Frigidaire FGB500CE User manual

PRODUCT NO. FACTORY NO. COLOR MARKET

FGB500CESF 37454412E6016 WHITE U.S.A.

FGB500CESG 37454412E6017 WHITE U.S.A.

FGB500CEBF 37454412E6066 BLACK U.S.A.

FGB500CEBG 37454412E6067 BLACK U.S.A.

GAS WALL OVEN

Model No.

FGB500CE

FACTORY PARTS CATALOG

GAS WALL OVEN

MINUTE

HOUR

TIMER

CLOCK

OVEN

LIGHT

550

500

450

400

350

300

250

200

THERMOSTAT

OFF

WIRING DIAGRAM MODELS (FGB500CESF / FGB500CEBF) #-223059-1020

(FGB500CESG / FGB500CEBG) #-318046303

OWNER’S GUIDE MODELS (FGB500CESF / FGB500CEBF) #-318103401

(FGB500CESG / FGB500CEBG) #-318200900

INSTALLATION INSTR. # - 318064002

FRIGIDAIRE HOME PRODUCTS

7075 ORDAN DRIVE

MISSISSAUGA, ONTARIO

CANADA, L5T 1K6

TEL: (905) 565-9200

Publication No.

5995312062

980923

-EN/SERVICE

377

Publication No. FGB500CE

5995312062

09/98 2

CONTROL PANEL

P22G0019

FGB500CE Publication No.

5995312062

# = Functional Part 309/98

* = Non-Illustrated Part

CONTROL PANEL

A=FGB500CE (FGB500CESF)

B=FGB500CE (FGB500CESG)

C=FGB500CE (FGB500CEBF)

D=FGB500CE (FGB500CEBG)

POS. NO PART NO DESCRIPTION

9 318028021 A B - - Trim-splasher anodized

9 318028020 - - C D Trim-splasher black

12 # 318058910 A-C-Thermostat-oven

12 # 318058911 -B-DThermostat

14 318044602 A B C D Light/Lamp

18 5303310391 A B - - End Cap RH

18 5303280338 - - C D End Cap RH

18 A 5303310389 A B - - End Cap LH

18 A 5303280339 - - C D End Cap LH

19 318129502 A- - - Panel-control white

19 318129504 -B- - Panel-control white

19 318129503 - - C-Panel-control black

19 318129505 ---DPanel-control black

20 # 318011919 A B - - Clock/Timer

20 # 318011918 - - C D Clock/Timer

21 5303271091 A B - - Trim-canopy anodized

21 318056901 - - C D Trim-canopy black

23 318015710 A B C D Bracket

24 # 316005607 A B - - Switch-rocker white

24 # 316005602 - - C D Switch-rocker black

32 318017206 A- - - Knob-thermostat white

32 318016327 -B- - Knob black

32 318017205 - - C-Knob-thermostat white

32 318016326 ---DKnob thermostat black

42 318027300 A B - - Trim-vent anodized

42 318027301 - - C D Trim-vent black

65 5303308466 A B C D Cover-control housing

69 5303323134 A B C D Screw 8-32 X 3/16

72 5303302397 A B C D Housing-control

* 5303311528 - - C D Screw 6-20 X 5/8 black

* 5303308458 A B C D Screw 10-24 X ¼

FGB500CE Publication No.

5995312062

09/98 6

CAVITY / ELEMENTS

14 15

102

121

103

LAP22V0007

58B

100

58C

8376

98A

101 41

104

FGB500CE Publication No.

5995312062

# = Functional Part 709/98

* = Non-Illustrated Part

CAVITY / ELEMENTS

A=FGB500CE (FGB500CESF)

B=FGB500CE (FGB500CESG)

C=FGB500CE (FGB500CEBF)

D=FGB500CE (FGB500CEBG)

POS. NO PART NO DESCRIPTION

2 318101900 A B C D Wrapper

2 A 5303305035 A B C D Shield

4 318161500 A B C D Box-oven burner

6 5303296873 A B C D Rack-oven

8 318121400 A B C D Panel-oven bottom

12 # 5301314211 A B C D Switch-light

14 5308011085 A B C D Socket-light/lamp

15 3201908 A B C D Lamp-oven light

16 3201911 A B C D Glass-oven light lens

17 3204483 A B C D Retainer-lens

25 5303210706 A B C D Shield-insulation

27 5303284616 A B C D Clip thermo-bulb

36 3203725 A B C D Flue

39 # 5303308453 A B C D Cord-electric power

41 3019063 A B C D Retainer-door

54 5303310514 A B C D Housing-oven light

55 3204210 A B C D Shield-flue cover

56 5303308459 A B - - Trim-bodyside white

56 318145508 - - C D Trim-bodyside black

57 5303308476 A B C D Shield-rear wall

58 5303280377 A B C D Insulation

58B 5303304703 A B C D Insulation

58C 318132600 A B C D Insulation

76 318056120 A B C D Front-oven

80 5303301261 A B C D Spring-oven

83 318089400 A B C D Liner-oven assy

86 3201631 A B C D Channel-hinge

87 5303308475 A B C D Bracket-safety valve

97 318066801 A B C D Wrapper-back side

98 318029400 A B C D Trim-side black

98A 318029401 A B C D Trim-side black

99 5303299686 A B C D Support-adjustable

100 5303302715 A B C D Shield-flue

101 5303308474 A B C D Shield-vent

102 3203688 A B C D Support-oven front black

103 5303316734 A B - - Trim-base white

103 5303316735 - - C D Trim-base black

104 3203730 A B C D Adapter-flue

121 318145001 A B C D Wrapper-base

* 5303300195 A B C D Screw 10-32 X 3/8

* 08011955 A B C D Screw 10-24 X 3/8

* 5303311528 - - C D Screw 6-20 X 5/8 black

* 5303320422 A B C D Screw 6-20 X 5/16

Publication No. FGB500CE

5995312062 BURNER

# = Functional Part 401/95

* = Non-Illustrated Part

P22B0008

FGB500CE Publication No.

BURNER 5995312062

# = Functional Part 509/98

* = Non-Illustrated Part

A=FGB500CE (FGB500CESF)

B=FGB500CE (FGB500CESG)

C=FGB500CE (FGB500CEBF)

D=FGB500CE (FGB500CEBG)

POS. NO PART NO DESCRIPTION

14# 5303210167 A B C D Regulator-pressure

17# 3203702 A B C D Valve-safety

18# 5303210787 A B C D Burner-oven

19# 5303308468 ACIgnitor-oven

19# 5303308452 BDIgnitor-oven

20 3203676 A B C D Baffle-oven burner

21 3201885 A B C D Nut lock base

28 5303295305 A B C D Valve-shut off

49 5303308469 A B C D Bracket-safety valve

*3015250 A B C D Insulator, nylon

*08002868 A B C D Screw, 10-24 X 1/2

FGB500CE Publication No.

5995312062

09/98 8

DOOR

LAP22D0013

45A

37 36

FGB500CE Publication No.

5995312062

# = Functional Part 909/98

* = Non-Illustrated Part

DOOR

A=FGB500CE (FGB500CESF)

B=FGB500CE (FGB500CESG)

C=FGB500CE (FGB500CEBF)

D=FGB500CE (FGB500CEBG)

POS. NO PART NO DESCRIPTION

3 318026510 A B C D Trim-oven door

4 5303302707 A B - - Glass-oven door white

4 3202420 - - C D Glass-oven door black

6 318073600 A B C D Shield-air wash

7 5303308470 A B C D Insulation

9 318048400 A B C D Liner-oven door

10 5303311217 A B C D Screw-handle 10-24 X 2 3/16

12 5303316768 A B C D Seal-oven door

16 5303016336 A B C D Glass-oven door

17 318162601 A B C D Spacer-glass

18 5303299723 A B C D Seal-rope

20 318014301 A B - - Spacer-handle white

20 318014300 - - C D Spacer-handle black

23 318074103 A B C D Hinge-oven door

29 5303210003 A B C D Spacer-handle mtg

33 5303308464 A B - - Glass-drawer white

33 3203715 - - C D Glass-drawer black

34 318116000 A B C D Panel-inner drw black

35 318107000 A B C D Drawer-broiler

36 5303935079 A B C D Roller

37 3203722 A B C D Rail-drawer RH

37A 3203723 A B C D Rail-drawer LH

39 316091104 A B - - Handle-door white

39 316091103 - - C D Handle-door black

43 318107800 A B C D Liner-broiler door

44 318088300 A B C D Spring-broiler

45 318024400 A B C D Hinge-broiler

45A 318024401 A B C D Hinge-broiler

46 318126200 A B C D Pan-broiler

47 318126300 A B C D Insert-broiler pan

* 5303308456 A B C D Screw 8-18 X 17/32

* 5303308458 A B C D Screw 10-24 X ¼

Publication No. FGB500CE

5995312062

09/98 10

WIRING DIAGRAM
