Fnirsi FNB48P User manual
●The dark blue below the trigger timing is the load resistance.
●The first column of the bottom white table is D+, D- voltage;the second column is the
current charging agreement that may be in progress;the third column is the status
bar. When the trigger timer starts, it will display RUN , and it will display STOP
when it stops，when the instrument does not trigger any fast charging protocol is
displayed as NONE , when a certain fast charging protocol has been triggered,
such as QC2.0, it is displayed as QC2.0 .
