Fortec Star Distec POS-Line Series User manual
User Manual
POS-Line Series small V2
POS-Line Monitors
from 38 cm (15“) to 61 cm (24“)
202102_Manual_POS_Line_small_V2_EN
2
Copyright
The contents of this manual are subject to change without notice.
© 2021 Distec GmbH. All rights reserved.
Reproduction of this manual in parts or entirely without the previous authorization of Distec GmbH is prohibited.
Distec GmbH is not liable for errors and collateral or subsequent damage which result from supply, deployment or any other utilisation of this document.
All product names mentioned in this document are trademarks or registered trademarks of their due owners.
3
Table of Contents
1. GeneralSpecications ...............................................................................4
2. Chassis Versions......................................................................................... 5
3. Scope of Delivery .......................................................................................6
4. General Safety Regulations .......................................................................7
5. First Installation........................................................................................10
6. Touch Sensors........................................................................................... 14
7. POS-Line Video PME.................................................................................15
8. POS-Line IQ Atom.....................................................................................23
9. POS-Line IQ Core®-i..................................................................................27
10. POS-Line VideoPoster...............................................................................31
11. POS-Line IoT .............................................................................................36
12. WebPoster................................................................................................39
13. Maintenance ............................................................................................41
14. Guarantee / Service .................................................................................41
15. Disposal....................................................................................................43
16. Declaration of Conformity ........................................................................44
General Specications
4
1. General Specications
Scope of Document
This user manual is valid for POS-Line monitors up to 61 cm (24”). The POS-Line monitors are offered in different screen sizes and with
various controllers and other options.
Important note: All documents are available for download from Distec web site: https://www.distec.de/en/service/downloads/mon-
itor-downloads/.
POS-Line monitor versions:
POS-Line Video PME: Monitor with integrated AD converter board, 1 x RGB, 1 x HDMI, 1 x Display Port.
POS-Line IQ Atom: Monitor with integrated PC board Intel Atom.
POS-Line IQ Core-i7: Monitor with integrated PC board Intel Core-i.
POS-Line VideoPoster: Monitor with integrated network media player for video play lists.
POS-Line IoT: Monitor with integrated Raspberry®Pi CM3 ARM module.
Chassis Versions
5
2. Chassis Versions
Various front options are available for the POS-Line displays to support the mounting in different situations and applications. The front
options changes the look of the displays.
Note: All the photos and graphic representations of this document show open frame displays. However, the explanations
apply also to displays with front bezel.
Displays with various front bezels:
Open frame display
(without bezel)
For mounting with angles or VESA com-
patible mounts.
Display with front bezel
For VESA compatible mounts.
Display with front plate
For front mount applications with angles
or VESA compatible mounts.
Display with true-at glass
For front mount applications with angles
or VESA compatible mounts.
Scope of Delivery
6
3. Scope of Delivery
When unpacking the monitor, please check if the following accessories are included in the shipment:
Note: Pictures can differ from actually supplied products.
Product information
RGB cable*** USB cable* Power adapter
USB stick** 2 mounting brackets****
* Devices with touch sensor only
** POS-Line VideoPoster series only
*** POS-Line PME series only
**** Not together with option front bezel
General Safety Regulations
7
4. General Safety Regulations
Safety information
Please read this safety information carefully for your personal safety and for the prevention of property damage.
In case of a malfunction, immediately disconnect the power plug and contact your dealer or the next Data Display Group service cen-
tre. A malfunction is also considered if the housing, a control element or cable is damaged or if liquids or other objects penetrate the
monitor.
Please read the safety information carefully before installing the device. If you have any doubts about whether the device may be used
in a particular environment, please contact our service partner.
Repairs
Repairs may only be carried out by authorized technical personnel. Unauthorized access or improper repairs might cause serious prop-
erty damage or cause danger to the user. In addition to that, any legitimate warranty claim expires.
Electrical connection
Disconnect the monitor from socket before executing any work. Do not touch or connect data cables or power cables during thunder-
storms.
System start-up
Before the system start-up let the monitor adjust to the room temperature. Do not expose the device to direct heat sources. In case
of condensation, please wait a minimum of 12 hours before switching on the monitor. The monitor shall only be installed and used
according to this documentation data sheets. Only qualied personnel may perform the initial installation and system setup.
Qualied personnel
Qualied personnel, in terms of the safety information of this documentation, are persons who are qualied to activate, ground and
label devices, systems and circuits according to the safety standards.
Operation
For a proper and safe utilization of the product, adequate transportation, storage, installation, assembly, careful handling and main-
tenance are essential. The device is only certied for in-door operation. Extreme ambient conditions shall be avoided and the monitor
shall be protected from dust, humidity and heat. Do not expose the monitor to direct sunlight.
Transport
Unpack the monitor at the place of installation. Use only original packaging for transportation. Please observe these rules for any later
transport.
Condensation
Avoid condensation during transport at low temperatures or at extreme uctuations of temperature.
General Safety Regulations
8
• Do not put objects onto the device.
• Do not place candles, heaters or humidier near the device.
• Keep the device away from replaces and ammable materials.
• According to the size, devices may be difcult to handle and very heavy. Ensure that at
least two people lift and carry the device.
• Put down the device slowly and carefully to avoid damaging the LCD screen. Ensure that
the device stands stable.
• Keep packaging away from children. Danger of suffocation!
• Use our specied and professionally mounted wall mounting only.
• Do not use extension block to plug several devices into a single socket.
• Do not use damaged or loose sockets to plug in the device.
• Plug the device in secured sockets only.
• Operate the device with the power cables included in the delivery packet only.
• Use undamaged power cables only.
• When plugging in and out, do not touch the power cable with wet hands.
• Ensure that the power cable is plugged in the socket safely and correctly.
• Use for devices with external power supply only Low Power Source (LPS).
Safety guidelines for the handling of LCD monitors
• If the device is not used for a long period of time, unplug the power cable.
• Do not unplug the power cable while the device is powerd on, except for emergencies.
• To unplug the device without problems, sockets have to be easily accessible.
• Ensure that the power cable does not get pinched or kinked.
• Do not place heavy objects on the power cable.
General Safety Regulations
9
• In case of unusual noises, burnt smell or smoke unplug the power cable.
• Do not insert objects into the device through the ventilation slots.
• If the same picture is displayed over a longer period of time, an after-image may arise.
• When exchanging batteries, pay attention to the polarity. Keep batteries away from
children and ensure an environmentally correct disposal.
• Please use a soft, moist cloth for cleaning.
• For cleaning the screen, please use only commercially available screen cleaner. Do not
spray the cleaner directly to the device but onto a cloth.
• Please clean ventilation slots regularly to ensure a good air circulation.
• Protect your device from water splash.
• When cleaning, please make sure that no liquids get into the device.
• Screens and surfaces can be easily scratched. Therefore, please use the prescribed
cloth only.
• Do not install the device in places where it is exposed to environmental impacts such
as rain or direct sunlight.
• Do not install the device in places where it is exposed to high humidity, dust or smoke.
In case of doubt, please contact your sales partner.
• Ensure sufcient ventilation of the device.
• Keep a minimum distance of at least 10 mm devices to the wall, for devices with inte-
grated PC of at least 40 mm.
• Ensure compliance with the operating temperature.
First Installation
10
5. First Installation
Position of connectors and controls
All the connectors for power and cables are located at the bottom of the back side of the display. The OSD keyboard (POS-Line Video
series only) is located at the top of the back side.
Position of the OSD keyboard (Video series only)
Position of the connectors for power and signal cables
Mounting with VESA compliant monitor brackets
VESA-Befestigungspunkte
VESA mounting points
The POS Line monitors have an integrated VESA mounting.
The operating position of the device is perpendicular (90 degrees to the oor). For wall mounting, the permissible tilt angle is observed.
The device can be operated both in landscape mode and in portrait mode.
VESA formats:
VESA 200x100 POS Line
This manual suits for next models
5
