Frigidaire FEB24S5AB Installation instructions

frigidaire.com

Drop-In Cooktop

FPEC3085K S

30" Electric

Signature Features

Product Dimensions

Height 30-3/4"

Width 23-7/8"

Depth 25-3/8"

More Easy-To-Use Features

Large Window

Our large oven window lets you easily

see what’s inside.

Bright Oven Lighting

Our bright lighting makes it easy to see

what’s inside.

Delay Bake

Timer Function

Timed Cook Option

Auto Shut-O

As an extra safety measure, the oven

will automatically shut off after 12 hours.

Sabbath Mode (Star-K® Certiﬁed)

Available in:

Single Wall Ovens

FEB24S5A S / B

24" Electric

White

(S)

Black

(B)

Self-Cleaning

Ovens clean themselves — so you don’t

have to.

Vari-Broil™ Option

Allows you to choose between two

heat levels.

Even Baking Technology

Our latest technology ensures even

baking every time.

Ready-Select™ Controls

Easily select options or control

cooking temperature with our

easy-to-use controls.

Accessories information available

on the web at frigidaire.com

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Specifications

subject to change.

Single Wall Ovens

FEB24S5A S / B 24" Electric

NOTE: For planning purposes only. Always consult local and national electric codes.

Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.

Spacer

Single Electric Wall Ovens

Frigidaire Baseline

Cutout Dimensions

Height (Min.)

Height (Max.)

Width (Min.)

Width (Max.)

Depth (Min.)

28-1/8"

30-1/8"

22"

22-1/4"

23-1/2"

Product Dimensions

A - Height

B - Width

C - Depth

D - Height (Wrapper)

E - Width (Wrapper)

Depth with Door Open 90˚

30-3/4"

23-7/8"

25-3/8"

28-3/32"

21-11/16"

43-3/4"

1Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz AC

only electrical supply with ground required on separate circuit fused on

both sides of line.

Features

Oven Control / Timing System

Window

Exterior Door Finish

Handle Design

Oven Cleaning System

Oven Controls

Bake / Broil

Convection Conversion

Convection Bake / Broil / Roast

Quick Bake Convection

PowerPlus™ / Quick Preheat

My Favorite

Chicken Nugget Button

Pizza Button

Keep Warm

Add-a-Minute

Delay Bake

Self-Clean

Rapid / Quick Clean Option

Delay Clean

Kitchen Timer

Timed Cook Option

Control Lock

Auto Oven Shuto

Oven Lock-Out

Oven Features

Capacity (Cu. Ft.)

Convection System

Oven Light

Hidden Bake Element

Rack Conﬁguration

Baking System

Broiling System

Bake / Broil Element (Watts)

Certiﬁcations

A.D.A. Compliant

Sabbath Mode (Star-K® Certiﬁed)

Speciﬁcations

Oven Interior ( H x W x D )

Power Supply Connection Location

Voltage Rating

Connected Load

(kW Rating) @ 240 / 208 Volts1

Amps @ 240 / 208 Volts

Minimum Circuit Required (Amps)

Approved for Under-Counter

Installation

Shipping Weight (Approx.)

Ready-Select™

Large

Color-Coordinated

Self Clean

Yes /

Variable (Hi - Lo)

Yes

12 Hours

2.9

2 Handle Racks

Even Baking Technology

Vari-Broil™

2,100 / 3,400

Yes

16" x 17" x 18-1/2"

Left Bottom Rear

240V / 208V / 60Hz

3.4 /2.6

14.5 / 12.5

130 Lbs.
