Fujitsu Siemens Computers AMILO Pi 3525 User manual

Issue January 2009

Version 3

AMILO Notebook Pi 3525

The perfect all-round

notebook Pages 6

The AMILO Notebook P Series combines versatile performance, great technology and a fascinating design.

Processor technology

Latest Intel® Centrino® 2 processor technology1(optional) for high-definition digital

entertainment experience, blistering performance, longer-lasting battery life and the

new wireless standard for connectivity

Operating System

Windows Vista® Home Premium

Mobility

Standard 15.4-inch form-factor that fits in almost every bag

Optional with integrated draft-n Intel® WiFi Link 5100 AGN to go online when and

wherever you want

Entertainment and Multimedia

The integrated AMILOcam with low-light technology for great video-quality even in

low-light conditions and the built-in array microphone are perfect for Internet telephony

(VoIP) and video chats

LCD WXGA display with BrilliantView technology for vivid colors, amazing sharpness

and impressive contrast

Enjoy your favorite Hollywood blockbuster on an external display via DVI-I (with

HDCP support)

More convenience thanks to

The spill-proof keyboard2that protects your notebook against accidentially spilt liquids

The silent mode function that causes a noticeable reduction in fan noise

The built-in DVD drive to store and secure data comfortably on the move

Model: Reveal white

Model: Eclipse black

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Pi 3525 Page 2 / 6

Fujitsu Siemens Computers recommends Windows Vista® Home Premium

Operating systemand Recovery

Operating system Genuine Windows Vista® Home Premium (32-bit version)

Fujitsu Siemens Computers Recovery Program Backup and restore the original status of the hard disk and create system

restore disks

or individual recovery media on CD or DVD are included

Product design

Color Reveal white or eclipse black

Architecture

System architecture Intel® Centrino® 2 processor technology (optional)1

Chipset Intel® GM45 + ICH9M

Processors3

Intel® Core™2 Duo processors P7350 (2.0 GHz, 1066MHz FSB, 3MB L2 cache)

P7450 (2.13 GHz, 1066 MHz FSB, 3 MB L2 cache)

P8400 (2.26 GHz, 1066MHz FSB, 3MB L2 cache)

P8600 (2.4 GHz, 1066MHz FSB, 3MB L2 cache)

T5800 (2.0 GHz, 800 MHz FSB, 2 MB L2 cache)

T5900 (2.2 GHz, 800 MHz FSB, 2 MB L2 cache)

T6400 (2.0 GHz, 800 MHz FSB, 2 MB L2 cache)

T6600 (2.2 GHz, 800 MHz FSB, 2 MB L2 cache)

Intel® Pentium® processor T3200 (2.0 GHz, 677 MHz FSB, 1MB L2 cache, dual-core)

T3400 (2.16 GHz, 667 MHz FSB, 1 MB L2 cache, dual-core)

Memory 2 SO-DIMM memory slots (no memory on board)

Memory speed 800 MHz

Memory type DDR 2 RAM

Memory modules 1024 or 2048 MB

Max. memory size3,4 4096 MB

Drives

Hard disk drive

HDD type SATA

HDD size 2.5-inch

HDD speed 5400 rpm

HDD cache 8 MB

HDD capacity3160, 250, 320 or 500 GB

Optical disc drive(built-in)

ODD type SATA

ODD technology SuperMulti-format DVD burner with double layer (DL) support

ODD read speed CD-ROM 24x, DVD-ROM 8x

ODD write speed CD-R 24x, CD-RW 16x, DVD+R 8x, DVD-R 8x, DVD+RW 8x,

DVD-RW 6x, DVD+R DL (8.5 GB) 4x, DVD-R DL (8.5 GB) 4x,

DVD-RAM 5x

Display

Display type BrilliantView LCD

Display size 15.4-inch

Display resolution (intern) 1280 x 800 pixels

Display resolution (extern) 1920 x 1200 pixels

Resolution type WXGA

Reaction time 16 ms

Brightness (typ.) 200 NIT

Contrast (typ.) 400 : 1

Compliance with standards ISO 13406-2 class II

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Pi 3525 Page 3 / 6

Fujitsu Siemens Computers recommends Windows Vista® Home Premium

Graphics

Dedicated graphics (full name) -

Dedicated video memory -

Onboard graphics chip Mobile Intel® Graphics Media Accelerator 4500MHD

Shared video memory5Up to 1292 MB shared memory

3D Benchmark 2006 Up to 840 points6(depending on configuration)

Graphic features DirectX® 10 support

Supporting full HD video experience

Interfaces

Video 1x DVI-I (incl. HDCP support)

Audio 1x line in, 1x microphone in, 1x line out / headphone out combined with

S/PDIF out

Network 1x LAN (RJ-45)

Data 1x eSATA combined with USB, 2x USB 2.0

1x ExpressCard slot (54 / 34 mm)

1x 15-in-1 card reader7

SD, miniSD, MicroSD, SDHC

MS, MS-Duo

MMC, RS-MMC, MMC-Micro

MSPRO, MS-PRO Duo, MS-Pro HG, MS-Pro HG Duo, M2

xD picture card

Power supply 1x DC-in

Communication

Integrated Bluetooth® -

LAN (Local Area Network) 10 / 100 Mbps

Built-in WLAN (Wireless Local Area Network) Yes

WLAN brand name Intel® WiFi Link 5100 AGN

WLAN type3draft-n 802.11a/g/n

WLAN max. date rate Up to 300 Mbps

WLAN encryption WEP, WPA and WPA2

For use in BE, CH, DK, DE, EE, FI, FR, EL, IE, IS, IT, LI, LV, LT, LU, MT, NL, NO,

PL, AT, PT, SE, SK, ES, CZ, HU, UK, CY

Option3

WLAN type 802.11b/g

WLAN max. date rate Up to 54 Mbps

WLAN encryption WEP, WPA and WPA2

For use in BE, CH, DK, DE, EE, FI, FR, EL, IE, IS, IT, LI, LV, LT, LU, MT, NL, NO,

PL, AT, PT, SE, SK, ES, CZ, HU, UK, CY

Multimedia

Audio Support of high-definition audio for S/PDIF output with up to 7.1 channels

Audio chip Realtek ALC662

Speakers 2x built-in speakers (1.5 W each)

Microphone Built-in array microphone

Subwoofer -

Input device Volume control via function key combination

AMILOcam

Image sensor VGA webcam

Frames per second 308

Features Auto focus

Automatic brightness adjustment with status LED (blue: on, red:

streaming / application on)

Low-light technology for great video-quality even in dark

surrounding

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Pi 3525 Page 4 / 6

Fujitsu Siemens Computers recommends Windows Vista® Home Premium

Input devices / Control buttons

Power button Located left of the keyboard, black-lighted

Keyboard Spill-proof keyboard2with 85 keys

Touchpad Hidden touchpad, with left and right mouse button,

touchpad disable function via function key combination (Fn+F6)

Multimedia keys Located on top of the keyboard to launch the following applications:

Silent mode (reduce noise level / fan speed, by reducing the CPU

performance, office applications, Internet and DVD playback are not

affected)

DVD playback

Internet browser

Hot keys The following hot keys or key combinations are available

Fn+F1 WLAN on / off

Fn+F3 Mute on / off

Fn+F4 Volume down

Fn+F5 Volume up

Fn+F6 Touchpad on / off

Fn+F7 AMILOcam on / off

Fn+F8 Brightness down

Fn+F9 Brightness up

Fn+F10 Display switch

Fn+F11 Silent mode

Fn+F12 Suspend

Status indicators The notebook has 3 status icons:

Power status (& suspend)

Blue (always on): on; Blue blinking: stand by; None: off

WLAN

Blue: on; None: off

Battery charge

Blue (always on): full; Blue blinking: charging;

Red blinking: < 10 % capacity

Security

Supervisor and user password Yes

Kensington lock Yes

Lid switch (hidden) Yes

ACPI functions ACPI 3.0 compliant for Vista requirement

Power on stand by (S1 LCD off)

Stand by / energy saving mode (S3 save to RAM)

Hibernate mode (S4 save to disk)

Off mode (S5 soft off)

Power System

Battery9

Battery type Lithium-Ion battery

6 cells, 10.8 V / 2200 mAh (cell) / 4400 mAh (pack) or

6 cells, 11.1 V / 2400 mAh (cell) / 4800 mAh (pack)

Battery life (idle mode)10 Up to 3:45 hours

Battery life (DVD Playback)11 Up to 1:45 hours

Battery charging time (idle mode)12 Up to 1:40 hours (charging 90%)

Battery charging time (DVD playback)13 Up to 2:20 hours (charging 90%)

Battery charging time (off mode) Up to 2:00 hours (charging 90%)

AC Adapter Dynamic charge supported, ACPI 3.0 supported

Wide Range AC adapter 110 - 240 V AC, 50 - 60 Hz

Output 65 W with 20 V DC, 3.25 A

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Pi 3525 Page 5 / 6

Fujitsu Siemens Computers recommends Windows Vista® Home Premium

Energy consumption

S0 (idle mode) 19 W

S0 (max. active mode)14 48.6 W

S3 (stand by / energy saving mode) 2.3 W

S4 (hibernate) 0.8 W

S5 (off mode) 0.7 W

Noise emission

Idle mode15 19 dB(A) (silent mode off)

Maximum active mode16 28 dB(A) (silent mode off)

Operating conditions

Operational 5 °C to 35 °C (ambient temperature)

10 % to 90 % relative humidity, non-condensing

Dimensions and weight

W x D x H 358 x 256 x 37.0 (front) / 41.0 (back) mm

Weight 2.9 kg17

Certifications GOST (WLAN)

CE Marking

R&TTE (WLAN)

Warranty Country specific terms

Application Software

Home office Microsoft® Works

Microsoft® Office Home and Student Trial

Adobe Reader

Windows Mail (within Vista operating system)

Windows Calendar (within Vista operating system)

Multimedia Nero Essentials S (CD / DVD write software)

Vista DVD Playback Pack (DVD playback software)

Windows Media Player (within Vista operating system)

Windows Media Center (within Windows Vista® Home Premium

operating system)

Internet Microsoft® Internet Explorer

Country specific Internet provider

Security Norman security software solution

Data Sheet ⏐Issue: January 2009⏐AMILO Notebook Pi 3525 Page 6 / 6

Fujitsu Siemens Computers recommends Windows Vista® Home Premium

delivery subject to availability. Any liability that the data and illustrations are complete, actual or

correct is excluded.

Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which

by third parties for their own purposes may infringe the rights of such owner.

For further information see http://www.fujitsu-siemens.com/terms_of_use.html

Published by

FSC IP CLI PMKT

Christiane Geis

Fujitsu Siemens Computers

http://www.fujitsu-siemens.com/

Company stamp

Accessories

Included AC adapter 65 W

First Battery (6 cells battery)

Optional Find out more: www.fujitsu-siemens.com/accessories

Manuals Manual (on hard disk), quick start guide, safety guide, warranty guide,

recovery guide

Drivers Updates downloadable at http://www.fujitsu-siemens.com

Awards

Notebookjournal.de

Germany – 09/2008

“Good”

Connect

Germany – 11/2008

“Good”

Computer Bild

Germany – 12/2008

Test winner

1The processor technology depends on the actually installed processor.

2DISCLAIMER: The keyboard is spill-proof up to 50ml. This is enough to protect your notebook from an accidental spill. However, we recommend a backup as well

as a system shut-down should liquids come into contact with the keyboard. The spill-proof protection does not prevent data loss caused by water damage. If this

should happen, please contact your local customer service desk.

3Depending on exact configuration. Please check at your local retailer

4DISCLAIMER: Up to 1 GB may not be available with 32-bit operating systems due to system resource requirements if system is preinstalled with 4096 MB RAM

5Shared video memory size may vary depending on configuration. Used video memory size depends on Microsoft® Windows Vista® memory management

- 1024 MB system memory enables up to 268 MB static and shared memory

- 2048 MB system memory enables up to 779 MB static and shared memory

- 3072 MB system memory enables up to 1292 MB static and shared memory

- 4096 MB system memory enables up to 1292 MB static and shared memory

6Configuration for measurement: Intel® Core™2 Duo T9400 processor, 4 GB RAM, 250 GB HDD; display resolution: 1280 x 1024

7An adapter is needed for the following card formats: RS-MMC, MMC-Micro, miniSD, MicroSD, SDHC, MS-Duo, MS-PRO Duo, MS-Pro HG, MS-Pro HG Duo, M2

8AMILOcam frame rate can vary significantly depending on the used software application.

9DISCLAIMER: Battery life may vary depending on product model, configuration, applications, power management settings and features utilized. Recharge time

varies depending on usage. The recharge capacity may decrease after some months so that the battery lifetime as well as operating time can not be assured for the

whole lifetime of the notebook

10 Tested with Battery Mark 4.0.1 (“power saver mode”)

11 DVD playback tested with Vista DVD playback

12 Tested with BatteryMon, V2.0 Build:1007

13 DVD playback tested with Vista DVD playback

14 Tested with 3DMark06

15 Tested with idle mode (according to ISO 7779:2001 Nr. C.15.3.1) noise emission values according to ISO 9296 at operator position

16 Tested with HDD stress test and CPU stress text at approx. 90 % CPU load, no ODD load, noise emission values according to ISO 9296 at operator position

17 Weight may vary depending on actual configuration

The configuration described in this document is generic only and non-binding. For the exact

configuration of your AMILO, please contact your licensed dealer.

Other Fujitsu Siemens Computers Laptop manuals

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Xi Series Product information sheet

Fujitsu Siemens Computers

Fujitsu Siemens Computers LIFEBOOK P Series Product information sheet

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Xa 1526 Product information sheet

Fujitsu Siemens Computers

Fujitsu Siemens Computers LIFEBOOK S Series Product information sheet

Fujitsu Siemens Computers

Fujitsu Siemens Computers answers 2 LIFEBOOK C Series User manual

Fujitsu Siemens Computers

Fujitsu Siemens Computers Siemens AMILO L Series Product information sheet

Fujitsu Siemens Computers

Fujitsu Siemens Computers Amilo Si 2654 User manual

Fujitsu Siemens Computers

Fujitsu Siemens Computers Amilo L1310G User manual

Fujitsu Siemens Computers

Fujitsu Siemens Computers WF2H Product information sheet

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO M Series User manual

Fujitsu Siemens Computers

Fujitsu Siemens Computers V3525 User manual

Fujitsu Siemens Computers

Fujitsu Siemens Computers LIFEBOOK T Series Product information sheet

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Desktop L Series User manual

Fujitsu Siemens Computers

Fujitsu Siemens Computers LIFEBOOK P Series Product information sheet

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Pa series Product information sheet

Fujitsu Siemens Computers

Fujitsu Siemens Computers CELSIUS H250 Product information sheet

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Li Series Product information sheet

Fujitsu Siemens Computers

Fujitsu Siemens Computers Lifebook C Series User manual

Fujitsu Siemens Computers

Fujitsu Siemens Computers ESPRIMO U Series User manual

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Li Series Product information sheet

Fujitsu Siemens Computers

Fujitsu Siemens Computers LIFEBOOK P7120 User manual

Fujitsu Siemens Computers

Fujitsu Siemens Computers ESPRIMO Mobile D9500 Product information sheet

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Xi 3650 User manual

Fujitsu Siemens Computers

Fujitsu Siemens Computers AMILO Pro V3205 User manual

Popular Laptop manuals by other brands

HP ze2401xt - Pavilion Notebook PC datasheet

Velocity

Velocity NoteMagix M10 quick start guide

Dell

Dell Alienware 17 R2 Service manual

Toshiba

Toshiba A105-S2236 Specifications

HP ENVY 17 Maintenance and service guide

Winbook

Winbook LM user guide

Dell

Dell Inspiron 1464 Setup guide

Dell

Dell Inspiron 15R 5537 quick start guide

HP PROBOOK 4520S Maintenance and service guide

Dell

Dell Latitude ATG D620 Service manual

Sony

Sony VAIO PCG-FX270 Specifications

Dell

Dell Latitude 7310 Service manual

Dell

Dell Precision GU806 Quick reference guide

Sony

Sony VAIO PCG-R505JLK user guide

Lenovo

Lenovo THINKPAD X32 Setup guide

HP Compaq tc4200 Software guide

Toshiba

Toshiba mini NB300 specification

Lenovo

Lenovo ThinkPad X201 Tablet Manual
