth with door handle (in.) E†33-5/8

Depth with fresh food door open 90° (in.) F†49-3/8

Width (in.) G 35-3/4

Width with door open 90° inc. door handle (in.) H 38-1/4

Air

Clearances

Each side (in.) 1/8

Top (in.) 1

Back (in.) 1

Listed by

Underwriters

Laboratories

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

Specification Revised 4/08 310104

GSH25IGX

Features and Benefits

• External Temperature Controls with Child Lock - Combines the ease of 0-9 temperature

settings, with the sophistication of electronic controls

• Adjustable Humidity Vegetable/Fruit Crispers - Provide ideal storage environment for fruits

and vegetables

• Adjustable Temperature Deli Drawer - Keep meats and cheeses fresher, longer

• Snack Pan - Conveniently stores re-wrapped meats, cheeses and other snacks

• Adjustable Gallon Door Bins - Provides additional storage space for milk and other gallon-

size containers

• Adjustable Slide-Out, Spillproof Glass Shelves - Raised edges help contain spills and slide-

out shelves make clean up quick and easy

• GE Water Filtration - Provides clean, fresh-tasting filtered ice and has a slim

spacesaving design

• FrostGuard™Technology - Protects frozen items from freezer burn by monitoring freezer

door openings and defrosting only when needed

• AutoEnergy Saver - Senses freezer and fresh door openings and adjusts refrigeration

operation cycles accordingly

• NeverClean™Condenser - Condenser coils are encased, so they don't require cleaning in

normal operating environments

• Deluxe Quiet Design - Significantly reduces operating noise

• Model GSH25IGXWW - White on white

• Model GSH25IGXBB - Black on black

As an ENERGY STAR®

partner, GE has determined

that this product meets the

ENERGY STAR guidelines

for energy efficiency.

GSF25IGX

GE®25.0 Cu. Ft. Side-By-Side Refrigerator with Dispenser

Specification Revised 4/08 310104
