Frigidaire FGHS2399K Instruction Manual

N58L00003.eps F58FSDEEB1.eps F58RSDAAA0.eps E58BAAAAE0.eps

F58SLDLBH10.eps F58TEBCAE0.eps N58CAAAAC14.eps F58XFAAAA0.eps

N58YDAAAC4.eps N58I115TServo.eps W241912901.eps S241912901.eps

Product No. FPHS2399KF1

Series Professional

Color stainless

Volts 115

Wiring Diagram 241912901

Owner's Guide 241979200

Market North America

Energy Guide 241935569

Service Data Sheet 240389638

P.O. BOX 212378

AUGUSTA, GA 30917

Publication No.

5995538484

09/04/20

(EN/SERVICE/DCS)

137

SIDE-BY-SIDE

REFRIGERATOR

Model No.

FGHS2399K

Publication No: 5995538484 FPHS2399KF1

04/09 2

FREEZER DOOR

22C

13A

22A

21A

79 80

F58FSDEEB1

FPHS2399KF1 Publication No: 5995538484

# Functional Parts 3 04/09

* Non-Illustrated Parts

FREEZER DOOR

POS. NO PART NO. DESCRIPTION

1 241786004 Gasket-frzr door, white, magnetic

4B 240367302 Bin-door, frzr-upper

4C 240358402 Bin-door, frzr-dispenser

5 241545004 Bin-tilt out, tilt-out

11 241993811 Door-frzr, stainless, complete assy

13A 241942604 Door Stop, black, frzr

18 241972501 Handle-door, stainless

21A 240442706 Screw-#10-32 X 3/4, zinc

22A 241990302 Bearing-hinge(frz), closer

22C 241760401 Bearing, hinge, top

79 218755401 Screw-set, 10-32 x 0.375

80 218755504 Screw-shoulder, #10 AB, handle mounting

* 240352102 Connector-water, straight

* 240451503 Screw, ind hex wshr hd, 8-32 x 0.375, trilobe

* 5303918371 Dispenser heater kit, 115

* # 241834703 Harness-wiring, door

Publication No: 5995538484 FPHS2399KF1

04/09 4

REFRIGERATOR DOOR

21A

22B

F58RSDAAA0

27A

FPHS2399KF1 Publication No: 5995538484

# Functional Parts 5 04/09

* Non-Illustrated Parts

REFRIGERATOR DOOR

POS. NO PART NO. DESCRIPTION

2 241786003 Gasket-refr door, white, magnetic

4 240363702 Bin-door, 2-liter

7 240338303 Door, dairy, clear

12 242015101 Label-nameplate

13 241942603 Door Stop, black, ref

15 241837275 Door-refr, stainless, complete assy

18 241972501 Handle-door, stainless

21A 240442706 Screw-#10-32 X 3/4, zinc

22 241990301 Bearing-hinge, gray

22B 241760403 Bearing, hinge, top

27A 241812702 Retainer, tall bottle

49 241808226 Bin-door, gallon, w/trim

49* 241780303 Liner, bin, bin

79 218755401 Screw-set, 10-32 x 0.375

80 218755504 Screw-shoulder, #10 AB, handle mounting

Publication No: 5995538484 FPHS2399KF1

04/09 6

CABINET

72 54

40A

21D

38A

30A

21C

10A

66A

100

E58BAAAAE0

14A

FPHS2399KF1 Publication No: 5995538484

# Functional Parts 7 04/09

* Non-Illustrated Parts

CABINET

POS. NO PART NO. DESCRIPTION

10 240435913 Cover-air duct

10A 241719710 Cover-evap coil, lower

11 5303208309 Plug-hole, factory test

14A# 241547901 Switch-light/lamp, frzr door

21C 218252201 Screw, #8 truss hd, 10-32CA x 0.500

21D 241548003 Screw, 10-32 x 3/8

22 241917801 Plate-door closer

22* 218755402 Screw-set, 10-32 x 0.375

28 240335502 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special

30 241917901 Bracket-lower hinge, RH, w/hinge pin

30A 241917902 Bracket-lower hinge, LH, w/hinge pin

37 240337612 Trim-cabinet corner, nickeloid, (2)

38 241761301 Bracket-upper hinge, RH

38A 241761302 Bracket-upper hinge, LH

40 241946707 Cover-upper hinge, RH

40* 241835801 Harness-wiring

40A 241946708 Cover-upper hinge, LH

40A* 241891901 Harness-wiring, freezer

41 241550801 Grommet-shelf mtg, 1.40" long

41* 241550701 Grommet-shelf mtg, .96" long

42 240578902 Screw, hex head, 1/4-20 x 5/8

43 240335006 Roller Assy, front, (2)

45 241500303 Screw, hex washer head, 8-18AB x 0.500

47 241513001 Channel-shelf mtg, side, (2)

50 242000406 Board-main power

50* 241867901 Harness-wiring

54 241532401 Channel

58 218781101 Screw, pan head, 8-18 x 0.625

66 241756801 Damper-meat keeper

66* 241512807 Seal

66A 241756901 Housing-damper

72 241972905 Grille/Kickplate

81 5304455650 Screw, hex washer head, 8-15A x 0.625, low profile

82 5304418225 Roller, compressor base, rear, (2)

83 5304455655 Rivet, flat head, 1/4 OD x 1-3/4, roller pin

89 241733904 Cover-access, w/label

90 218249807 Seal-coil cover

92 241710601 Screw, hex washer hd, 1/4 x 7/8, hinge mtg

93 241911701 Switch, plunger style

100 240423701 Support, crisper cover, front, (4)

100* 240350802 Support, crisper cover, rear, (4)

* 240396801 Clamp, tube/wiring, nylon, black/natural

* 241781601 Seal-return air

* 241852501 Clip, wiring harness

* 241868101 Air Guide

Publication No: 5995538484 FPHS2399KF1

04/09 8

SHELVES

51A

140

136

126

122

121

120

109

108

107B

101

100

101

52B

52A

51B

49B

49A

47B

47A

26A

25B

25A

24B

F58SLDLBH10

11A

11D

108A

107

FPHS2399KF1 Publication No: 5995538484

# Functional Parts 9 04/09

* Non-Illustrated Parts

SHELVES

POS. NO PART NO. DESCRIPTION

2 241510609 Trim-basket

11A 241992913 Shelf-freezer, glass, upper

11D 241992914 Shelf-freezer, glass, lower

15 241552801 Light Bulb

16 241622802 Socket-light, frz light

16*# 241797601 Harness-wiring

21 5304455658 Screw, hx wshr hd sems, 8-15A x 0.625

24 240350142 Shelf-"Spill-Safe", cantilever, sliding

24B 240424617 Shelf-"Spill-Safe", "Aspect", complete

25 241974201 Cover-crisper pan, upper

25* 240362101 Clip-slide, cover-crisper

25A 241974301 Cover-crisper pan, lower

25B 241973101 Cover-meat pan

26 240354727 Pan-crisper, upper

26* 240349801 Clip-slide, pan-crisper

26A 240351101 Control-humidity

27 240354830 Pan-crisper, lower

39 240367606 Trim-shelf, front

47 241992910 Insert-pan cover, glass

47A 240350614 Insert-pan cover, glass

47B 241992909 Insert-pan cover, glass

49 240564301 Basket-sliding

49A 240530501 Basket-sliding, upper, half

49B 240530503 Basket-sliding, upper, full

51 240343002 Hanger-basket, RH

51A 240395502 Hanger-basket, RH

51B 240579801 Hanger-basket, RH

52 240343102 Hanger-basket, LH

52A 240395602 Hanger-basket, LH

52B 240579802 Hanger-basket, LH

62 241974403 Pan-meat

81 5304455650 Screw, hex washer head, 8-15A x 0.625, low profile

97 241532007 Water Tank

100 240326303 Cover-water tank

101 218493101 Screw, hex washer head, 8-18AB x 1-3/4

107 241753501 Shield-light, refr

107B 241947502 Shield-light, meat pan

108 241513301 Cover-wiring, meat pan light

108A 241753701 Housing-light, upper, fresh food

109 241513202 Base-crisper light socket

120 241740701 Shelf-ice cream

121 241561001 Rail-ice cream shelf, LH

122 241561101 Rail-ice cream shelf, RH

126 241674401 Channel, auger mtg, LH

126 241674402 Channel, auger mtg, RH

136 241657701 Dispenser-can, white

140 241812501 Channel, wtr tube cover

* 241781601 Seal-return air

* 241868101 Air Guide

* 241935559 Energy Guide

Publication No: 5995538484 FPHS2399KF1

04/09 10

CONTROLS

208

137

139

210

210A

209

115

149

F58TEBCAE0
