Fujitsu AMILO Li 3910 User manual
Consumer Notebook
First-time setup
AMILO Notebook Li 3710 / Li 3910
Copyright
© Fujitsu Technology Solutions 2009
Published by
Fujitsu Technology Solutions GmbH
Mies-van-der-Rohe-Straße 8
80807 München, Germany
Contact
http://ts.fujitsu.com/support
All rights reserved, including intellectual property rights.
Technical data subject to modifi cations and delivery subject
to availability. Any liability that the data and illustrations are
complete, actual or correct is excluded. Designations may be
trademarks and/or copyrights of the respective manufacturer,
the use of which by third parties for their own purposes may
infringe the rights of such owner. For further information see
http://ts.fujitsu.com/terms_of_use.html
1
2
2
1
10 601087302
English
Ελληνικά
עברית
Türkçe
SAP: 10601087302
FSP: 440N00791
AMILO-Notebook-Cover_s-w_XS021.i1 1 27.05.2008 11:16:45
3
4
5
6 W-LAN on/off
w
w
w
1
2
2x
AMILO
CAM
8-"/
AMILO-Notebook-Cover_s-w_XS021.i2 2 27.05.2008 11:16:45
AMILO Notebook
Li 3710 / Li 3910
First-time setup
English
Ελληνικά
Türkçe
ﺔﻴﺑﺮﻌﻟا ﺔﻐﻠﻟا
תירבע
Microsoft, MS Windows and Windows Vista are registered trademarks of the Microsoft Corporation.
Adobe Reader is a trademark of Adobe Systems Incorporated.
MultiMediaCard is a registered trademark of Infineon Technologies AG
Sony and Memory Stick are registered trademarks of Sony Electronics, Inc.
All other trademarks referenced are trademarks or registered trademarks of their
respective owners, whose protected rights are acknowledged.
Copyright © Fujitsu Technology Solutions GmbH 2009
All rights reserved, including rights of translation, reproduction by printing, copying
or similar methods, either in part or in whole.
Non-compliance is subject to compensation for damages.
All rights reserved, including rights created by patent grant or registration of a utility model or design.
Subject to availability and technical modifications.
Contents
English
Contents
Innovativetechnology ................................................................. 1
Notational conventions .................................................................. 2
Furtherinformation ...................................................................... 3
"AMILO Notebook" Operating Manual . . . . . ............................................ 3
PortsandOperatingElements ......................................................... 4
AMILO Notebook Li 3710 . . . . . ........................................................... 4
AMILO Notebook Li 3910 . . . . . ........................................................... 5
Importantnotes ........................................................................ 6
Helpifproblemsoccur ................................................................... 6
Preparingyournotebookforuse ....................................................... 7
Unpacking and checking your notebook ................................................... 7
Selectingthelocation ................................................................... 8
Connecting the mains adapter ........................................................... 8
Switching the notebook on for the firsttime ................................................ 9
Application buttons (only for AMILO Notebook Li 3910) . .................................... 10
Allocatingtheapplicationbuttons .................................................... 10
Technical specification ................................................................. 11
Notebook . . . . . .......................................................................... 11
Mains adapter .......................................................................... 11
10601087302, edition 1 English
Contents
English 10601087302, edition 1
Innovative technology
Innovative technology
... and ergonomic design make your AMILO Notebook Li 3710 / Li 3910 a
user-friendly and reliable notebook.
If you have purchased a notebook with a Microsoft Windows operating system, this
is already pre-installed and optimally configured for you. The notebook is immediately
ready to use, as soon as you switch it on for the first time.
Your notebook features the very latest technology so that you get the best
performance from your computing experience.
• a drive for reading and writing CDs/DVDs
• three USB ports, providing simple expansion options for game pads, printers and other equipment
• LAN and Wireless LAN for Internet and network access
• a VGA monitor port for an external monitor
• an integrated webcam and a microphone for the widest variety of multimedia applications
• a multi-format card reader for rapid transfer of digital photos, music and
video clips onto your notebook
• an onboard sound card and stereo loudspeakers for your audio enjoyment
• in addition, input and output ports for high-quality audio accessories
• a keyboard with a separate numeric keypad (only AMILO Notebook Li 3910)
• an on-screen display for visually checking the most important settings of your notebook
With the user-friendly "BIOS Setup Utility" you can control your notebook’s hardware and better
protect your system against unauthorised access by using the powerful password properties.
This Operating Manual tells you how to get your AMILO notebook up and
running and how to operate it in daily use.
10601087302, edition 1 English - 1
Innovative technology
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
this warning will endanger your life, will damage the device or lead to loss
of data. The warranty will be invalidated if you cause defects in the device
through failure to take notice of this warning
indicates important information that is required to use the device properly.
►indicates an activity that must be performed in the order shown
indicates a result
This style flags data entered using the keyboard in a program dialog or command
line, e.g. your password (Name123) or a command to launch a program
(start.exe)
This style refers to information displayed by a program on the screen, e.g.:
Installation is completed
This style is for
• terms and texts in a software user interface, e.g.: Click Save.
• names of programs or files, e.g. Windows or setup.exe.
"This style" is for
• cross-references to another section, e.g. "Safety information"
• cross-references to an external source, e.g. a web address: For more
information, go to "http://ts.fujitsu.com"
• indicates names of CDs and DVDs as well as names and titles of other
materials, e.g.: "CD/DVD Drivers & Utilities" or "Safety" manual
Abc refers to a key on the keyboard, e.g.: F10
This style flags concepts and text that are emphasised or highlighted, e.g.: Do not
switch off device
2 - English 10601087302, edition 1
Innovative technology
Further information
You will find general information on your AMILO Notebook in the
"AMILO Notebook" operating manual.
You will find the Windows Vista drivers for your AMILO Notebook on our
Internet website. When in the factory this device did not support any other
operating system. Fujitsu Technology Solutions does not accept any liability
whatsoever if any other operating system is used.
Software oriented components of these instructions refer to Microsoft products, if
they come within the scope of the delivery of your AMILO Notebook.
If you install other software products, pay attention to the operating
instructions of the producer.
"AMILO Notebook" Operating Manual
The operating instructions for the "AMILO Notebook" will be found in the Windows Start
menu or on the Internet under "http://ts.fujitsu.com/support".
10601087302, edition 1 English - 3
Ports and Operating Elements
Ports and Operating Elements
This chapter presents the individual hardware components of your notebook. You can
obtain an overview of the displays and connections of the notebook. Please familiarise
yourself with these items before you start to work with your notebook.
AMILO Notebook Li 3710
14
13
1
3
65
11
21
2
4
7
8
9
17
15
1210
18
22
15
16
11
19 20
14
1 = Webcam
2 = Touchpad
3 = Keyboard
4 = Status indicators
5 = Touchpad buttons
6 = Multi-format card reader
7 = Line-in socket
8 = Microphone port
9 = Headphones / SPDIF / Line-out port
10 = ExpressCard slot
11 = USB port
12 = Network port
13 = Monitor port (VGA)
14 = Ventilation slots
15 = Loudspeakers
16 = ON/OFF switch
17 = Microphone
18 = CD/DVD drive
19 = Kensington Lock
20 = DC input connector (DC IN)
21 = Battery
22 = Service compartment, memory
and hard disk
4 - English 10601087302, edition 1
