GE 040315A-0 - ILLUSTRATED REV A Setup guide

Not for

Reproduction

Illustrated Parts List

MODEL

040315A-0

7,000 Watt

Home Generator System

Rev. A

IPL No. 314263 2/1/2011

Not for

Reproduction

Not for

Reproduction

Table Of Contents

Torque Specification Chart ............................................................................................ Inside Back Cover

PRODUCT COMPONENTS PAGES

Main Unit .............................................................................................................................................................. 4

Alternator .............................................................................................................................................................. 6

Control Panel ....................................................................................................................................................... 7

Enclosure ............................................................................................................................................................. 9

Not for

Reproduction

loded View - Main Unit

NOTE: Unless noted otherwise, use the

standard hardware torque

specification chart.

313698

The above parts group applies to the following Mfg. Nos.:

Briggs & Stratton Power Products Group, LLC

2011

040315A-0 - 7,000 Watt Home Generator System (General Elect

314263IPL No.

Not for

Reproduction

Part No. Descri

tionRef.

Parts List - Main Unit

Footnotes:

Part No. Descri

tionRef.

CRADLE1 B191860GS

BOX, Muffler2 313654GS

TRAY, Oil Drain3 193536GS

ADAPTER, Engine4 191793GS

ALTERNATOR ASSEMBLY5 -----

* WASHER, Lock, M86 -----

BOLT7 B4300GS

WASHER, 8.4 x 22.2 x 38 96796GS

KIT, Seal9 311723GS

TAPTITE10 2830598SM

CAPSCREW, Hex Head, 5/16-24 x 9.8411 187365HGS

KIT, Deflector, Muffler Assembly12 207270GS

ASSEMBLY, Deflector Muffler13 193475GS

BRACKET, Muffler14 313651GS

GASKET15 692236

SCREW, Taptite, M8 1.25 x 1516 83512GS

MUFFLER17 207059GS

SCREW, Socket Head Cap18 698941

PIPE, Exhaust19 194159GS

KIT, Muffler Hardware20 195008GS

KIT, Vibration Mount21 194209GS

CLIP, Retainer Fuel Hose22 192940GS

* CAPSCREW, Hex Head, M6 - 1.0 x 3023 -----

* WASHER, Lock, M624 -----

* CAPSCREW, Hex Head, 5/16-18 x 125 -----

SCREW, Taptite, M5 - .8 x 1026 74908GS

HOSE, Fuel27 206817GS

ARRESTOR, Spark29 194221GS

PLATE, Switch30 206047GS

SWITCH31 206045GS

WASHER, Lock, #432 27772GS

* - Items without part numbers are common fasteners and are available at your local hardware store.

** Contact Engine Manufacturer

The above parts group applies to the following Mfg. Nos.:

Briggs & Stratton Power Products Group, LLC

2011

040315A-0 - 7,000 Watt Home Generator System (General Elect

314263IPL No.

Not for

Reproduction

loded View - Main Unit

NOTE: Unless noted otherwise, use the

standard hardware torque

specification chart.

313698

The above parts group applies to the following Mfg. Nos.:

Briggs & Stratton Power Products Group, LLC

2011

040315A-0 - 7,000 Watt Home Generator System (General Elect

314263IPL No.

Not for

Reproduction

Part No. Descri

tionRef.

Parts List - Main Unit

Footnotes:

Part No. Descri

tionRef.

* SCREW, Phillips Head, 4-40 x .01933 -----

COVER, Bearing34 192906GS

HOSE, Oil Drain35 1723165SM

WIRE, Ground48 15253621GS

WARMER, Oil49 01916

CLAMP50 57822GS

** ENGINE900 -----

MANUAL, Operator’s (Not Illustrated)-- 313689GS

MANUAL, Engine (Not Illustrated)-- 277766TRI

KIT, Manual ACC (Not Illustrated)-- 313695GS

FLEX HOSE (Not Illustrated)-- 202295GS

PAINT, Touchup, Silver (Not Illustrated)-- 198811GS

FILTER, Oil (Not Illustrated)-- 492932B

FILTER, A/C Cartridge (Not Illustrated)-- 790263

KIT, Conversion, LP (Not Illustrated)-- 195069GS

BIT, Screw (Not Illustrated)-- 196731BGS

WARMER, Battery (Optional Accessory)-- 01915

KIT, Maintenance (Optional Accessory)-- 6034

PAINT, Touchup Spray, 12oz, Gray (Optional

Accessory)

-- 199474GS

* - Items without part numbers are common fasteners and are available at your local hardware store.

** Contact Engine Manufacturer

The above parts group applies to the following Mfg. Nos.:

Briggs & Stratton Power Products Group, LLC

2011

040315A-0 - 7,000 Watt Home Generator System (General Elect

314263IPL No.

Not for

Reproduction

loded View - Alternator

NOTE: Unless noted otherwise, use the

standard hardware torque

specification chart.

206480

The above parts group applies to the following Mfg. Nos.:

Briggs & Stratton Power Products Group, LLC

2011

040315A-0 - 7,000 Watt Home Generator System (General Elect

314263IPL No.

Not for

Reproduction

Part No. Descri

tionRef.

Parts List - Alternator

Footnotes:

Part No. Descri

tionRef.

ADAPTER, Alternator1 209599GS

ROTOR2 195430GS

STATOR3 206542GS

RBC (with O-Ring p/n 189197GS)4 193336GS

BOLT5 86308BGS

BRUSH ASSEMBLY6 66386GS

TAPTITE7 66849GS

PIN9 81917GS

HARNESS, Wiring10 193472GS

COVER, Rear Bearing11 192906GS

TAPTITE12 74908GS

BEARING13 65791GS

The above parts group applies to the following Mfg. Nos.:

Briggs & Stratton Power Products Group, LLC

2011

040315A-0 - 7,000 Watt Home Generator System (General Elect

314263IPL No.

Not for

Reproduction

loded View - Control Panel

NOTE: Unless noted otherwise, use the

standard hardware torque

specification chart.

208189

The above parts group applies to the following Mfg. Nos.:

Briggs & Stratton Power Products Group, LLC

2011

040315A-0 - 7,000 Watt Home Generator System (General Elect

314263IPL No.
