Garmin Nuvi 1360 Instruction manual

Starry Liu, 11643, 2010/09/27

nüvi

1360

quick start manual

Starry Liu, 11643, 2010/09/27

2 nüvi 1360 Quick Start Manual

Looking at Your nüvi

Speaker Mini-USB

connector

Power button:

Press to turn the nüvi on and off.

microSD

™

card slot

Microphone

Using the Main Menu

➊➋➌➍ ➎

➏ ➐

➑ ➒ ➓

➊

GPS satellite strength.

➋

Bluetooth®technology status.

➌

Touch to select a usage mode.

➍

Current time. Touch to change

time settings.

➎

Battery status.

➏

 Touchtondadestination.

➐

Touch to view the map.

➑

Touch to make a call when

connected to a compatible

mobile phone. (Go to www.

garmin.com/bluetooth/ to

determine whether your

mobile phone with Bluetooth®

technology is compatible with

the nüvi.)

➒

Touch to adjust the volume.

➓

Touch to use the tools, such as

settings and Help.

Starry Liu, 11643, 2010/09/27

nüvi 1360 Quick Start Manual 3

Setting Up Your nüvi

Mounting Your nüvi

1. Remove the clear plastic from the suction cup.

Place the suction cup on the windshield.

2. Flip the lever back toward the windshield.

3. Snap the cradle onto the suction cup arm.

4. Plug the vehicle power cable into the back of

your nüvi.

5. Plug the other end of the vehicle power cable

into a power outlet in your vehicle. Your unit

should turn on automatically if it is plugged in

and the vehicle is running. Follow the on-screen

instructions.

6. Fit the bottom of your nüvi into the cradle.

7. Tilt your nüvi back until it snaps into place.

WARNING: This product contains a lithium-ion battery. To prevent damage, remove the unit from the

vehicle when exiting or store it out of direct sunlight.

Cradle

Suction cup mount

Vehicle power cable

Starry Liu, 11643, 2010/09/27

4 nüvi 1360 Quick Start Manual

Acquiring Satellites

1. Go outdoors to an open area,

away from tall buildings and trees.

2. Turn on your nüvi.

Acquiring satellite signals can take a

few minutes. The bars indicate

satellite strength. When at least one

of the bars is green, your nüvi has

acquired satellite signals.

Using the Power Button

Press and quickly release the Power

button to view additional options:

• Touch and to adjust the

screen brightness.

• Touch Lock Screen to prevent

accidental screen touches.

• Touch Power Off to turn off your

nüvi. You can also turn off the

nüvi by holding the Power button

for 2 seconds.

Resetting Your nüvi

If your nüvi stops functioning, reset

your nüvi by pressing and holding the

Power button for 10 seconds.

Finding Points of Interest

1. Touch Where To? > Points of

Interest.

2. Select a category and a

subcategory, if necessary.

3. Select a destination, and touch

Go!.

4. If necessary, touch Start to

navigate the route.

To enter letters contained in the

name, touch Where To? > Points of

Interest > Spell Name.

To search for a location in a different

area, touch Where To? > Near.

Starry Liu, 11643, 2010/09/27

nüvi 1360 Quick Start Manual 5

Following Your Route

Your route is marked with a magenta

line. As you travel, your nüvi guides

you to your destination with voice

prompts, arrows on the map, and

directions at the top of the map. If you

depart from the original route, your

nüvi recalculates the route.

Touch and drag the map to view a

different area of the map.

A speed limit icon could appear as

you travel on major roadways.

➊ ➋

➌

➍

➎➏ ➐

➊

Touch to view the Next Turn

page and the fullscreen Junction

page (if available).

➋

Touch to view the Turn List

page.

➌

Touch to view the Where Am I?

page.

➍

Touch and to zoom in

and out.

➎

Touch to return to the Main

menu.

➏

 Touchtochangethedataeld.

➐

Touch to view the Trip

Computer.

Adding a Stop

1. While navigating a route, touch

> Where To?.

2. Search for the extra stop.

3. Touch Go!.

4. Touch Add as Via Point to

add this stop before your nal

destination.

Taking a Detour

1. While navigating a route, touch .

2. Touch .

Starry Liu, 11643, 2010/09/27

6 nüvi 1360 Quick Start Manual

Using Hands-Free

Features

Bluetooth wireless technology is

available on some nüvi models.

To use the hands-free features, you

must pair your phone and your nüvi.

To pair and connect, your device and

the nüvi must be turned on and near

each other.

Pairing Your Phone

1. Enable the Bluetooth component

on your phone.

2. On your nüvi, touch Tools >

Settings > Bluetooth.

3. Touch the button below Bluetooth,

and touch Enabled >OK.

4. Touch the button below Phone.

5. Select your phone, and touch OK.

6. Enter the Bluetooth PIN (1234) for

your nüvi in your phone.

Calling a Number

1. From the Main menu, select

Phone > Dial.

2. Enter the number, and touch Dial.

3. To end a call, touch > End

Call.

Receiving a Call

When you receive a call, the

Incoming Call window opens.

• Touch Answer to answer the call.

• Touch Ignore to ignore the call

and stop your phone from ringing.

Charging Your nüvi

• Connect the vehicle power cable.

• Connect the USB cable.

• Connect an AC adapter (optional

accessory).

Starry Liu, 11643, 2010/09/27

nüvi 1360 Quick Start Manual 7

Securing Your nüvi

1. Ensure that you are at your

security location and that your nüvi

is receiving satellite signals.

2. Touch Tools > Settings >

Security.

3. Touch the button below Garmin

Lock.

4. Enter a four-digit PIN.

5. Touch Set.

NOTE: If you forget your PIN and

your security location, you must

send your nüvi to Garmin to get

it unlocked. You must also send a

valid product registration or proof

of purchase.

More Information

For more information about your

nüvi, select Tools > Help. Download

the latest version of the owner’s

manual from www.garmin.com.sg.

For information on accessories, go to

http://buy.garmin.com or contact your

Garmin dealer.

Garmin

, the Garmin logo, and nüvi

are

trademarks of Garmin Ltd. or its subsidiaries,

registered in the USA and other countries. Garmin

Lock

™

is a trademark of Garmin Ltd. or its

subsidiaries. These trademarks may not be used

without the express permission of Garmin. The

Bluetooth

word mark and logos are owned by the

Bluetooth SIG, Inc., and any use of such name by

Garmin is under license. microSD

™

is a trademark

of SanDisk or its subsidiaries.

Starry Liu, 11643, 2010/09/27

May 2010 190-01050-2D Rev. A Printed in Taiwan

Garmin International, Inc.

1200 East 151st Street, Olathe, Kansas 66062, USA

Garmin (Europe) Ltd.

Liberty House, Hounsdown Business Park, Southampton, Hampshire, SO40 9LR UK

Garmin Corporation

No. 68, Jangshu 2nd Road, Sijhih, Taipei County, Taiwan
