GE JGBS17DEM Manual
Dimensions and Installation Information (in inches)
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Specification Created 5/07 330584
24
30" FS Gas Ranges-CL
A10325
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
Installation Information (Dimensions in inches)
Recommended common
area for gas outlet and
electrical outlet
C
L
46-1/8
26-1/4*
46-1/4
36-1/4±1/4
*Dimension from wall
to front of closed
door handle is 29".
30
24
30" FS Gas Ranges-CL
A10325
30
8
4
9
2
2-1/2
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
Installation Information (Dimensions in inches)
Recommended common
area for gas outlet and
electrical outlet
C
L
46-1/8
26-1/4*
46-1/4
36-1/4±1/4
*Dimension from wall
to front of closed
door handle is 29".
30
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
*Dimension from the wall to the front of the closed door
handle is 29". Depth to the front edge of cooktop 25-1/4".
Factory set for Natural gas. A set of LP orifices
is included with each range for LP conversion.
Gas Self-Clean Range Anti-Tip Bracket
(Part No. 205C1714P001)
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
JGBS17DEM
GE® 30" Free-Standing Standard Clean Gas Range
Features and Benefits
• Extra-Large Oven Capacity - Provides a large oven interior ideal for cooking more
items at once
• All Purpose Burners - Deliver a wide range of heat output ideal for most cooking
requirements
• Electronic Clock And Timer - Features a convenient digital clock and easy-to-use
timer with an audible signal to help coordinate cooking times in the kitchen
• Standard Grates - Provide a sturdy and convenient cookware surface
for everyday cooking
• Porcelain Oven Door - Offers a scratch-resistant porcelain coating for easy cleaning
• ClearView™ Window - Features a convenient viewing area to check the progress
of food
• Two Oven Racks - Feature a durable construction to help accommodate any size
or type of cookware
• Six Rack Positions - Provides flexibility and allows consumers to make the most
of available oven capacity
• Interior Oven Light - Supplies light to make viewing the progress of cooking easy
and convenient
• Electronic Pilotless Ignition - Provides reliable burner ignition operation, eliminating
the need for a standing pilot
• Easy Clean Subtop - Porcelain enameled subtop collects spills and messes
for easy cleaning
• Model JGBS17DEMWW - White on white (white door and cooktop)
• Model JGBS17DEMBB - Black on black (black door and cooktop)
JGBS17DEM
LIGHT
TEMP
KITCHEN
Specification Created 5/07 330584
JGBS17DEM
GE® 30" Free-Standing Standard Clean Gas Range
This manual suits for next models
