Dear Customer,
THE FORBES XTRA TUFF STORAGE WATER PURIFIER IS FROM THE MARKETERS OF AQUAGUARD, EUREKA FORBES
LIMITED
FOUR-STAGE PURIFICATION PROCESS
2 Tier – PHYSICAL FILTRATION:
CARBON BLOCK:
ACTIVE DISINFECTANT:
SIMPLE STEPS TO ASSEMBLE THE UNIT:
How to fix the Sediment and Carbon Block Filter Cartridge:
Fixing up float mechanism:
Placing and assembling the body and Sediment Filter & tap:
Flushing of Filter Cartridge & Carbon:
How to get purified water:
How to purify water:
Congratulations on your purchase of the Forbes Xtra Tuff Storage Water Purifier. With this purchase you have wisely
invested in your family's health by providing them protection against waterborne diseases caused by bacteria and
viruses. The Forbes Xtra Tuff Storage Water Purifier has been designed to provide you with safe drinking water. We
recommend you read the User Manual carefully before commencing use of the product.
Should you require any assistance just call us on 1860 - 266 - 1177.
Your Forbes Xtra Tuff Storage Water Purifier is made of food grade material and provides you with pure and safe
drinking water.
Stages 1 & 2
Comprises Particulate and Sediment Filters, removes suspended impurities from
water and provides clear water.
Stage 3
It removes organic, chemical impurities and chlorine. It also removes bad taste and odour from water.
Stage 4
It destroys bacteria that cause waterborne diseases like diarrhoea, dysentery, gastro-enteritis,
cholera, typhoid etc., and viruses.
Fig. (1)
Soak the Filter Cartridge & Carbon Block to remove any air bubbles. Fig. 1(a)
Take out the Cartridge & Carbon from the carton
Remove the sticker from the bottom of the Cartridge and pull the string from the top of the Cartridge to remove
the rubber seal. Soak the Cartridge & Carbon under water for 30 mins.
Now press fit the Filter Cartridge (which has several vertical slits on its outer cover) into the top container. Fig. 1(b)
Insert the air vent pipe on the top hole of the Carbon Block. Fig. 1(c)
Place the Particulate-filter bag in position on the top lid. Fig. 1(d)
Screw the external threaded end of the float in a clockwise direction to the threaded por tions of the top
container. Fig. 1(e)
Fig. (2)
Place the bottom container on a flat surface. Fig. 2(a)
Fix the tap. Fig. 2(b)
Place bottom container on stand as shown in Fig. 2 (c)
Place the mid-frame on the bottom container. Fig. 2 (d)
Place the top container with the fitted filter cartridge on the mid-frame.
Rinse the Particulate filter thoroughly in water. Then place the Particulate Filter at the mouth of the lid. Fig. 2(e)
Fill the top container with water and allow it to filter through the cartridge into the bottom container. Fig. 2(f)
Drain off the water from the bottom container through the tap
Again fill water in the top container. Fig. 2(e)
Place the top lid and turn clockwise and lock it
YOUR FORBES XTRA TUFF STORAGE WATER PURIFIER IS NOW READY FOR USE.
Follow the above procedure every time a new cartridge is replaced.
Fig. 3 (a) & (b)
Fill the top container with water through the Particulate Filter
Close the lid by rotating it
Wait for completion of filtration
Discard this water completely from the bottom container when the product is used for the first time
Ensure cleaning the inner bottom surface of the bottom container
Follow the above procedure every time a new cartridge is replaced
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
