Frigidaire FRS23SM4A User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS

FRS23SM4AW0 FRS23SM4A R134a white 115

MARKET

North America

Publication No.

5995368106

020312

-EN/SERVICE/KHB

357

SIDE BY SIDE

REFRIGERATOR

Model No.

FRS23SM4A

WIRING DIAGRAM - 240389604

OWNER’S GUIDE - 240389303

SERVICE DATA SHEET - 240389604

ELECTROLUX HOME PRODUCTS, INC

P.O. BOX 212378, Augusta, GA 30917

FACTORY

PARTS CATALOG

03/02 2

Publication No. FRS23SM4AW0

5995368106

FREEZER DOOR

# = Fast-moving Parts 3 03/02

* = Non-Illustrated Parts

FRS23SM4AW0 Publication No.

5995368106

FREEZER DOOR

POS. NO PART NO DESCRIPTION

1 240390604 Gasket-door,white

4A 240367301 Bin-door,frzr-upper

4B 240359001 Bin-door

11 240451880 Door-frzr,white ,complete assy

13A 240456902 Door Stop,white ,frzr

18 218762701 Handle-door,white

21A 5308016566 Screw,hex washer head ,8-15A x 0.625, low profile

21C 218781100 Screw,pan head ,8-18 x 0.625

22A 240328202 Bearing-hinge,closer

22C 240328402 Bearing-hinge,upper

37 218811618 Trim-handle,white ,upper

37* 218676004 Band-decorative, satin aluminum, handle trim

37A 218811615 Trim-handle,white ,lower

37A* 215782300 Lock-handle trim,snap-in

68 240465801 Chute-ice

96 240345505 Plug,door foam hole ,white

* 240323201 Wiring Harness

* 240352101 Connector-water,straight

* 5303918256 Dispenser heater kit

03/02 4

Publication No. FRS23SM4AW0

5995368106

REFRIGERATOR DOOR

# = Fast-moving Parts 5 03/02

* = Non-Illustrated Parts

FRS23SM4AW0 Publication No.

5995368106

POS. NO PART NO DESCRIPTION

2 # 240390603 Gasket-refr door,white ,magnetic

4 240363701 Bin-door,2-liter

7 240338303 Door,dairy ,clear

13 240456901 Door Stop,white ,ref

15 240451947 Door-refr,white ,complete assy

18 218762701 Handle-door,white

21A 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile

21C 218781100 Screw,pan head ,8-18 x 0.625

22 240328201 Bearing-hinge,closer

22B 240328401 Bearing-hinge,upper

37 218811618 Trim-handle,white ,upper

37* 218676004 Band-decorative, satin aluminum, handle trim

37A 218811615 Trim-handle,white ,lower

37A* 215782300 Lock-handle trim,snap-in

49 240324501 Bin-door,gallon

96 240345505 Plug,door foam hole ,white

REFRIGERATOR DOOR

03/02 6

Publication No. FRS23SM4AW0

5995368106

CABINET

# = Fast-moving Parts 7 03/02

* = Non-Illustrated Parts

FRS23SM4AW0 Publication No.

5995368106

POS. NO PART NO DESCRIPTION

10 240435901 Cover-air duct

10A 240475901 Cover-evap coil,lower

11 5303208309 Plug-hole,factory test

14 # 240413601 Switch,light/lamp ,rocker

14A# 215486600 Switch-light/lamp

21C 218252200 Screw,#8 truss hd ,10-32CA x 0.500

22 240457701 Plate-door closer

23 240402701 Screw-#10-32 x 1/4 flat hd

28 240335501 Bolt-roller adj,hex washer head, 1/4-20 x 4.020,(2),special

30 240419103 Bracket-lower hinge, ref

30A 240419104 Bracket-lower hinge

37 240337601 Trim-cabinet corner,white ,(2)

38 240327202 Bracket-upper hinge

40 240327001 Cover-upper hinge,white

41 240358701 Grommet-shelf mtg,1.40" long

41* 240358801 Grommet-shelf mtg,.875" long

42 240315301 Screw-hinge mtg,hex head ,1/4-20 x 0.75

43 240335003 Roller Assy,front ,(2)

45 241500301 Screw,hex washer head ,8-18AB x 0.500

47 218659500 Channel-shelf mtg,side ,(2)

58 218749600 Screw,#10 pan hd ,8-18 x .5

66B 240374301 Diffuser-air

66B* 240518802 Pin-push,push-in ,plastic

72 240324401 Grille/Kickplate,white

81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile

82 5304418225 Roller,compressor base ,rear ,(2)

83 5303316859 Rivet, flat head, 1/4 OD x 1-3/4, roller pin

89 240326103 Cover,access ,system compt ,with label

90 218249807 Seal-coil cover

91 240380101 Duct-ice maker

92 5303001479 Screw-hinge mtg,hex hd ,1/4-20 x 0.875

100 240423701 Support,crisper cover ,front ,(4)

100* 240350802 Support,crisper cover ,rear ,(4)

150 240368701 Guide-control bulb

* 240396801 Clamp,tube/wiring ,nylon ,black/natural

* 240481601 Shim-lower hinge

* 5303305324 Paint,touch-up ,white

CABINET

03/02 8

Publication No. FRS23SM4AW0

5995368106

SHELVES

# = Fast-moving Parts 9 03/02

* = Non-Illustrated Parts

FRS23SM4AW0 Publication No.

5995368106

POS. NO PART NO DESCRIPTION

2 240434601 Trim-basket

11 240338801 Shelf-freezer,flip-up

11A 240338701 Shelf-freezer,fixed wire

11B 240338703 Shelf-freezer,fixed wire

24 240355211 Shelf-"Spill-Safe",fixed

25 240354501 Cover-crisper pan,upper

25* 240362101 Clip-slide,cover-crisper

25A 240354601 Cover-crisper pan,lower

26 240354705 Pan-crisper,upper

26* 240349801 Clip-slide,pan-crisper

26A 240351101 Control-humidity

27 240354807 Pan-crisper,lower

39 240430705 Trim-shelf,front

39B 240430701 Trim-shelf,front

42 240356501 Hanger-meat pan,RH

42 240365401 Hanger-meat pan,LH

47 240350635 Insert-pan cover,glass

47A 240350614 Insert-pan cover,glass

49 240338401 Basket-sliding

51 240343002 Hanger-basket,RH

52 240343102 Hanger-basket,LH

54 240351901 Plug-hanger,right hand

55 240352001 Plug-hanger,left hand

62 240355506 Pan-meat

81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile

97 240453002 Water Tank Assy,coiled tubing, rear filter

100 240326301 Cover-water tank

101 218493100 Screw, hex washer head, 8-18AB x 1-3/4

123 215005100 Screw-roller/hanger,8-10 x 0.438

126 218867401 Channel,auger mtg ,LH

126 218867402 Channel,auger mtg ,RH

140 240430501 Channel,water tube cvr

SHELVES

03/02 10

Publication No. FRS23SM4AW0

5995368106

CONTROLS
