GE Profile PGB910SEMSS Manual

Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

geappliances.com or call GE Answer Center®

service, 800.626.2000.

*Note: Dimension from the wall to the front

of the closed door handle is 29". Depth to

front edge of cooktop 25-1/4".

Electrical Rating: 120V, 60Hz, 9A

Installation Information: Before installing,

consult installation instructions packed

with product for current dimensional data.

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

PGB910SEM

GE Profile™ 30" Free-Standing Gas Range

Specification Revised 2/10

230585

Depth with door closed

(includes handle)

14-1/2 2-1/2

Recommended area

for thru the floor

connection of pipe stub

and shut-off valve

Recommended common

area for gas outlet and

electrical outlet

Recommended

area for 120V outlet

on rear wall and

area for thru the

wall connection

of pipe stub and

shut-off valve

47-3/16"36-1/4 ±1/4

Depth varies

depending on model.

See specifications

sheet for your model.

29"

46-7/8"

Depth with

door open

26-5/8"

Depth with door closed

(includes handle)

14-1/2 2-1/2

Recommended area

for thru the floor

connection of pipe stub

and shut-off valve

Recommended common

area for gas outlet and

electrical outlet

Recommended

area for 120V outlet

on rear wall and

area for thru the

wall connection

of pipe stub and

shut-off valve

47-3/16"36-1/4 ±1/4

Depth varies

depending on model.

See specifications

sheet for your model.

29"

46-7/8"

Depth with

door open

26-5/8"

Features and Benefits

• Self-CleanOven-Convenientlycleanstheovencavitywithoutneedofscrubbing

• Extra-LargeOvenCapacity-Providesalargeoveninterioridealforcookingmore

items at once

• DeepRecessedCooktop-Designedwitharecessedsurfacetohelpcontainspills

and make cleaning easy

• CenterOvalBurner-Addsafifthelementtothecenterofthecooktop

to accommodate large cookware and deliver ideal results

• Non-StickGriddle-Offersaflatcookingsurface,placedoverthecenterovalburner,

for cooking multiple foods at once

• PowerBoil™17,000 BTU Burner - Delivers 17,000 BTUs of forceful heat for rapid boiling

• QuickSetVOvenControls-Featureaneasytousedesignthatallowsyoutoset

precise cooking temperatures

• PreciseSimmerBurner-Deliversalowsettingof140degrees,idealfordelicate

foods and sauces

• ContinuousGrates-Provideaflat,sturdysurfaceallowingeasymovementofpans

between burners

• DishwasherSafeGrates-Durablegrateconstructioncanbeplacedintothe

dishwasher for easy cleaning and maintenance

• ModelPGB910SEMSS-Stainlesssteel

PGB910SEM

LITE

FRONT

654

LO HI

LITE

REAR

654

LITE

RECISESIMMER

REAR

654

LITE

POWER

BOIL

FRONT

POWERBOIL

LITE

CENTER

654

O C T C

12345

67890

Specification Revised 2/10

230585

PGB910SEM

GE Profile™ 30" Free-Standing Gas Range
