Freedom Motors BUICK ENCLAVE User manual
BUICK ENCLAVE
Wheelchair Accessible SUV Owners Manual
BENCH SECUREMENT
..
This manual illustrates and describes the operation of features and equipment
that are either standard or optional on this vehicle. This manual may also include
a description of features and equipment that are no longer available or were not
ordered on this vehicle.
Freedom Motors reserves the right to make changes in design and specifications,
and/or make additions to or improvements to its products without imposing any
obligation upon itself to install them on products previously manufactured.
Freedom Motors USA, Inc.
TABLE OF CONTENTS
INTRODUCTION ....................................................................................... 1
SAFETY PRECAUTIONS......................................................................... 2
REMOTE KEYLESS ENTRY TRANSMITTER ....................................... 3
CONTROL SWITCHES ............................................................................. 4
OPERATION INSTRUCTIONS ................................................................ 5-6
SEATING SECUREMENT ........................................................................ 7
MANUAL OPERATION ............................................................................ 8
DOCKING SYSTEM OPERATIONS ....................................................... 9-10
SCHEDULED MAINTENANCE .............................................................. 11
MAINTENANCE LOG .............................................................................. 12-13
WARRANTY............................................................................................... 14-17
1
INTRODUCTION
CONGRATULATIONS ON PURCHASINGYOUR WHEELCHAIR
ACCESSIBLE BUICK ENCLAVE FROM FREEDOM MOTORS
Please take the time to read this publication carefully. Following the
instructions and recommendations in the manual will help assure safe and
enjoyable operation of your vehicle. When it comes to service, remember
that your authorized dealer knows your vehicle best, has factory-trained
technicians, and cares about your satisfaction.
2
SAFETY PRECAUTIONS
If you have any questions or concerns regarding your Buick
Enclave, please contact Freedom Motors directly at 800-625-6335
• Read your owners manual before operating the vehicle. In addition to reading
the owners manual, please make sure your Freedom Motors salesperson
explains and demonstrates the vehicle’s features before operating.
• Before operating the ramp, make sure the transmission is in park.
• Do not operate the ramp in traffic or hazardous conditions.
• All wheelchairs must be facing forward and properly secured.
3
REMOTE KEYLESS ENTRY
Open Function
Pressing and holding button 1 will open the
rear door and deploy the ramp. Releasing the
button will halt the ramp opening and can be
moved manually if desired.
Close Function
Pressing and holding button 2 will retract the
ramp and close the rear door. Releasing the
button will halt the ramp closing and can be
moved manually if desired.
Keyless Entry Transmitter
REMOTE KEYLESS ENTRY
3
Open Function*
Pressing and holding button 1 will deploy the
ramp. Releasing the button will halt the ramp
opening and can be moved manually if desired.
Close Function*
Pressing and holding button 2 will retract the
ramp. Releasing the button will halt the ramp
closing and can be moved manually if desired.
Keyless Entry Transmitter
CAUTION: Be certain to release button after
ramp completely deploys. Failure to do so may
result in damage to ramp components.
*If factory equipped with automatic rear hatch,
use OEM remote to open/close.
4
CONTROL SWITCHES
CONTROL SWITCHES
The drivers ramp
deploy / retract switch
is located on the
dashboard on the left
side of the steering
wheel. This switch
activates the conversion
functions.
The back seat ramp
Ramp Deploy / Retract Switch
4
DO NOT retract the ramp if a person or object
is on the ramp. This could cause ramp system
damage or serous bodily injury.
WARNING
Ramp Deploy / Retract Switch
The drivers ramp
deploy / retract switch
is located on the
dashboard on the left
side of the steering
wheel. This switch
activates the conversion
functions.
WARNING
DO NOT retract the ramp if a person or object is on
the ramp. This could cause ramp system damage or
serious bodily injury.
5
OPERATION INSTRUCTIONS
WARNING
Before operating the power door and power ramp, make sure the rear
area of the vehicle is clear and unobstructed.
Allow approximately 8 feet for the ramp to deploy beyond the rear of the
vehicle plus an additional 4 feet for the wheelchair occupant to maneuver.
OPERATION INSTRUCTIONS
6
The wiring circuits for the automatic ramp conversion are protected from short circuits by a combination of fuses
and circuit breakers. This greatly reduces the chance of damage by electrical problems.
Checking and ReplacingThe Fuse
If the automatic ramp deployment is not working, check the placement and
condition of the fuse.
Note: The fuse for ramp operation is separate from the vehicle’s OEM fuse
block. It is located along a circuit leading from the battery.
To inspect the fuse:
• Look at the silver-colored band inside the fuse.
• If the band is broken or melted, replace it with a new one of the identical
size and rating.
To replace the fuse:
• Remove the fuse cover.
• Pull the fuse straight out.
• Replace the fuse with a new one of the identical size and rating. Ensure
the fuse is inserted completely.
WARNING
Fuses and circuit breakers are marked with their ampere rating. Do not exceed the specified amperage rating
when replacing fuses and circuit breakers. Use of an oversized fuse or circuit breaker can result in a vehicle
fire. Consult your OEM vehicle manual for more information.
