Frigidaire FFEW3025L S User manual

frigidaire.com

Drop-In Cooktop

FPEC3085K S

30" Electric

Signature Features

30" Electric

Single Wall Ovens

FFEW3025L S / W/ B

Product Dimensions

Height 29"

Width 30"

Depth 24-1/2"

More Easy-To-Use Features

Keep Warm

Timer Lock-Out

Oven Rack Handles

Oven racks are designed with space for

you to easily pull out the racks, even

when wearing an oven mitt.

Extra-Large Window

Our extra-large oven window lets you

easily see what’s inside.

Bright Oven Lighting

Our bright lighting makes it easy to see

what’s inside.

Delay Clean

Set the oven to begin cleaning on your

schedule.

Delay Bake

Timed Cook Option

Auto Shut-O

As an extra safety measure, the oven

will automatically shut off after 12 hours.

Attractive Stainless Steel

Exterior1

A.D.A. Compliant2

Sabbath Mode (Star-K® Certiﬁed)

Available in:

1Select models only.

2When properly installed, meets the appliance

standards in the Americans with Disabilities Act

and the Architectural Barriers Act Accessibility

Guidelines as published by the United States

Access Board on June 23, 2004, as amended

August 5, 2005.

White

(W)

Stainless

(S)

Black

(B)

Self-Cleaning

Ovens clean themselves — so you don’t

have to.

Vari-Broil™ Option

Allows you to choose between two

heat levels.

Even Baking Technology

Our latest technology ensures even

baking every time.

Ready-Select™ Controls

Easily select options or control

cooking temperature with our

easy-to-use controls.

Accessories information available

on the web at frigidaire.com

Spacer

Single Electric Wall Ovens

Frigidaire Baseline

NOTE: For planning purposes only. Always consult local and national electric codes.

Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.

Cutout Dimensions

Height (Min.)

Height (Max.)

Width (Min.)

Width (Max.)

Depth (Min.)

27-1/4"

28-5/8"

28-1/2"

29"

23-1/2"

Product Dimensions

A - Height

B - Width

C - Depth

D - Height (Wrapper)

E - Width (Wrapper)

Depth with Door Open 90˚

29"

30"

24-1/2"

27-3/16"

28-1/4"

44-1/2"

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Specifications

subject to change.

Single Wall Ovens

FFEW3025L S / W/ B 30" Electric

1When properly installed, meets the appliance standards in the

Americans with Disabilities Act and the Architectural Barriers Act

Accessibility Guidelines as published by the United States

Access Board on June 23, 2004, as amended August 5, 2005.

2Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz AC

only electrical supply with ground required on separate circuit fused on

both sides of line.

Features

Oven Control / Timing System

Window

Exterior Door Finish

Handle Design

Oven Cleaning System

Oven Controls

Bake / Broil

Convection Conversion

Convection Bake / Broil / Roast

Quick Bake Convection

PowerPlus™ / Quick Preheat

My Favorite

Chicken Nugget Button

Pizza Button

Keep Warm

Add-a-Minute

Delay Bake

Self-Clean

Rapid / Quick Clean Option

Delay Clean

Kitchen Timer

Timed Cook Option

Control Lock

Auto Oven Shuto

Oven Lock-Out

Oven Features

Capacity (Cu. Ft.)

Convection System

Oven Light

Hidden Bake Element

Rack Conﬁguration

Baking System

Broiling System

Bake / Broil Element (Watts)

Certiﬁcations

A.D.A. Compliant1

Sabbath Mode (Star-K® Certiﬁed)

Speciﬁcations

Oven Interior ( H x W x D )

Power Supply Connection Location

Voltage Rating

Connected Load

(kW Rating) @ 240 / 208 Volts2

Amps @ 240 / 208 Volts

Minimum Circuit Required (Amps)

Approved for Under-Counter

Installation

Shipping Weight (Approx.)

Ready-Select™

Extra-Large

Stainless Steel (S),

Color-Coordinated (W/B)

Stainless Steel (S),

Color-Coordinated (W/B)

Self Clean

Yes /

Variable (Hi - Lo)

Yes

Quick

2, 3, 4 Hours

Yes

12 Hours

4.2

2 Handle Racks

Even Baking Technology

Vari-Broil™

2,750 / 3,400

Yes

16-1/2" x 24-1/8" x 18-1/32"

Left Bottom Rear

240V / 208V / 60Hz

3.4 /2.6

14.5 / 12.5

Yes

175 Lbs.

Specifications

subject to change.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Combination Frigidaire Gas Cooktop/

27" & 30" Electric Wall Oven Under-Counter Installation

30"/ 27" Electric Single Wall Oven

Under-Counter Installation Specifications

•Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz

AC only electrical supply with ground required on separate circuit

fused on both sides of line.

•For detailed electrical requirements, refer to model-specific product

page and installation guide on web.

•Always consult local and national electric codes.

•Minimum 21" clearance for oven door depth when open.

•Minimum 23-1/2" deep cutout dimension is critical for proper

installation, to ensure that oven’s faceplate will fit flush against

cabinet front.

•Full oven base of solid plywood or similar material required,

capable of supporting 200 Lbs. Install over two runners and flush

with toe plate.

•Base must be level and cabinet front must be square.

•Allow 5" maximum height from oven base to floor, if NO cooktop is

installed directly over wall oven.

Gas Cooktop Installation Over

30" / 27" Electric Single Wall Oven Specifications

All Frigidaire® Electric Single Wall Ovens are approved to be used

beneath any approved Frigidaire® Gas Cooktop.

For detailed Gas Cooktop installation, refer to model-specific product

page and installation guide on web.

•Side filler panels necessary to isolate oven from adjoining cabinets.

Panel height may need to be modified to accommodate the depth

of approved gas cooktop models.

•Minimum height opening of 6-1/2" (from top of counter) required

in right cabinet side panel and/or filler panel, to route gas and

electric hookups.

•Allow 4-1/2" maximum height from oven base to floor, if cooktop is

installed directly over wall oven.

Note: For planning purposes only. Refer to Product Installation Guide

on the web at frigidaire.com for detailed instructions.

Gas Cooktop Installation

Over 30"/27" Electric Single Wall Oven

Electric Cooktop Installation

Over 30"/27" Electric Single Wall Oven

Combination Frigidaire Electric Cooktop/

27" & 30" Electric Wall Oven Under-Counter Installation

Specifications

subject to change.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

30"/ 27" Electric Single Wall Oven

Under-Counter Installation Specifications

•Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz

AC only electrical supply with ground required on separate circuit

fused on both sides of line.

•For detailed electrical requirements, refer to model-specific product

page and installation guide on web.

•Always consult local and national electric codes.

•Minimum 21" clearance for oven door depth when open.

•Minimum 23-1/2" deep cutout dimension is critical for proper

installation, to ensure that oven’s faceplate will fit flush against

cabinet front.

•Full oven base of solid plywood or similar material required,

capable of supporting 200 Lbs. Install over two runners and flush

with toe plate.

•Base must be level and cabinet front must be square.

•Allow 5" maximum height from oven base to floor, if NO cooktop is

installed directly over wall oven.

Electric Cooktop Installation Over

30"/ 27" Electric Single Wall Oven Specifications

All Frigidaire® Electric Single Wall Ovens are approved to be used

beneath any approved Frigidaire® Electric Cooktop.

For detailed Electric Cooktop installation, refer to model-specific

product page and installation guide on web.

•Side filler panels necessary to isolate oven from adjoining cabinets.

Panel height may need to be modified to accommodate the depth

of approved electric cooktop models.

•To route armored cable to junction box, cut minimum 4" x 4" opening

in right cabinet side panel.

•Allow 4-1/2" maximum height from oven base to floor, if cooktop is

installed directly over wall oven.

Note: For planning purposes only. Refer to Product Installation Guide

on the web at frigidaire.com for detailed instructions.
