Franklin MWD-520 User manual
License Agreement
READ THIS LICENSE AGREEMENT BEFORE USING
THE ELECTRONIC REFERENCE. YOUR USE OF THE
ELECTRONIC REFERENCE DEEMS THAT YOU ACCEPT
THE TERMS OF THIS LICENSE. IF YOU DO NOT
AGREE WITH THESE TERMS, YOU MAY RETURN THIS
PACKAGE WITH PURCHASE RECEIPT TO THE DEALER
FROM WHICH YOU PURCHASED THE ELECTRONIC
REFERENCE AND YOUR PURCHASE PRICE WILL BE
REFUNDED. ELECTRONIC REFERENCE means the
software product and documentation found in this package
and FRANKLIN means Franklin Electronic Publishers, Inc.
Limited Use License
All rights in the ELECTRONIC REFERENCE remain the
property of FRANKLIN. Through your purchase,
FRANKLIN grants you a personal and nonexclusive
licensed to use this ELECTRONIC REFERENCE. You may
not make any copies of the ELECTRONIC REFERENCE or
of the data stored therein, whether in electronic or print
format. Such copying would be in violation of applicable
copyright laws. Further, you may not modify, adapt,
disassemble, decompile, translate, create derivative works
of, or in any way reverse engineer the ELECTRONIC
REFERENCE. You may not export or reexport, directly or
indirectly, the ELECTRONIC REFERENCE without
compliance with appropriate governmental regulations. The
ELECTRONIC REFERENCE contains Franklin’s
confidential and proprietary information which you agree to
take adequate steps to protect from unauthorized
disclosure or use. This license is effective until terminated.
This license terminates immediately without notice from
FRANKLIN if you fail to comply with any provision of this
license.
Introduction
Congratulations on your purchase of the MWD-
520. You can now use your dictionary as a
bookmark! Clip the unit onto the cover of your
book and use the ribbon to mark a page. With this
dictionary you can find over 80,000 entries, correct
misspellings, save words to My Word List, sharpen
your spelling and increase your vocabulary with
learning exercises, and play fun, educational word
games. You can also set local and world times
using the clocks or store names and numbers
using the databank.
Key Guide
Main Keys
Toggles between the calculator and
Conversions menu.
Goes to the Confusables
®
list. At the
Entry screen, types a ? to stand for a
letter in a word. At a menu, displays a
menu item. At a dictionary entry,
displays the headword. In games,
reveals the word and forfeits the
game.
Toggles between the Home and World
Clock.
Goes to the Databank menu.
Goes to the dictionary.
Goes to the Games menu.
Goes to the Learning Exercises menu.
Goes to the Setup menu.
Function Keys
In the dictionary, goes to the Entry
screen. In the calculator, clears all
entries. In the converter and
databank, goes to its main menu.
Backs up, erases a letter, or turns off
the highlight at an entry.
Shifts to type capital letters and
punctuation marks.
Enters a word, selects an item, or
begins a highlight in an entry.
Displays a help message.
Direction Keys
Move in the indicated direction.
Goes to the next entry.
Goes to the previous entry.
At menus and dictionary entries,
pages down. At the Entry screen,
types a space.
Key Combinations*
+ At a dictionary entry, goes to the top
or bottom of an entry. At menus, goes
to the top or bottom of a list.
+ At the Entry screen, types an asterisk
to stand for a series of letters in a
word. In games, gives a hint or
shuffles the letters.
*Hold down the first key while pressing the
second.
/
Calculator Keys
Q–P Types numbers.
A(1/x) Calculates a reciprocal.
S(√x) Calculates a square root.
D(x
2
)Squares a number.
F(%) Calculates a percentage.
G(.) Inserts a decimal point.
H(+),J(-) Adds, subtracts, multiplies or divides
numbers.
Z(+/-) Changes the number on the screen to
a negative or positive number.
X(
M
+) Adds the number on the screen to the
number stored in the memory.
C(
M
–) Subtracts the number on the screen
from the number stored in the
memory.
V(
MR
)Recalls the number stored in the
memory.
B(
MC
)Clears the memory.
➤About Screen Illustrations
Some screen illustrations in this User’s Guide
may differ slightly from what you see on
screen. This does not mean that your MWD-
520 is malfunctioning.
➤Help is Always at Hand
You can view a help message at any screen
by pressing HELP. Use the direction keys to
read the message. To exit help, press BACK.
To read a tutorial describing how to use the
product, select Tutorial from the Setup menu.
Replacing the Battery
Your MWD-520 uses 1 CR-2016, 3-volt lithium
battery. Important!! Before you follow these steps
please have the new battery at hand. You will also
need a small Phillips screwdriver (one that fits into
screws with an “x” notch).
1. Turn the unit off and turn it over.
2. Use a Phillips screwdriver to remove the screw
on the battery cover and then remove the
cover.
3. Remove the old battery and insert the new one
with the positive (+) side facing up.
4. Replace the battery cover.
Warning! If the battery wears out completely, or if
you take more than a few seconds while changing
the battery, any user-entered information will be
erased. You should always keep written copies of
your important information.
➤Follow the Arrows
The flashing arrows on the right of the screen
show which arrow keys you can press to move
around menus or view more text.
Setting the Clock
The clock lets you set a Home Time and view local
times around the world. You must set the Home
time before viewing World Times as World Times
are based on Home Time.
➤Setting Home Time
1. Press .
You see the Home Time mode.
2. Press Sto enter the setting mode.
3. Press ENTER to select Set Time Format.
Press or to cycle through the 12- and
24-hour Day/ Month/Year formats. Press
ENTER to save your selection.
4. Press to highlight Set DST and press
ENTER to select it.
Press or to cycle between DST On or
DST Off. Press ENTER to select your choice.
5. Press to highlight Set Home Time and
press ENTER to select it.
Press or until the current hour is
displayed.
Press to move to minutes, then press
or until the current minute is displayed.
Press ENTER to set the time.
6. Press to highlight Set Date and press
ENTER to select it.
Use or to move to the next or
previous field. Use or to scroll to the
current day/month/year. Press ENTER to set it.
7. Press to highlight Set City and press
ENTER to select it.
Press or until your local city is
displayed. Press ENTER to select it.
8. Press to exit setting mode.
➤Setting World Time
1. Press until you see World City.
Press Sto enter Setting Mode.
2. Press ENTER to select Set DST.
Press or to cycle between DST On or
DST Off. Press ENTER to select your choice.
3. Press to highlight Set World City and
press ENTER to select it.
Press or until the city you want is
displayed. Press ENTER to select it.
4. Press to exit Setting Mode and see the
World City time.
Changing the Settings
When using this dictionary, you can adjust the
screen contrast, the shutoff time, and the type
size. The shutoff time is how long your MWD-520
stays on if you forget to turn it off.
1. Press SETUP.
2. Press or to highlight Contrast,
Shutoff, or Type Size in the Settings menu.
