Fujitsu Siemens Computers SCALEOVIEW L19-1W User manual

Monitor

Erste Schritte / Getting Started

Deutsch, English, Français,

Español, Português,

Italiano, Svenska,

Nederlands, Dansk, Suomi,

Pycckий, Norsk, Eesti keel,

Ελληνικά, Lietuviškas,

Latviski, Polski, Slovensko,

Slovenský, Česky, Magyar

SCALEOVIEW

L19-1W / L22-1W

Downloaded from ManualMonitor.com Manuals

Sie haben ...

... technische Fragen oder Probleme?

Wenden Sie sich bitte an

unseren Help Desk (siehe Garantieheft).

Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw. finden Sie im Internet:

http://www.fujitsu-siemens.com

Are there ...

... any technical problems or other questions you need clarified?

Please contact

our Help Desk (see Warranty Booklet).

The latest information on our products, tips, updates, etc., can be found on the Internet under:

http://www.fujitsu-siemens.com

Downloaded from ManualMonitor.com Manuals

SCALEOVIEW L19-1W / L22-1W

⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯

Technical data

Dimensions and weight L19-1W L22-1W

Visible diagonals: 48 cm (19”)

Screen size : 410 mm x 256 mm

Dimensions (W x H x D)

incl. monitor base : 433 mm x 360 mm x 221.6 mm 514 mm x 418 mm x 219.5 mm

Dimensions box (W x H x D): 415 mm x 415 mm x 160 mm 560 mm x 140 mm x 490 mm

Weight : approx. 5,5 kg / 6,0 kg approx. 6.1 kg / 6.7 kg

Dot pitch : 0,285 mm 0,282 mm

Maximal resolution : 1440 x 900 pixels 1680 x 1050 pixels

Electical data

Video: analogue, positiv, 0.7 Vpp, 75 Ω, digital, DVI-D

Synchronisation : Seperate Synch. TTL, positive or negative

Horizontal frequency: 30 kHz …. 82 kHz

Refresh rate: 50 Hz …. 75 Hz

Maximum pixel rate: 140 MHz

Power supply: switches automatically

100 V – 240 V, 50 Hz – 60 Hz, 1.0 A max.

Total power consumption: < 60 W < 55 W

< 2 W < 2 W in the energy-saving modes

(standby mode, suspend

mode

and Off mode)

Environmental conditions

Environment class 3K2, IEC 721

Operating range: 5 °C …. 35°C

Humidity: 20 % …. 85 %

Condensation must be avoided.

Preset operating modes

The picture position and size have been set set to optimum values at the factory for the

operating modes listed above.

Horizontal frequency Refresh rate Display resolution

31.5 kHz

37.5 kHz

37.9 kHz

46.9 kHz

48.4 kHz

60.0 kHz

64.0 kHz

79.9 kHz

56.0 kHz

70.6 kHz

70 Hz

60 Hz

75 Hz

60 Hz

75 Hz

60 Hz

75 Hz

60 Hz

75 Hz

60 Hz

70 Hz

720 x 400

640 x 480

800 x 600

1024 x 768

1280 x 1024

1440 x 900

Downloaded from ManualMonitor.com Manuals

65.3 kHz 60 Hz 1680 x 1050

Downloaded from ManualMonitor.com Manuals

Dieses Handbuch wurde erstellt von

cognitas. Gesellschaft für Technik-Dokumentation mbH – www.cognitas.de

Herausgegeben von/Published by

Fujitsu Siemens Computers GmbH

Printed in Taiwan

AG 0706 07/06

Ausgabe/Edition 1

Bestell-Nr./Order No.: A26361-K1128-Z200-1-M119

Edition 1

Downloaded from ManualMonitor.com Manuals

SCALEOVIEW

L19-1W / L22-1W

Erste Schritte

Getting Started

Deutsch

Magyar

Русский

English

TCO

Norsk

Français

WEEE

Eesti keeles

Español

Ελληνικά

Português

Lietuviškas

Italiano

Latviski

Svenska

Polski

Nederlands

Slovensko

Dansk

Slovenský

Suomi

Česky

Ausgabe Juli 2006

July 2006 edition

Downloaded from ManualMonitor.com Manuals

VESA, DDC und DPMS sind eingetragene Warenzeichen der Video Electronics Standards

Association.

Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.

Zuwiderhandlungen verpflichten zu Schadenersatz.

Liefermöglichkeiten und technische Änderungen vorbehalten.

VESA, DDC and DPMS are registered trademarks of Video Electronics Standards

Association.

All rights, including rights of translation, reproduction by printing, copying or similar methods,

even of parts are reserved.

Offenders will be liable for damages.

All rights, including rights created by patent grant or registration of a utility model or design,

are reserved.

Delivery subject to availability. Right of technical modification reserved.

Downloaded from ManualMonitor.com Manuals

Ausgabe 1 Deutsch

Inhalt

Einleitung.............................................................................................................................................. 1

Weitere Informationen .................................................................................................................. 1

Wichtige Hinweise ................................................................................................................................ 2

Sicherheitshinweise...................................................................................................................... 2

Netzleitung ................................................................................................................................... 2

Transport ...................................................................................................................................... 2

Reinigung ..................................................................................................................................... 2

CE-Kennzeichnung ...................................................................................................................... 2

Überprüfen der Lieferung ..................................................................................................................... 2

Anschließen des Bildschirms ............................................................................................................... 2

Bedienen des Bildschirms .................................................................................................................... 2

Fehlerbehandlung................................................................................................................................. 2

Montage des Bildschirmfußes .............................................................................................................. 2
