Frigidaire EICMR255-SS User manual
Introduction....................................................................................
Important Safety Information..................................................
Getting to Know Your Unit.......................................................
Operating Procedures & Maintenance..................................
How to Make Ice Cream.............................................................
Troubleshooting...........................................................................
Product Specifications...............................................................
Limited Warranty.........................................................................
2
3
Safety Instructions....................................................................... 4
5
6
8
17
Recipes.............................................................................................15
18
19
USA CANADA 1-800-
ICE CREAM MAKER
EICMR255-SS
2INTRODUCTION
WARNING
WARNING indicates apotentially
hazardous situation which, if not avoided,
could result indeath or serious injury.
IMPORTANT
IMPORTANT indicates installation, oper-
ation or maintenance information which
is important but not hazard-related.
DANGER
DANGER indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
CAUTION
CAUTION indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
Safety Definitions
This is the safety alert symbol. It is
used to alert of potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible injury
or death.
Safety Instructions
•DO NOT store or use gasoline, or
other flammable liquids in the vicinity
of this or any other appliance. Read
product labels for warnings regarding
flammability and other hazards.
•Avoid contact with any moving parts
of automatic ice cream maker.
•Remove all staples from the carton.
Staples can cause severe cuts, and also
destroy finishes if they come in contact
withother appliances or furniture.
WARNING
Please read all instructions before using
this appliance.
Child Safety
3IMPORTANT SAFETY INFORMATION
Destroy or recycle the carton, plastic
bags, and any exterior wrapping material
immediately after the Ice Cream Maker is
unpacked. Children should NEVER use these
items to play. Cartons covered with rugs,
bedspreads, plastic sheets or stretch wrap
may become airtight chambers, and can
quickly cause suocation.
This appliance must be plugged into at least a 15 AMP 110-115 VOLT 60 Hz
GROUNDED OUTLET. This appliance must be grounded. It is equipped with a
3-wire cord having a grounding plug. The plug must be plugged into an outlet that
is properly installed and grounded.
Avoid the use of an extension cord because it may overheat and cause a risk of
fire. However, if it is necessary to use an extension cord:
A. Use only 3-wire extension cords with 3-blade grounding plug.
B. The marked rating of an extension cord must be be equal to or greater than the
rating of this appliance.
C. It should be positioned such that it does not drape over the counter or tabletop
where it can be pulled on by children intentionally.
Attempting any maintenance or cleaning:
To minimize the possibility of electric shock, unplug this appliance from the power
suply or disconnect at the household distribution panel by removing the fuse or
switching o the circuit breaker before attempting any maintenance or cleaning.
NOTE: Pressing the Power ON/OFF button to an o position does not disconnect
the appliance from the power supply.
WARNING!
Improper use of grounded wire can result in the risk of electric shock.
Consult a physician if necessary. Do not attempt to defeat this safety
feature by modifying the plug.
4SAFETY INSTRUCTIONS
1. Measuring Cup
2. Touchpad Control Panel with LED display
3. Ice Cream Shovel
4. Rotation shaft of stir motor
5. Transparent cover
6. Mixing Paddle
7. Power plug
8. Mixing Bowl with Lift-Out Handle
9. Hot Air outlet
10. Cold Air inlet
General instruction
Position of control panel & function
A
I
H
B C
DE F
G
5GETTING TO KNOW YOUR UNIT
Hard Ice
Cream
STIRTIME+
Milkshake Soft Ice
cream
TIME-
START
STOP
Hard Ice
Cream
STIRTIME+
Milkshake Soft Ice
cream
TIME-
START
STOP
12345
6
7
8
910
DANGER
1. Remove the exterior and interior packaging. Check if all the parts, such as the paddle,
ice cream mixing bowl, and ice cream scoop etc., are inside. If any parts are missing,
please contact our customer service.
2. Clean the ice cream mixing bowl, paddle, and ice cream scoop first.
3. Put the unit on a level & flat counter top, and without direct sunlight and other sources
of heat (i.e.: stove, furnace, radiator).
4. Make sure that there is at least 10mm gap between the back & LH/RH sides with the wall.
5. Allow one hour for the refrigerant fluid to settle before plugging in the unit.
6. The appliance must be positioned so that the plug is accessible.
Touch Control Panel:
A. Button to select milkshake function
B. Button to select soft ice cream function
C. Button to select hard ice cream function
D. Button to increase the ice cream making time
E. Button to decrease the ice cream making time
F. Button to select stir function
H. LED display window
I. LED Light for work state and system warning indicator
1. This unit should be properly grounded for your safety. The power cord of this appliance is
equipped with a grounding plug which mates with standard grounding wall outlets to
minimize the possibility of electric shock.
2. Plug your appliance into an exclusive, properly installed, grounding wall outlet. Do not
under any circumstances; damage the grounding means of the plug under any circumstances.
Any questions concerning power or grounding should be directed toward a certified
electrician.
3. This appliance requires a standard 110-120Volt, 60Hz electrical outlet with good grounding
means.
4. DO NOT immerse the compressor/motor base in water.
CONNECTING YOUR ICE CREAM MAKER
UNPACKING YOUR ICE CREAM MAKER
6OPERATING PROCEDURES & MAINTENANCE
Improper use of the grounded plug can result in the risk of electrical shock. If the power
cord is damaged please call our customer service.
7OPERATING PROCEDURES & MAINTENANCE
Before using your ice cream maker, it is strongly recommended to clean it thoroughly.
1. Turn the transparent cover by counterclockwise, be sure the arrow on lid is lined up with the
lock icon on the base, and then you can take the cover out.
2. Take out the paddle and ice cream mixing bowl.
3. Use a dry, clean, soft cloth to clean the internal wall of the ice cream making house smoothly,
no need to use water or wet cloth to clean it.
4. The outside of the unit should be cleaned regularly with a mild detergent solution and warm
water. DO NOT immerse the compressor/motor base in water. It will wet the inside electrical
parts and cause the electrical safety problem.
5. Then you can put the transparent cover, paddle, ice-making mixing bowl, and the ice cream
scoop into the water, and use the wet and soft cloth to clean them. Then dry them before
running the unit. Warning: Don’t use the abrasive tool to wipe them.
6. Dry all the parts and exterior with a clean soft cloth.
7. Put back all the parts to the original position.
8. When the machine is not to be used for a long time, clean & dry all the parts and the unit.
If your ice cream machine has been tilted for any reason,wait over 2 hours before piugging in.
CLEANING AND MAINTAINING YOUR ICE CREAM MAKER
8HOW TO MAKE ICE CREAM
Please prepare the material of the ice cream per your personal food recipe or refer to the
recipe page 15 and 16. No need to put the material and the ice cream mixing bowl into
freezer for freezing ahead, this ice cream maker can freeze the material and make the ice
cream directly.
1. Put your ice cream materials inside the ice cream mixing bowl and also with some warm
water, then stir smoothly and mix it uniformly.
2. Put the ice cream mixing bowl filled with material into the ice cream making house.
3. Install the paddle on the rotating shaft.
Please follow the step：
HOW TO MAKE ICE CREAM 9
4. Put back the transparent cover and turn it clockwise to install tightly. Then plug in the unit.
6. You can add some other favorite ingredient during making process.
Note: It cant ' change the mode during it's making Ice Cream, so Please make sure what
style do you want before starting.
TIME-
Hard Ice
Cream
STIRTIME+
Milkshake Soft Ice
cream
START
STOP
5. Press the Milkshake/Soft Ice Cream/Hard Ice Cream or stir button to select the function,
then press the START/STOP button to start or stop the function, also can press the TIME+
or TIME- button to change the duration time a little during the making process. Press the
STIR button again that will be stopped during it's stirring.
10HOW TO MAKE ICE CREAM
7. In order to dig out the sphere ice cream from the bowl by the sphere ice cream device
after the hard ice cream is made, please take out the paddle when making the hard ice
cream. Use the ice cream scoop to wipe down the soft ice cream from the surface of
paddle and then make hard ice cream.
Note: Please take out this paddle after stopping rotating.
8. Once the ice cream making process completed, you can enjoy it at once. If you
don’t finish, you can put the ice cream mixing bowl back in the ice cream making
housing to keep cool.
WARNING:
1. With the ice cream making time passed, the ice cream become more harder, the stir motor
will be locked and the paddle will stop rotating. It is normal, but when the unit enters the hard
ice cream making process, the internal control system will buzz to remind you, please take out
the paddle.
2. Be sure don't pour ice cream material volume exceeding 60% of the ice cream mixing bowl
maximum capacity. Otherwise it will overflow the bowl.
