GE JP201CBSS User guide
Specification Revised 9/06 321305
JP201CBSS
GE®Built-In Electric Cooktop
For answers to your Monogram,® GE Profile™or
GE®appliance questions, visit our website at
ge.com or call GE Answer Center®service,
800.626.2000.
Note: Built-In Electric Cooktops require 1-1/2" free
area between the bottom of the cooktop and any
combustible material, i.e., shelving. Requires an
18" minimum from cooktop to adjacent overhead
cabinets. Units are furnished with a 48” flexible
armored cable.
Installation Information: Before installing, consult
installation instructions [Pub. No. 31-0978] packed
with product for current dimensional data.
KW Rating
240V 3.4
208V 2.5
Electrical junction
box 12" MIN.
below countertop
30" MIN. to
unprotected
cabinet
Cut should
not interfere
with cabinet
structure at
front
2" MIN.
clearance to
side wall
2" MIN.
clearance to
side wall
18" MIN.
to cabinet
2" to
rear wall
13" MAX.
depth
Cooktop
2-1/2"
Required
20-1/8"
16-1/8"
21-1/4" 16-5/8"
3"
Dimensions and Specifications (in inches)
Specification Revised 9/06 321305
JP201CBSS
GE®Built-In Electric Cooktop
Features and Benefits
• Compact Cooktop – Smaller cooktop is ideal for 21"
cooktop installations
• One 6" and One 8" Coil Heating Elements – Provide
consistent and even heat on the cooktop with plug-in
elements that are removable for easy cleaning
• Chrome Drip Bowls – Contain minor spills and are
removable for easy cleaning
• Heating Element “On” Light – Illuminates when the cooking
surface is activated
• Model JP202DWW – White
• Model JP201CBSS – Stainless steel
