Dimensions and Installation Information (in inches)

For answers to your Monogram,® GE Profile™or

GE®appliance questions, visit our website at

ge.com or call GE Answer Center®service,

800.626.2000.

Specification Created 4/06 330532

All GE ranges are equipped with

an Anti-Tip device. The installation

of this device is an important,

required step in the installation

of the range.

*Dimension from the wall to the front of the closed door

handle is 29". Depth to the front edge of cooktop 25-1/4".

Gas Self-Clean Range Anti-Tip Bracket

(Part No. 205C1714P001)

Electrical Rating: 120V, 60Hz, 5A

Installation Information: Before installing,

consult installation instructions packed with

product for current dimensional data.

24

30

8

4

9

2

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

30

47-1/2

26-1/4*

46-3/8

36-1/4 ±1/4

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

C

L

24

30

8

4

9

2

2-1/2

Recommended area for

thru the floor connection

of pipe stub and shut-off valve

Recommended area for

120V outlet on rear wall

and area for thru the wall

connection of pipe stub

and shut-off valve

30

47-1/2

26-1/4*

46-3/8

36-1/4 ±1/4

Installation Information (Dimensions in inches)

Recommended common

area for gas outlet and

electrical outlet

C

L

JGBP86SEL

GE® 30" Free-Standing Self-Clean Gas Range

Specification Created 4/06 330532

Features and Benefits

• Self Clean Oven - Conveniently cleans the oven cavity without need of scrubbing

• Extra-Large Oven Capacity - Provides a large oven interior ideal for cooking more

items at once

• Deep Recessed Cooktop - Designed with a recessed surface to help contain spills

and make cleaning easy

• Center Oval Burner - Adds a fifth element to the center of the cooktop, ideal for

griddle or odd-size cookware

• Non-Stick Griddle - Offers a flat cooking surface, placed over the center oval burner,

for cooking multiple foods at once

• PowerBoil™16,000 BTU Burner - Delivers 16,000 BTUs of forceful heat for rapid boiling

• Precise Simmer Burner - Delivers a low setting of 140 degrees, ideal for delicate

foods and sauces

• Continuous Grates - Provide a flat, sturdy surface allowing easy movement of pans

between burners

• Dishwasher-Safe Grates - Feature durable construction for worry-free and effortless

cleaning and maintenance

• Sealed Cooktop Burners - Eliminate the space between the burners and the cooktop

to help contain spills and boil over liquids, ensuring easy cleanup

• TrueTemp™System - Delivers even heat distribution and maximum oven control

• Big Hearth Window - Features an enhanced shape to add an elegant appearance

and make viewing trouble-free

• Model JGBP86SELSS - Stainless steel

JGBP86SEL

PRECISESIMMERHIGHOUTPUT

OVENCONTROLS

TrueTemp

BAKE

SELF

CLEAN

COOKING

TIME

DELAY

START

TIMER

CLOCK

OVEN

LIGHT

ONOFF

BROIL

START

CLEAR

OFF

TIMECONTROLS

JGBP86SEL

GE® 30" Free-Standing Self-Clean Gas Range
